Larson Davis SoundAdvisor 831C Reference Manual page 139

Module 18
In this module:
18.1 Setting Up Markers for Sound Recording .........................................................................18-1
18.2 Making a Manual Sound Recording Using Mark Sound Type ..........................................18-2
18.3 Making an Automated Event Sound Recording ...............................................................18-3
18.3.1 About Sound Recording Constraints .................................................................18-4
18.4 Enabling Measurement History Sound Recording ...........................................................18-5
18.5 Understanding Recording Settings and Sound Quality ..................................................18-6
18.5.1 Understanding Resolution, Peak Overload, and Range ...................................18-6
18.5.2 Choosing a File Format for Sound Records .......................................................18-6
18.6 Sound Recording Playback ...............................................................................................18-7
18.6.1 Playback on the 831C .........................................................................................18-7
18.6.2 Playback After Saving in G4 ................................................................................18-8
18.1 Setting Up Markers for Sound Recording
SoundAdvisor Model 831C
Using 831C Sound Recording
S
ound recordings on the 831C are often used to identify the source of loud
noises during a measurement.
This feature is available when you purchase and install firmware option 831C-
SR. The upgrade allows you to trigger a recording and add a sound type label
to the resulting measurement data using 3 methods: by creating a manual
sound recording, by setting automated event-triggered recording, and by
using measurement history event recording. This section covers each method
and the related settings and options.
Markers help you label and initiate a recording of the sound being measured.
You can also use markers to simply mark the sound occurrence with a label
that's saved in the measurement's Time History.
Before you begin:
• Verify that 831C-SR firmware is installed and enabled on your meter.
For more information, see 14.4 Enabling or Disabling Optional
Firmware.
Step 1
On the meter, go to Tools Setup
Step 2
Highlight the setup file you want to enable for Sound
top-left softkey (
Step 3
Select the checkbox in-line with 1 or more sound types to enable sound
recording for that type.
FIGURE 18-1
Setting Up Markers for Sound Recording
Manager.
*//
) until you see the
Setup Manager Markers
Recording, then press the
Markers tab.
18-1
