Epygi Quadro2x Administrator's Manual page 104

Quadro2x Manual II: Administrator's Guide
Parameter
Extension Settings – Remote
Extension Settings – Call Queue
Extension Settings – Voice Mailbox
Extension Settings – Codecs
Attendant 00 Settings – General
Attendant 00 Settings – Attendant
Scenario
Attendant 00 Settings – SIP and SIP
Advanced
Attendant 00 Settings - Codecs
Universal Extension Recordings
Receptionist Management
Extensions Directory
Call Statistics
SIP Settings
RTP Settings
NAT Traversal Settings
Quadro2x, Quadro2xi; SW Version 4.0.x
System Default Value
Remote Extension – disabled
Call Queue – disabled
Extensions 11, 31 and 32 – Use Internal Voice Mail,
Extension 12 – Disabled Voice Mail.
Codecs - G711u (preferred), G711a, G729a, G726/32, G726/16, G726/24, G726/40
Out of Band DTMF Transport – enabled,
T.38 FAX – disabled on extensions 11 and 31-32, enabled on extension 12,
Pass Through FAX – enabled,
Pass Through Modem – disabled,
Force Self Codecs Preference for Inbound Calls - disabled.
Display name – Attendant,
FAX forwarding – enabled, Extension to forward – 12,
Percentage of System Memory – 3%.
Scenario – default,
Send AA digits to Routing Table – disabled,
Welcome Message – enabled,
Welcome Message and Recurring Attendant Prompt – default,
Authorized Phones Database – undefined.
Same as for an extension.
Codecs - G711u (preferred), G711a, G726/16, G726/24, G726/32, G726/40, G729a,
G723, iLBC
Out of Band DTMF Transport – enabled,
T.38 FAX – enabled,
Pass Through FAX – enabled,
Pass Through Modem – disabled,
Force Self Codecs Preference for Inbound Calls - disabled.
Default, Percentage of System Memory – 1%.
No entries
No entries
Enabled
100 entries for all type of calls
UDP and TCP Port – 5060,
Session Timer – disabled,
DNS Server for SIP – default,
SIP timers – RFC 3261.
Properties for all Codecs except G723 and iLBC :
Packetization -20ms
Silence Suppression -yes
G723 and iLBC properties:
Packetization - 30ms
Silence Suppression – yes
G276 Standard - ITU-T specification
RTP/RTCP port range - 6000-6049
Telephone Event Draft Support - enabled
RTCP Support - disabled
NAT Traversal for SIP – Automatic
SIP and RTP Parameters - Use STUN
SIP TCP Port – 5060
STUN Parameters:
Primary STUN Server - stun.epygi.com
Primary STUN Port – 3478
Secondary STUN Server – undefined
Secondary STUN Port - undefined
Polling Interval: 1 hour
Keep-alive interval: 120 seconds
NAT IP checking interval: 300 seconds
No entries in NAT Exclusion table
Appendix: System Default Values
