TriStar II 3020
7. Select the Non-condensing Adsorptive checkbox if this file is to be used for a non-condensing
gas.
8. Enter information in the following text boxes:
• Maximum manifold pressure
• Non-ideality factor
• Density conversion factor
• Therm. tran. hard-sphere diameter
• Molecular cross-sectional area
9. In the Dosing Method group box, select From Psat tube for krypton and Normal for all other
gases.
10. Click Save, then click Close. The file saves with a .ADP file extension.

Report Options

Report Options files specify the type of reports that will be generated from an analysis or from manu-
ally entered data. They also contain report details, for example, axis scale, axis range and column
headings. Report options files may contain tabular reports, plots, or both, as well as user-defined report
tables.
Report options files may be defined to include overlay options. This system allows the overlay of up to
eight plots of different samples onto a ninth plot of the same type or overlay one plot type onto a differ-
ent plot type from the same analysis. Refer to
instructions on graph overlays.
1. Go to File > Open > Report Options or use the F5 keyboard shortcut.
2. Enter a name in the File name text box. Click Open.
302-42828-01 - Dec 2012
Overlays, page
Generating Graph
Defining Parameter Files
for further
3-37
3-15
