Star-Hash (*#) Network Commands - Multi-Tech MultiModem EDGE Reference Manual

19.2 Star-Hash (*#) Network Commands

The following command strings can be sent to the network via ATD and have to be terminated with a semicolon.
The command strings are defined with GSM 2.30.
Table 19.1 Star-Hash (*#) Overview (Abbreviations used in this table on defined on the following page)
Star-Hash Code
Phone Security
*#06#
**04[2]*oldPin[2]*newPin[2]*new-
Pin[2]#
**05[2]*unblKey[2]*newPin[2]*new-
Pin[2]#
*#0003*MasterPhoneCode#
*[*]03*[ZZ]*oldPw*newPw*newPw#
Phone Number Presentation
*#30#
*#31#
*31#<Phonenumber>[;]
#31#<Phonenumber>[;]
*#76#
*#77#
Call Forwarding
(choice of *,#,*#,**,##)21*DN*BS#
(choice of *,#,*#,**,##)67*DN*BS#
(choice of *,#,*#,**,##)61*DN*BS*T#
(choice of *,#,*#,**,##)62*DN*BS#
(choice of
*,#,*#,**,##)002*DN*BS*T#
(choice of
*,#,*#,**,##)004*DN*BS*T#
Call Waiting
(choice of *,#,*#)43*BS#
Call Barring
(choice of *,#,*#)33*Pw*BS#
(choice of *,#,*#)331*Pw*BS#
(choice of *,#,*#)332*Pw*BS#
(choice of *,#,*#)35*Pw*BS#
(choice of *,#,*#)351*Pw*BS#
#330*Pw*BS#
#333*Pw*BS#
#353*Pw*BS#
Call Hold / Multiparty
C[C] in call
USSD Messages
[C]...[C]#
C[C] (excluded 1[C])
*) Notes on ^SCCFC, +CCWA, ^SCLCK: The output depends on the affected basic service of the Star-Hash code. One line will be
output for every tele- or bearer service coded in basic service code BS.
^SCCFC and ^SCLCK are modified by giving an additional <reason> or <fac> in front of the regular output string generated by the
standard commands +CCFC and +CLCK.
Multi-Tech Systems, Inc. AT Commands for EDGE Modems (S000371G)
Functionality
Query IMEI
Change SIM pwd
Change/Unblocking SIM pwd
Unlock "PS" lock with Master Phone
Code
Registration of net password
Check status of CLIP (Calling Line
Identification Presentation)
Check status of CLIR (Calling Line
Identification Restriction)
Suppress CLIR
Activate CLIR
Check status of COLP (Connected
Line Identification Presentation)
Check status of COLR (Connected
Line Identification Restriction)
Act/deact/int/reg/eras CFU
Act/deact/int/reg/eras CF busy
Act/deact/int/reg/eras CF no reply
Act/deact/int/reg/eras CF no reach
Act/deact/int/reg/eras CF all
Act/deact/int/reg/eras CF all cond.
Activation/deactivation/int WAIT
Act/deact/int BAOC
Act/deact/int BAOIC
Act/deact/int BAOIC exc.home
Act/deact/int. BAIC
Act/deact/int BAIC roaming
Deact. All Barring Services
Deact. All Outg.Barring Services
Deact. All Inc.Barring Services
Call hold and multiparty
Send USSD message
Send USSD message
Chapter 19 – Summary Tables
Response, also refer to Table 19.3
<IMEI> OK
+CME ERROR: <err> / OK
+CME ERROR: <err> / OK
+CME ERROR: <err> / OK
+CME ERROR: <err> / OK
+CLIP : <n>,<m> OK (see AT+CLIP)
+CLIR : <n>,<m> OK (see AT+CLIR)
(see AT+CLIR)
(see AT+CLIR)
+COLP : <n>,<m> OK (see
AT+COLP)
+COLR : 0,<m> OK (where <m> =
active or not active)
^SCCFC : <reason>, <status>,
<class> [,...] like +CCFC *) (see
AT+CCFC)
see above
see above
see above
see above
see above
+CCWA : <status>, <class> [,...] like
+CCWA *) (see: AT+CCWA)
^SCLCK : <fac>, <status>, <class>
[, ...] like +CLCK *) (See AT+CLCK)
see above
see above
see above
see above
see above
see above
see above
+CME ERROR: <err> / OK
+CME ERROR: <err> / OK
+CME ERROR: <err> / OK
264
