Configuring And Using Ftp Download (Urc Mode) - Multi-Tech MultiModem EDGE Reference Manual

Part 3 - host 1 opens the service and communicates with host 2:
AT^SISO=0
OK
^SISW: 0, 1
^SISR: 0, 1
AT^SISR=0, 100
OK
^SISR: 0, 23, 0, 10.10.0.22:6561
Hello, I'm the client!
OK
AT^SISW=0,1,0,1,"10.10.0.22:6561"
^SISW: 0, 1500, 0
Hi, I'm the UDP endpoint!
OK
^SISW: 0, 1
AT^SISC=0
OK
Part 4 - host 2 opens the service and communicates with host 1:
AT^SISO=0
OK
^SISW: 0, 1
AT^SISW=0,1,0,1
^SISW: 0, 1500, 0
"^SISR: 0, 1"
Hello, I'm the client!
OK
^SISW: 0, 1
^SISR: 0, 1
AT^SISR=0,100
OK
^SISR: 0, 26
Hi, I'm the UDP endpoint.
OK
AT^SISC=0
OK

10.14.7 Configuring and Using FTP Download (URC Mode)

First set up a connection profile as explained in Section 10.1.1 or Section 10.1.2. Enter at least all parameters that
are mandatory for the connection profile.
Configure the service profile 1 for FTP:
at^siss=1,srvType,ftp
OK
at^siss=1,conId,0
OK
at^siss=1,address,ftp://192.168.1.2;type=d
OK
Multi-Tech Systems, Inc. AT Commands for EDGE Modems (S000371G)
Chapter 10 – Internet Service Commands
Open the service.
The URC indicates that host 1 is waiting on UDP port 6666 and can send
data to any UDP client.
The URC indicates that host 2 has opened the connection to host 1 and has
sent some data.
Host 1 requests to read 100 bytes.
Host 1 is reading the text string received from host 2 and gets information
about the remote client, i.e. the address of host 2.
Host 1 starts sending a text string to host 2.
Host 1 is sending a text string to host 2. As a result, host 2 is receiving the
URC "^SISR: 0, 1" shown below in part 4 of the example.
The URC confirms that host 1 can send data again.
Close the service.
Open the service.
The URC indicates that the service is ready.
Host 2 has entered interactive text mode and starts to write.
Host 2 is writing a text string. As a result, host 1 is receiving the URC
shown above in part 3 of this example.
The URC confirms that there is no further data available.
The URC indicates that data has been received.
Host 1 requests to read 100 bytes.
The response indicates that host 2 has received 26 characters from host 1.
Close the service.
Select service type FTP.
Select connection profile 0.
Specify FTP address with user and password anonymous.
164
