4.1 Robot Arm
Joint names
Wrist 2 joint
Wrist 1 joint
Wrist 3 joint
Lower arm
Elbow joint
Tool Force/Torque sensor
Upper arm
Base joint
Base
Shoulder joint
Joint size UR3e
Joint size UR5e
Joint size UR10e and UR16e
Size 2
Size 2
Size 0
Size 1
Size 1
Size 3
Size 1
Size 3
Size 1
Size 3
Size 3
Size 4
Size 2
Size 2
Size 4
