Make an FTP connection:
at^siso=1
OK
^SISR: 1, 1
at^sisr=1,1500
^SISR: 1, 50
hardware
in test
software
support
system test
OK
^SISR: 1, 2
at^sisc=1
OK

10.14.8 Configuring and Using FTP Upload (URC Mode)

First set up a connection profile as explained in Section 10.1.1 or Section 10.1.2. Enter at least all parameters that
are mandatory for the connection profile.
Configure the service profile 1 for FTP:
at^siss=1,srvType,ftp
OK
at^siss=1,conId,0
OK
at^siss=1,address,"ftpput://
myname:mypasswd@192.168.1.2/
upload/example.bin;type=i"
OK
Make an FTP connection:
at^siso=1
OK
^SISW: 1, 1
at^sisw=1,100
^SISW: 1, 100
0123456789012345678901234567890123456789012
3456789012345678901234567890123456789012345
67890123456789
OK
^SISW: 1, 1
at^sisc=1,0,1
OK
^SISW: 1, 2
at^sisc=1
Multi-Tech Systems, Inc. AT Commands for EDGE Modems (S000371G)
Chapter 10 – Internet Service Commands
Open the service.
Bearer is established, service is getting started.
Data are available.
Request to read 1500 bytes.
50 bytes are now available.
Data transfer finished. No more data available. The
connection to the FTP server is closed.
Close the service.
Select service type FTP.
Select connection profile 0.
Specify FTP address with individual user name and
password. The file "example.bin" shall be created on the
FTP server.
Open the service.
Bearer is established, service is getting started.
FTP service is ready for upload.
Client requests to send 100 bytes.
The write command response confirms: 100 bytes must be
transferred now.
User data are transferred.
URC indicates that the FTP service is ready to transfer more data.
Data of the last AT^SISW command are transferred to the remote
host.
No more data available. The file "example.bin" shall be closed on
the FTP server.
Data transfer finished. The connection to the FTP server is closed.
Close the FTP service.
