Universal Robots E Series Service Manual page 71

NO. DESCRIPTION
1a AC external power terminal screws
1b DC external power terminal bolts
2a AC internal power terminal screws
2b DC internal power terminal screws
3 Control Board mounting screws
4 Bolt and nut for fan and energy eater
5 Power supply mounting screw
6 Panel screw and washer
All rights reserved
Tool size
PZ2
8mm
PZ2
PZ2
T10
Torx
10mm
T20
Torx
T20
Torx
71 Service Manual e-Series (EN) 1.1.8
Torque
1.2Nm
1.6Nm
1.2Nm
1.6Nm
0.6Nm
2.25Nm
1.0Nm
1.6Nm
