Maintenance work on the carrier
7.20 Other maintenance work
7.20.5
Grease, tools
Checking
Lubricating
7 - 142

Lubricating the connecting and socket pins

Lubricating Designation
grease to DIN 51502
Grease KP - 1K - 50
– Brush.
Depending on the equipment, there are various connecting and socket pins
on the carrier such as:
– Fastenings to hold the hook block on the bumper while driving on the
road
– Clamps for ladders on the carrier
– Hinged warning panels under the bumper,
– Fastenings for the outrigger pads and socket pins on the outrigger,
– Locks on the removable covers,
– Hinges on the doors and covers of the storage box.
•
Check the pins for wear such as rust, deformation, broken clips, chains
and pin-type keepers.
•
If the pins are damaged, have them replaced by
or an authorised GROVE dealer or your qualified repair crew.
•
Use only authentic replacement pins.
•
Clean the pins.
•
Lubricate the pins with a brush.
Specification
classification
DIN 51825
3 302 364 en
M 12
GROVE part no.
03233369
Manitowoc Crane Care
Maintenance manual
GMK 4100L-1
