Basic Format - Micromeritics TriStar II 3020 Operator's Manual

TriStar II 3020
4. Enter Operator, Submitter and Bar Code identification information in the respective text boxes.
To omit the field and information in the sample files, select the Omit checkbox to the right of the
field.
The labels for the Sample, Operator, Submitter and Bar Code fields can be modified by
overwriting the default field labels.
5. In the Mass group box, choose whether to enter mass manually or to have the system
automatically calculate mass. Enter a value for sample mass and/or density. Refer to
Files, page 5-8.
Information
6. In the Type of Data group box, select if data are to be automatically collected or manually
entered.
7. The optional user-defined fields in the User Parameters group box may be used to enter and
track information from another instrument or source, along with other statistical process control
data. Refer to
Sample Information
8. After completing the Sample Description window, click the parameter tabs to edit other sample
information file parameters. The saved parameter defaults become the defaults for new parameter
files.
9. Click Save, then click Close.

Basic Format

When specifying defaults in the Basic format, select from existing default parameters. The defaults
established in Basic format also serve as defaults for files created using the Restricted format.
To define parameter files before entering sample defaults in Basic format, refer to
Files, page 3-6.
Information
Perform the following steps to establish defaults for a sample information file in the Basic format.
1. To change to Basic format, go to Options > Option Presentation > Basic.
302-42828-01 - Dec 2012
Files, page 5-8.
Specifying Sample Defaults
Sample
Defining Sample
3-3
