Mail Settings; Sms Settings - Epygi Quadro2x Administrator's Manual

Quadro Baseline

Mail Settings

The System Mail Settings page allows you to send warnings automatically about the board status or problems to the administrator. System events
that require email notification are selected on the
message transmission to the extension user's mailing account.
Enable enables system mail sending and voice messages
transmission to the extension user's mailbox.
SMTP Host requires the SMTP host IP address or domain
name. The SMTP host needs to be configured to enable voice
message transmission.
SMTP Port requires the SMTP host port number.
Mail Sender Address text field requires the source address for
the Quadro notification emails. The email address defined here
should be an existing valid e-mail address registered on the
selected SMTP server or it should have permission to use that
particular SMTP server for e-mail transmission.
Mail Recipient Address text field requires an active e-mail
address where system emails will be delivered. The e-mail
recipient here can be a Quadro administrator or someone
responsible for network and system problems.
Mail Recipient Address (CC) text field requires an active email
address where a carbon copy (CC) of the system emails will be
delivered.
Enable SMTP Authentication must be selected if the specified
SMTP server requires
authentication User Name and Password configured on the
SMTP server should be defined in the corresponding text fields.
Send Test Mail is used to initiate a test e-mail transmission.
This button will be enabled if correct values have been
submitted and saved on this page.
To configure the System Mail
1. Enable the system mail sending by the Enable checkbox selection.
2. Update or set the SMTP host in the SMTP Host text field.
3. Update or set the e-mail sender address in the Mail Sender Address text field.
4. Update or set the e-mail address in the Mail Recipient Address text field.
5. Enable SMTP Authentication if it is required on the server.
6. Insert into the corresponding text fields an authentication User Name and User Password defined by your SMTP server.
7. Press the Save button to submit these settings.
8. Use the Send Test Mail button to send a test e-mail with the configured settings.

SMS Settings

The SMS Settings are used to configure the SMS parameters that will allow Quadro to send the voice mail notifications or event notifications via
SMS to the extension user's mobile phone. Every extension user can enable voice mail notifications when a new voice mail is received and they can
to define their own mobile numbers from the Voice Mail Settings or to set the certain
Quadro to deliver SMS notifications, the SMS service should be enabled and SMS settings should be configured from this page.
Quadro2x, Quadro2xi; SW Version 4.0.x
Quadro2x Manual II: Administrator's Guide – Administrator's Graphical User Interface
E vents page. System mail must be enabled and the SMTP server needs to be configured for voice
2 6 5 H
authentication. In this case,
E vents notification to be delivered per SMS. However, for
2 6 6 H
Fig. II-37: System Mail Settings page
24
