Manitowoc Grove GMK 4100L-1 Maintenance Manual page 338

Spare parts required for maintenance
11.3 Spare parts for the carrier
Assemblies and spare parts
Carrier
Wheels
Wheel nuts for steel rims
Wheel nuts for aluminium rims
Vehicle brake (for all 4 axle lines)
Wear contact set
Set of brake pads with a wear contact
set
Guide set and packing set
Packing set
Brake disc
Compressed air system
Valve (if defective)
Gasket 22 x 27 Cu DIN 7603
Filter cartridge
Hydraulic system
Filters 1 and 2 (only clean)
Packing set
Filters 1 and 2
Packing set
Filters 3 and 4
Packing set
Oil tank cover gasket 140 / 90 x 3
Ventilation filter
Air-conditioning system
Driver's cab pollen filter
Other maintenance work
Driver's cab wiper blades
11 - 6
GROVE-
part number
W
01207756
7659100000
03142924
03142923
only if wear is present
03142922
03142925
03142916
01570750 (7)
00117142 (7)
04157844
03329152
04163599
03329152
04163599
and when the symbol lights up
03140253
03135867
03328286
01576026
03254375
04159795 (2)
3 302 364 en
Quantity, in single parts
For maintenance interval
M 1 M 3
In case of damage;
12 each per wheel
on the disc brakes
(2)
(2)
at every oil change
1 item for every oil change
(if damaged)
(if damaged)
Maintenance manual
M 6 M 12
12
12
24
24
8
1
2
2
2
2
1
1
GMK 4100L-1
