At^sdld Delete The 'Last Number Redial' Memory - Multi-Tech MultiModem EDGE Reference Manual

<nlength>
Maximum length of phone number for "normal" locations. Depending on the storage, a limited number of
locations with extended memory is available per phonebook. These locations allow storing numbers with twice
the standard length, which is 2*<nlength> digits for normal numbers, but only <nlength> digits for numbers saved
with parameter <type>= 209. If all extended locations of the selected phonebook are used up, then any attempt
to write a number which requires extended memory will be denied with CME ERROR 260: INVALID DIAL
STRING.
<tlength>
Maximum length of <text> assigned to the telephone number. The value indicated by the test command is given
in octets. If the <text> string is given in GSM characters, each character corresponds to one octet. If the <text>
string is given in UCS2, the maximum number of characters depends on the coding scheme used for the alpha
field of the SIM. In the worst case the number of UCS2 characters is at least one less than half the number of
GSM characters.
Users should be aware that when using this AT command quickly after SIM PIN authentication the SIM
Note:
data may not yet be accessible, resulting in a short delay before the requested AT command response is
returned. See Section 20.1, Restricted access to SIM data after SIM PIN authentication for further detail.
Examples
Example 1
Make a new phonebook entry at the first free location (here location 3)
AT^SPBW=,"+431234567",145,"international"
^SPBW: 3
Example 2
Delete entry at location 3
AT^SPBW=3
Example 3
The following examples are provided to illustrate the effect of writing phonebook entries with different
types of dial string modifiers in <number>.
AT^SPBW=5,"12345678",,"Arthur"
^SPBW: 5
AT^SPBW=6,"432!+-765()&54*654#",,"John"
^SPBW: 6
AT^SPBW=7,"432!+-765()&54*654#",129,"Eve"
^SPBW: 7
AT^SPBW=8,"432!+-765()&54*654#",145,"Tom"
^SPBW: 8
AT^SPBW=9,"432!+-765()&54*654#",209,"Richard"
^SPBW: 9
Example 4
Read phonebook entries from locations 5 - 9 via AT+CPBR
+CPBR:5,"12345678",129,"Arthur"
+CPBR:6,"432!+-765()&54*654#",209,"John"
+CPBR:7,"432+76554*654#",129,"Eve"
+CPBR:8,"+432+76554*654#",145,"Tom"
+CPBR:9,"432!+-765()&54*654#",209,"Richard"

15.7 AT^SDLD Delete the 'Last Number Redial' Memory

Description:
Test Command Syntax:
Response:
Exec Command Syntax:
Response:
Users should be aware that when using this AT command quickly after SIM PIN authentication, the SIM data
Note:
may not yet be accessible, resulting in a short delay before the requested AT command response is returned.
See Section 20.1, Restricted Access to SIM Data after SIM PIN Authentication.
Multi-Tech Systems, Inc. AT Commands for EDGE Modems (S000371G)
AT^SDLD deletes all numbers stored in the "LD" memory.
AT^SDLD=?
OK
AT^SDLD
OK
ERROR
+CME ERROR: <err>
Chapter 15 – Phonebook Commands
234
