Report Features and Shortcuts
Option
Edit curve
7-20
Use to edit selected curve properties.
• Title text box - use to change the title of the selected curve.
• Style dropdown list - use to select another style for the collected data
curve.
• Curve group box - options are disabled if Histogram is selected in the
Style dropdown list. Use to change the interpolation, point style and
pen style for the selected curve.
Color button - click to change the curve color.
Use default thickness checkbox - select to use the default curve
thickness. Deselect the checkbox and enter a new thickness number in
the Thickness text box.
• Histogram group box - enabled only if Histogram is selected in the
Style dropdown list. Use to specify the type of fill, fill color and label
position for the selected curve.
• Label dropdown list - select where the graph point labels will display
(left, right, center, etc.) on the SPC report.
Description (continued)
