Epygi Quadro2x Administrator's Manual page 26

Quadro Baseline
Please Note: Installing new firmware will take about 15
minutes. During this time, Quadro, telephony and Internet
access will be disabled.
The firmware update will cause the loss of the following
data:
•
All internally stored voice mails and custom voice
messages
•
DHCP leases
•
Transfer statistics
•
Call statistics
•
All pending events
•
User specific GUI states
The following main processes will be stopped during the
firmware update and will be restarted after the installation is
completed:
•
Voice Software
•
Network Time Protocol Daemon
•
Network Interface Statistic Daemon
•
Dynamic DNS Daemon
Please Note: If you consider the
displayed tables to be important, it is recommended to
download them from the corresponding page prior to starting
the Firmware Update.
Next will move you to the second page of Firmware Update
where the image file should be selected.
The second page of Firmware update has a Browse button
used to browse the image file, and the Specify Image text
field that will display the selected image filename.
Pressing Save will start uploading the image file to the
board and the next page will display results and verification
of the image being burned.
This page displays non-editable information about the image
validity. The Image Check field will display "invalid" if the
image does not correspond to the hardware version.
The Current Software Version field shows the old software
version. The New Software Version field shows the new
version of the software image.
This page needs to be confirmed in order to continue image
updating. If you are sure that the image version is
appropriate for your device press Save.
Quadro2x, Quadro2xi; SW Version 4.0.x
Quadro2x Manual II: Administrator's Guide – Administrator's Graphical User Interface
C all Statistics entries in the
2 6 7 H
Fig. II-39: Firmware Update page 1
Fig. II-40: Firmware Update page 2
Fig. II-41: Firmware Check page
