Epygi Quadro Series Manual

Configure fermax ip dp device on the quadro ip pbx
Hide thumbs Also See for Quadro Series:

Advertisement

Quick Links

Download this manual
Epygi Technologies
How to Configure Fermax IP DP device
Revision
Initial draft
valid for Quadro IP
PBX SW-version:
tested with
SW version:
Filename:
Version:
Last saved:
Abstract:
IP PBX with the Fermax Audio and Video Door Entry IP DP
1CP201 device (cityline series), hereafter referred as Fermax
IP DP device.
Please Note:
This document contains confidential and proprietary information owned by Epygi Technologies Ltd. Any copying, use or disclosure of
the document or the information contained herein without the written permission of Epygi Technologies Ltd. is strictly prohibited.
on the Quadro IP PBX
Revised By
Harutyun Gerasimenko
5.2.x and higher
5.2.21
ConfiguringFermaxIPDPdevice.doc
1.0
27/07/2011 14:43:52
Revision: 1.0
This document describes how to configure Quadro
Date
20-May-11

Advertisement

loading
Need help?

Need help?

Do you have a question about the Quadro Series and is the answer not in the manual?

Questions and answers

Related Manuals for Epygi Quadro Series

Summary of Contents for Epygi Quadro Series

  • Page 1 IP DP device. Please Note: This document contains confidential and proprietary information owned by Epygi Technologies Ltd. Any copying, use or disclosure of the document or the information contained herein without the written permission of Epygi Technologies Ltd. is strictly prohibited.
  • Page 2 Epygi Technologies Configuring Quadro with Fermax IP DP device Document Revision History Revision Date Description Valid for SW Valid for models 27-Jul-11 Initial release 5.2.x Quadro IP PBXs PAGE 2 27-Jul-11...

  • Page 3: Table Of Contents

    Epygi Technologies Configuring Quadro with Fermax IP DP device Table of Contents: Introduction................4 Requirements and Preparations ..........4 Configuration ..............4 Configuring the Quadro IP PBX..........5 Fermax IP DP Device Configuration as IP Line of Quadro IP PBX... 7 IP Video Phone configuration notice .........11 References ................11...

  • Page 4: Introduction

    Epygi Technologies Configuring Quadro with Fermax IP DP device 1 Introduction Quadro IP PBXs provide the option of using SIP phones/devices along with standard analogue phones. SIP phones/devices are connected to any network interface of Quadro via Ethernet and serve as additional extensions similar to onboard FXS extensions. The Quadro can be configured to serve IP phones connected to either LAN or WAN interfaces (see Figure 1, 2).

  • Page 5: Configuring The Quadro Ip Pbx

    Epygi Technologies Configuring Quadro with Fermax IP DP device 3.1 Configuring the Quadro IP PBX To configure the Quadro, login to the Quadro Web Management from your PC and configure the IP Line that will be used for the Fermax IP DP device to register to the Quadro: Log into the Quadro as an administrator and access Telephony->Line Settings->IP Line...
  • Page 6 Epygi Technologies Configuring Quadro with Fermax IP DP device Figure 4 Please Note: IP lines table lists only the extensions attached to the IP lines. If the extension is not listed on this page, go to Users ->Extensions Settings page and attach an IP line to the extension by editing the corresponding extension settings (see Figure 5).

  • Page 7: Fermax Ip Dp Device Configuration As Ip Line Of Quadro Ip Pbx

    Epygi Technologies Configuring Quadro with Fermax IP DP device To enable video, user should go to “Go To Codec Settings” link and enable H263 codec from that page. 3.2 Fermax IP DP Device Configuration as IP Line of Quadro IP To configure Fermax IP DP device as IP Line of Quadro IP PBX, one should change position of “DIP...
  • Page 8 Epygi Technologies Configuring Quadro with Fermax IP DP device • Log in to Fermax IP DP device using default 192.168.1.250 IP address (default user name “admin”, default password “1234”). • Click on “Network Settings” link and change IP address to the IP address in Quadro’s WAN or LAN subnet (depending on the way of IP phones configured on the Quadro, either on LAN or on WAN, please see Quadro’s configuration).
  • Page 9 Epygi Technologies Configuring Quadro with Fermax IP DP device Figure 7 • Set up “SIP proxy server” -> “Address” to the IP address of Quadro’s interface used for phones configuration. • Set up “SIP proxy server” -> “Port” to the SIP UDP port of Quadro IP PBX (specified in the UDP Port field of Quadro IP PBX in the Telephony->SIP Settings page).
  • Page 10 Epygi Technologies Configuring Quadro with Fermax IP DP device   Figure 8   • Press “memory number” link on the left part of WEB GUI of the phone (see Figure 9):   Figure 9 On Button 1, Button 2 user can set up any extension number or any routing rule number and press “save changes”...

  • Page 11: Ip Video Phone Configuration Notice

    Grandstream GXV 3175 • Yealink VP2009 5 References The following documents can be helpful for further configuration of the Quadro IP PBX. They can be downloaded from Epygi’s WEB portal at www.epygi.com • Quadro Manual II - Administrators Guide PAGE 11...
  • Page 12 THIS DOCUMENT IS PROVIDED TO YOU FOR INFORMATIONAL PURPOSES ONLY. The information furnished in this document, believed by Epygi Technologies to be accurate as of the date of publication, is subject to change without notice. Epygi Technologies assumes no responsibility for any errors or omissions in this document and shall have no obligation to you as a result of having made this document available to you or based upon the information it contains.
