10.1.2 Example: GPRS Connection Profile

at^sics=0,conType,GPRS0
OK
AT^SICS=0,inactTO,"0"
OK
AT^SICS=0,dns1,"193.254.160.1"
OK
AT^SICS=0,authMode,"PAP"
OK
AT^SICS=0,passwd,t-d1
OK
AT^SICS=0,apn,"internet.t-d1.de"
OK

10.2 AT^SICI Internet Connection Information

New command

The AT^SICI read command requests the current status of the Internet connection profiles currently
Description:
defined with AT^SICS.
The AT^SICI write command displays the status of the specified Internet connection profile. If the
connection profile is not defined yet, the command returns a "+CME ERROR" response.
Test Command Syntax:
Response:
Read Command Syntax:
Response:
Write Command Syntax:
Response:
Parameter Description:
<conProfileId>
Internet connection profile identifier as defined by AT^SICS (<conProfileId>).
0...5
<conState>
State of the Internet connection profile.
0 Down - Internet connection is defined but not connected.
1 Connecting - A service has been opened and so the Internet connection is initiated.
2 Up - Internet connection is established and usable by one or more services.
3 Limited Up - Internet connection is established, but temporarily no network coverage.
This state applies only to GPRS profiles (it does not occur with CSD).
4 Closing - Internet connection is terminating.
<numServices>
Number of services using this Internet connection profile.
0...9
<conAddr>
Local IP address of the Internet connection profile (empty if no address is associated yet).
Note
Before opening a service profile based on a connection profile recently used, check with AT^SICI that the
previous connection was properly closed. If AT^SICI confirms that the connection profile is in <conState> 0
(Down) the connection profile may be used again.
Multi-Tech Systems, Inc. AT Commands for EDGE Modems (S000371G)
Select connection type GPRS0.
Inactivity timeout = 0 (default).
IP address of Primary DNS server.
Authentication protocol PAP (default).
GPRS services password provided by the German operator
T-D1.
APN to access the GPRS services provided by the German
operator T-D1.
AT^SICI=?
[^SICI: (list of defined <conProfileId>s)]
OK
AT^SICI?
[^SICI: <conProfileId>, <conState>, <numServices>, <conAddr>]
[^SICI: ...]
OK
AT^SICI=<conProfileId>
^SICI: <conProfileId>, <conState>, <numServices>, <conAddr>
OK
ERROR
+CME ERROR: <err>
