Quadro Baseline
The Call Routing – Local AAA Table - Add Entry page offers a
group of manipulation radio buttons to select the type of
authorization and the following other parameters:
•
Authentication by Caller ID – this selection is used to set
the authentication based on the caller's phone number (which
is considered to be automatically detected). The Phone
Number text field requires the caller's phone number. Only
numeric and wildcard characters (see chapter
Addresses correctly) are allowed for this field. '[' , ']' , ',', '-', '{',
'}' are used to define a range or a quantity of numbers. For
example, 2{13-17, ww, a-c} means that the dialed number
may be 213, 214, 215, 216, or 217, 2ww, 2a, 2b and 2c to
match the specified phone number; in the case of 2[3,7], the
dialed number may be 23 or 27 to match the specified phone
number.
•
Authorization by Username and Password – this selection
is used to set the authentication based on the username and
password inserted by the user upon login. The Username
text field requires the authentication username. Only numeric
values are allowed for this field, otherwise the error message
"Incorrect Username - digits allowed only" will appear. The
Password text field requires the authentication password.
Only numeric values are allowed for this field, otherwise the
error message "Incorrect Password - digits allowed only" will
appear.
The Expiration Date and Time drop down lists are used to set the
date and time when the registration will expire.
The Expires in checkbox is used to enable the Expiration Date
and Time feature.
The Description text field requires an optional description about
the calling party.
To create a new Call Routing rule
1. Click on the Call Routing Table link on the Call Routing page.
2. Press the Add button on the Call Routing page.
3. Specify the Pattern in the corresponding field.
4. Select the Number of Discarded Symbols and Prefix if required.
5. Select the Call Type from the drop down list.
6. Define the Metric or leave the default.
7. Enter a Description if needed.
8. Enable the Filter on Caller / Call Type / Modify Caller ID checkbox, if the route functionality should be limited. This is dependent on the
inbound caller information.
9. Enable the Set Date/Time Period(s) checkbox if a route should be functional within certain time/date intervals.
10. Press Next.
11. Select the user or attendant extension from the Use Extension Settings drop down list that the call will be placed on.
12. Specify the Destination Host and Port Number, Username and Password if an IP or IP-PSTN call type has been selected. For the IP-PSTN
call type, enable Multiple Logons if necessary. Enable the Use RTP Proxy checkbox if needed.
13. Choose the Authentication and Accounting method from the AAA Required drop down list.
14. Choose a Fail Reason from the corresponding drop down list.
15. Configure Transport Protocol for SIP messages and SIP Privacy parameters as needed.
16. Press the Next button.
17. If the Filter on Caller / Call Type / Modify Caller ID checkbox has been previously enabled and the call type is different from the FXO, fill in
the Inbound Caller Pattern into the corresponding text field. Choose the needed value from the Inbound Call Type drop down list, as well as
the Inbound Number of Discarded Symbols and Inbound Prefix values.
18. Press the Next button.
19. If IP has been selected on the previous step in the Inbound Call Type drop down list, then Inbound Host should be inserted in the current
page. If FXO or ISDN has been selected in the Inbound Call Type drop down list, then the ISDN trunk or the FXO line number should be
selected here.
20. If the Set Date/Time Period(s) checkbox has been selected on the first page, pressing Next will open the Date/Time Rules page where route
validity should be defined.
21. Press the Finish button to establish a local route with the inserted settings.
To create a local AAA entry
1. Click on the Local AAA Table link on the Call Routing page.
2. Press the Add button on the Local AAA Table page.
3. Choose the Authentication type.
4. Enter the Phone Number or the Username and Password depending on the selected Authentication type.
5. Use the Expiration Date and Time checkbox to enable the expiration timeout.
6. Select the Expiration Date and Time from the corresponding drop down lists.
Quadro2x, Quadro2xi; SW Version 4.0.x
Quadro2x Manual II: Administrator's Guide – Administrator's Graphical User Interface
E ntering a SIP
3 1 2 H
Fig. II-128: PSTN User Registration - Add Entry page
