4 Smart VacPrep Calibration
Use to calibrate the servo valve to the manifold pressure transducer. The servo valve should always be
recalibrated after a pressure calibration has been performed. The pressure transducer should be
calibrated before starting this calibration procedure.
1. Go to Smart VacPrep > Unit [n] > Calibration > Servo Valve
2. Click Start. The window closes when the calibration is complete. Click
ibration process.
Servo Valve Fields and Buttons Table
Field or Button
Cancel
Start
4 - 2
Description
Discards any changes or cancels the current process.
Starts the operation.
.
Smart VacPrep Operator Manual — 067-42800-01
Cancel to stop the cal-
