Manitowoc Grove GMK 4100L-1 Maintenance Manual page 334

Spare parts required for maintenance
11.2 Lighting
Installation point
CARRIER LIGHTING:
Front spotlights:
(integrated in the bumper)
– Daytime driving light (left)
– Daytime driving light (right)
– Low-beam + full-beam headlights
– Low-beam + full-beam headlights (USA)
– Indicator light
– Parking light (in the direction
indicator light)
– Yellow side marker light
Front, side indicator lights:
(under the access ladder to the driver's cab)
– Indicator light
Tail lights:
(at the rear of the chassis)
– Marker light
– Number plate light
– Rear light
– Brake light
– Indicator light
– Fog tail light
– Reverse light
Licence plate lamp, external:
(at the rear of the chassis)
– LED licence plate light
Yellow side marker lights:
(at the sides, along the chassis)
– Side marker light
White rear marker lights:
(at the rear of the chassis)
– Left marker light
– Right marker light
11 - 2
GROVE part
number
04163680
04136679
03134828
03143584
03327578
03140908
03320937
03327578
03137450
03137450
03137450
03328445
03327578
03328445
03328445
04163112
03140042
03327625
03327626
3 302 364 en
Designation Power (W)
LED
LED
H7 24V
H9 12V
PY21W 24V
LED
LED
PY21W 24V
R5W 24V
R5W 24V
R5W 24V
P21W 24V
8GA 006841241 24 V / 21 W
P21W 24V
P21W 24V
LED
LED
LED
LED
Maintenance manual
70
65
21
21
5
5
5
21
21
21
GMK 4100L-1
