4.3 Viewing Weather Related Data

FIGURE 4-23 Overall Tab: Weather Page
SoundAdvisor Model 831C
Observe weather readings on the Live Tab, Overall Tab: Weather Page as
shown in Figure 4-23, in the Event History Data, and in the Event Time
History Data. For more information on accessing weather-related data, see
the G4 LD Utility Manual from LarsonDavis.com.
1.
2.
For more information about weather accessories, view the SoundAdvisor
LEARN MORE
brochure at www.LarsonDavis.com. For more information on viewing weather-
related data in G4, see the G4 LD Utility Manual from LarsonDavis.com.
Viewing Weather Related Data
1.
"Windy" indicates the wind speed is 36.8% faster
than the Threshold level.
2.
Red polygon on the compass indicates the relative
duration and wind direction.
To view additional weather-related data, download and
open the data file in G4. Locate the Event History data
and look for the following columns:
• Wind Speed@ Lmax (mi/h)
• Wind Dir @ Lmax (compass direction)
• Gust Speed (mi/h)
• Gust Dir (Compass direction)
• Trig Src (Event Trigger Source)
• Trig Level (usually in dB)
In G4, weather-related events and their triggers display
in the following columns in the Event Time History data:
• Gust Speed (mi/h)
• Gust Dir (Compass direction)
4-14
