Spare parts required for maintenance

11.4 Spare parts for the superstructure

11.4
Assemblies and spare parts
Superstructure
Hoists
Sight glass with hoses; complete
Slewing gear
Gasket 10 x 14 Cu DIN 7603
Gasket 10 x 14 Cu DIN 7603
Gasket 14 x 20 Cu DIN 7603
Hydraulic system
Filter 1 (only clean it)
Packing set
Filter 1
Packing set
Filter 2
Housing packing set
Ventilation filter
Hoist ropes
Cover gasket
Cable drums
Cover gasket for cable drum 1
Cover gasket for cable drum 2
Air conditioning system
Pollen filter for crane cab
Other maintenance work
Windscreen wiper blade
Roof wiper blade
11 - 8
Spare parts for the superstructure
part number
GROVE-
W
84012690 (2)
00117125 (2)
00117125
00117132
04156358
04165792
04156358
04165792
and when the symbol lights up
03142356
03326049
03134932
02315305
for every rope change on the hoist
03138891
(if damaged)
03138894
04163620
03268512 (1)
03326121 (1)
3 302 364 en
Quantity, in single parts
For maintenance interval
M 1 M 3
(if damaged)
(if damaged)
(1)
(1)
at every oil change
1 (if damaged)
(if damaged)
Maintenance manual
M 6 M 12
(2)
2
2
1
1
1
1
1
(1)
(1)
1
GMK 4100L-1
