Generating Graph Overlays
4. From the Report Options window, in the Selected Reports list box, select a sub-report and click
Edit.
5. Click the dropdown arrow on the Overlay field and select a second variable to overlay. Click OK
to return to the Report Options window.
6. Click OK again to return to the Report Options tab.
7. Click Save to save the selections.
Be advised when working with an existing file that a copy of the file be used rather
than the original. Modifying an existing file could possibly render it incompatible with
its original application.
3-42
TriStar II 3020
Select the report
variable
Click Edit
Displays the first
report variable
Select the second
variable from the
dropdown list
