Quadro Baseline
Numerous circumstances may cause a certain application on
Quadro to flag an event.
The Event Settings page lists all possible events on the Quadro
and allows controlling notification (action) when an event takes
place.
Each entry in the events' table has a checkbox assigned to each
row. By selecting the corresponding checkboxes, operations
such as Edit may be done for one or more events.
Edit opens the Edit Event Settings page to modify the event
action.
•
Display Notification - A notification link will be displayed
on the bottom of all pages and a record is added into the
Events table. The notification is executed as a link "Please
Check you pending events!". The link leads to the System
Events page. This action also will take place if Flash LED or
Send Mail has been selected, even if not specifically
selected.
•
Flash LED - The second LED (yellow) will blink every
second and a notification will be displayed on the bottom of
all pages. For some events the LED will start flashing after a
delay.
•
Send Mail – A notification e-mail about the new event
description in the email will be sent to the e-mail address
specified in the M ail Settings
2 6 3 H
•
Send SNMP Trap – an SNMP notification will be sent to the
traphost(s) listed in the SNMP Trap Settings table (see
S NMP Settings).
2 6 4 H
Actions that are not allowed for the selected event (like mail notification if the PPP link is down or the mail server has been configured improperly)
are hidden. For multiple events editing, actions that are not appropriate for least one of the selected events will also be hidden.
Please Note: In case of an IDS (Intrusion Detection System) intrusion alert, only the first possible intrusion in each 10 minute period will initiate an
event. This helps to avoid flooding the System Events table, and flooding the user with various intrusion alerts that result from each possible Denial
of Service attack. When these events are displayed in the System Events table, the user can receive detailed information about the intrusions
through a link to the IDS log list.
If Quadro cannot receive an IP address from the DHCP or PPP servers, or cannot register an extension on the SIP or Routing servers, or cannot
reach an NTP server, it raises only one event for the entire period the action has failed, but will continue to try. When the required action is
successful Quadro raises an appropriate message.
Quadro2x, Quadro2xi; SW Version 4.0.x
Quadro2x Manual II: Administrator's Guide – Administrator's Graphical User Interface
page.
Fig. II-33: Event Configuration Settings page
