Sample Analysis
Field or Button
Report after analysis
button
Skip button
Suspend / Resume
buttons

Report Port [n]
button
6-4
Click to select a print destination.
• Report after analysis checkbox - select to send the report to the
screen, printer, or file in either ASCII, .XLS, or REP format.
• Export after analysis checkbox - select to send the isotherm report to
the screen, printer, or file in either ASCII or .XLS format.
Refer to Destination group box in
Options, page 5-1.
Menu
Click to skip an analysis. Button is visible only when an analysis is in
progress. Select the ports containing the analysis to skip.
Click to suspend or resume an analysis in progress. Select the ports
containing the analysis to suspend or resume.
Click to generate reports on data being collected on the respective port.
The reports are printed to the screen only.
Description (continued)
Common Fields and Buttons - File
TriStar II 3020
302-42828-01 - Dec 2012
