Larson Davis SoundAdvisor 831C Reference Manual page 11

Table 1.2
Accessory Type
Microphone Preamplifier
Options
Environmental Protection
Weather Data Acquisition
Communication
GPS
Equivalent Electrical Impedance Adapter Options
Choose one of the following adapters in place of the microphone when making very high impedance
measurements. The adapter acts as a series capacitor with the same capacitance as the microphone it
replaces. If you're making a square wave pulse measurement, include a 100 kHz, low pass, T filter with the
adapter.
(ADP002) 6.8pF BNC Input
Adapter for ¼-inch, 7pF
microphone equivalent
SoundAdvisor Model 831C
(426E01) 1/2-inch ICP Low Noise
microphone preamplifier (requires
adapter (ADP074)
EPS Environmental Shell
Protects microphone and preamplifier from rain and wind with
mounting options for pipes, poles, and most tripods
EPS030-831
Weather-proof enclosure for remote noise monitoring; includes
battery
NMS/EPS044
Solar-powered noise monitoring system for outdoor, long-term,
and unattended sound monitoring
NMS/EPS045
Permanently-installed, solar-powered noise monitoring system
for outdoor, long-term, and unattended sound monitoring
SEN031: combined weather sensor, wind speed and direction
(with no moving parts), temperature, humidity, pressure, and
rainfall (requires CBL170 and DVX008A)
SEN032: Ultrasonic Anemometer: wind speed and direction only sensor
(requires CBL170 and DVX008A).
DVX012, 013, 014, 015, 008A
GPS001 GPS Receiver, USB Magnetic Mount
(ADP090) 12pF, BNC Input Adapter
for ½-inch, 12pF microphone
equivalent
Available Options and Accessories
Available Options
(PRM2103) Outdoor
microphone preamplifier
831-INT-ET with integrated
Ethernet capability
(ADP092) BNC In-Line, Low
Pass Filter, 75kHz
1-7
