3 Operate the Smart VacPrep
Smart VacPrep Evacuate Ports Fields and Buttons
Field or Button
Cancel
Evacuate Options
Evacuate Port[s]
Start
Q S D
UICK TART EGAS
Smart VacPrep > Unit [n] > QuickStart Degas Conditions
The QuickStart Degas Conditions option provides the ability to enter commonly used degas conditions
for each Smart VacPrep port without the need for a sample information file. Degassing can then be
easily started using the front panel buttons on the Smart VacPrep unit.
This option provides three ways to load information into QuickStart Degas Conditions:
1. Load degas conditions from an existing degas conditions file.
2. Copy conditions from another Smart VacPrep unit and port.
3. Enter degas conditions manually.
Degas conditions can be copied into sample files after degassing for record keeping.
When using the QuickStart menu option, the degas process is started using the Select button and Start
buttons for each port on the Smart VacPrep unit.
QuickStart degas conditions are remembered for the next push button operation.
3 - 2
Description
Discards any changes or cancels the current process.
Unrestricted evac. pressure. Pressure value at which unrestricted
l
sample evacuation should begin.
Vacuum level. Specify the vacuum level to be achieved before evac-
l
uation begins.
Evacuation rate. Rate of evacuation.
l
Select the ports() to evacuate.
Starts the operation.
C
ONDITIONS
