FusionModule5000 Smart Modular Data Center
V100R001C03
Commissioning Guide
Issue
06
Date
2020-03-20
HUAWEI TECHNOLOGIES CO., LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FusionModule5000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Huawei FusionModule5000

Summary of Contents for Huawei FusionModule5000

  • Page 1 FusionModule5000 Smart Modular Data Center V100R001C03 Commissioning Guide Issue Date 2020-03-20 HUAWEI TECHNOLOGIES CO., LTD.
  • Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...

  • Page 3: About This Document

    About This Document About This Document Purpose This document describes the FusionModule5000 Smart Modular Data Center (Smart Modular for short) in terms of the preparations, checklist, and precautions for power-on commissioning, power-on check, power-on commissioning of core components, and joint system commissioning.
  • Page 4 FusionModule5000 Smart Modular Data Center Commissioning Guide About This Document Symbol Description injury, equipment damage, and environment deterioration. Change History Changes between document issues are cumulative. The latest document issue contains all updates made in previous issues. Issue 06 (2020-03-20) Modified 6.1 Preparations and WebUI...

  • Page 5: Table Of Contents

    FusionModule5000 Smart Modular Data Center Commissioning Guide Contents Contents About This Document ........................ii 1 Safety Information ........................1 1.1 General Safety ................................1 1.2 Personnel Requirements ............................... 4 1.3 Electrical Safety ................................4 1.4 Installation Environment Requirements ........................6 1.5 Mechanical Safety ................................
  • Page 6 FusionModule5000 Smart Modular Data Center Commissioning Guide Contents 5.7 Startup ..................................42 5.8 Startup Wizard ................................46 5.9 (Optional) Power-off ..............................49 6 Commissioning the Management System ................51 6.1 Preparations and WebUI Login ........................... 51 6.2 Configuration Wizard ..............................55 6.3 Commissioning Alarm Notification ..........................
  • Page 7 FusionModule5000 Smart Modular Data Center Commissioning Guide Contents 7.1.1 How to Set and Add the Multi-functional Sensor ....................104 7.1.2 How to Set and Add the WLDS900 Water Sensor ....................106 7.1.3 How to Set and Add the Smoke Detector (Connected to the AI/DI Port on the Skylight Actuator) ...... 107 7.1.4 How to Set and Add the Temperature Sensor (Connected to the NTC Port on the Rack Environment Unit) ..

  • Page 8: Safety Information

    The "NOTICE", "CAUTION", "WARNING", and "DANGER" statements in this document do not cover all the safety instructions. They are only supplements to the safety instructions. Huawei will not be liable for any consequence caused by the violation of general safety requirements or design, production, and usage safety standards.
  • Page 9 FusionModule5000 Smart Modular Data Center Commissioning Guide 1 Safety Information  Before installing, operating, or maintaining the equipment, remove any conductive objects such as watches or metal jewelry like bracelets, bangles, and rings to avoid electric shock.  When installing, operating, or maintaining the equipment, wear dedicated protective gears such as insulation gloves, goggles, and safety clothing, helmet, and shoes, as shown in the following figure.
  • Page 10 FusionModule5000 Smart Modular Data Center Commissioning Guide 1 Safety Information  All cable holes should be sealed. Seal the used cable holes with firestop putty. Seal the unused cable holes with the caps delivered with the cabinet. The following figure shows the criteria for correct sealing with firestop putty.

  • Page 11: Personnel Requirements

    Do not power on the equipment before it is installed or confirmed by professionals. 1.2 Personnel Requirements  Personnel who plan to install or maintain Huawei equipment must receive thorough training, understand all necessary safety precautions, and be able to correctly perform all operations.
  • Page 12 FusionModule5000 Smart Modular Data Center Commissioning Guide 1 Safety Information Do not connect or disconnect power cables with power on. Transient contact between the core of the power cable and the conductor will generate electric arcs or sparks, which may cause fire or personal injury.

  • Page 13: Installation Environment Requirements

    FusionModule5000 Smart Modular Data Center Commissioning Guide 1 Safety Information  Wear ESD gloves or a well-grounded ESD wrist strap when touching the device or handling boards or application-specific integrated circuits (ASICs).  When holding a board, hold its edge without touching any components. Do not touch the components with your bare hands.

  • Page 14: Mechanical Safety

    FusionModule5000 Smart Modular Data Center Commissioning Guide 1 Safety Information Installation at Heights  Working at heights refers to operations that are performed at least 2 meters above the ground.  Do not work at heights if the steel pipes are wet or other potential danger exists. After the preceding conditions no longer exist, the safety director and relevant technical personnel need to check the involved equipment.
  • Page 15 FusionModule5000 Smart Modular Data Center Commissioning Guide 1 Safety Information  Do not drag steel ropes and hoisting tools or bump hoisted objects against hard objects during hoisting. Using Ladders  Use wooden or fiberglass ladders when you need to perform live working at heights.
  • Page 16 Metal shavings from drilling may short-circuit boards inside the equipment.  Obtain the consent from the customer, subcontractor, and Huawei before drilling.  Wear goggles and protective gloves when drilling holes. ...

  • Page 17: Cooling System Safety

    FusionModule5000 Smart Modular Data Center Commissioning Guide 1 Safety Information 1.6 Cooling System Safety Welding  At least two persons are required on a welding site.  A welder must have a work permit.  A welding site must be free from inflammables.

  • Page 18: Battery Safety

    The site must be equipped with qualified fire extinguishing facilities, such as firefighting sands and powder fire extinguishers. To ensure battery safety and battery management accuracy, use batteries provided with the UPS by Huawei. Huawei is not responsible for any battery faults caused by batteries not provided by Huawei. Battery Installation Before installing batteries, observe the following safety precautions: ...
  • Page 19 FusionModule5000 Smart Modular Data Center Commissioning Guide 1 Safety Information  Note the polarities when installing batteries. Do not short-circuit the positive and negative poles of the same battery or battery string. Otherwise, the battery may be short-circuited.  Check battery connections periodically, ensuring that all bolts are securely tightened.

  • Page 20: Others

    FusionModule5000 Smart Modular Data Center Commissioning Guide 1 Safety Information Lithium Battery The safety precautions for lithium batteries are similar to those for lead-acid batteries except that you also need to note the precautions described in this section. There is a risk of explosion if a battery is replaced with an incorrect model.

  • Page 21: Precautions For Power-On Commissioning

    FusionModule5000 Smart Modular Data Center Commissioning Guide 2 Precautions for Power-On Commissioning Precautions for Power-On Commissioning  Conduct power-on commissioning only after the hardware is installed and the installation is verified. Do not perform construction after power-on.  Before power-on commissioning, complete the commissioning of the customer's power supply and distribution devices.

  • Page 22: Preparations For Power-On Commissioning

    FusionModule5000 Smart Modular Data Center Commissioning Guide 3 Preparations for Power-On Commissioning Preparations for Power-On Commissioning 3.1 Personnel Skill Requirements Table 3-1 Personnel Skill Requirements Personnel Skill Requirements Supervisor Must be familiar with the configurations of the power supply and...
  • Page 23 FusionModule5000 Smart Modular Data Center Commissioning Guide 3 Preparations for Power-On Commissioning Tools Multimeter Electroprobe Network cable tester Cable tie PVC insulation tape Marker Electrostatic discharge Step ladder ESD wrist strap (ESD) gloves Clamp meter Point thermometer Adjustable wrench RJ45 crimping tool...

  • Page 24: System Networking

    FusionModule5000 Smart Modular Data Center Commissioning Guide 3 Preparations for Power-On Commissioning Tools 3.3 System Networking Figure 3-1 System network diagram If four or more cameras are deployed in a single smart module or multiple smart modules share one VCN, connect the signal cable from each camera and VCN to the LAN switch.

  • Page 25: Power-On Commissioning Process

    FusionModule5000 Smart Modular Data Center Commissioning Guide 3 Preparations for Power-On Commissioning 3.4 Power-On Commissioning Process Figure 3-2 Power-on commissioning process 3.5 Check Before Power-On 3.5.1 Checking Before Powering On the Integrated Cabling System Table 3-3 Checking before powering on the integrated cabling system...

  • Page 26: Checking Before Powering On The Power Supply And Distribution System

    FusionModule5000 Smart Modular Data Center Commissioning Guide 3 Preparations for Power-On Commissioning Check Item Operation Expected Result environment and other sundries inside copper wires and screws) on the top and outside each cabinet. of each cabinet.  There is no foreign matter at the copper bar terminals.
  • Page 27 FusionModule5000 Smart Modular Data Center Commissioning Guide 3 Preparations for Power-On Commissioning Check Item Operation Expected Result connections signal cables. requirements.  Check the communications cable connection to the ECC800. Smart cooling Check the pipe connections to The pipes are properly installed,...

  • Page 28: Commissioning The Power Supply And Distribution System

    FusionModule5000 Smart Modular Data Center 4 Commissioning the Power Supply and Distribution Commissioning Guide System Commissioning the Power Supply and Distribution System 4.1 (Optional) Commissioning the PDB Procedure Step 1 Power on the PDB. Switch on the SPD circuit breaker in the PDB.
  • Page 29 After the first login, change the password in time to ensure account security and prevent unauthorized network attacks, such as data tampering. Huawei will not be liable for any security issues caused by your failure to change the preset password in time or password loss after changing.

  • Page 30: Powering On The Smart Busway

    FusionModule5000 Smart Modular Data Center 4 Commissioning the Power Supply and Distribution Commissioning Guide System Table 4-3 Setting wizard 2 Item Parameter Setting Network Param. IP address assign DHCP Automatic System Param. Rated frequency Set as required Rated line voltage Set as required Check whether there is any alarm on the monitoring screen.
  • Page 31 FusionModule5000 Smart Modular Data Center 4 Commissioning the Power Supply and Distribution Commissioning Guide System Check that the voltage and frequency are in normal operating ranges.  Measure the upstream input line voltage using a multimeter. The line voltage is in the range of 342–456 V.

  • Page 32: Commissioning The Cooling System

    FusionModule5000 Smart Modular Data Center Commissioning Guide 5 Commissioning the Cooling System Commissioning the Cooling System 5.1 Power-On Procedure Step 1 Turn on the smart cooling product switch in the power distribution cabinet and the AC1 and AC2 switches on the smart cooling product.
  • Page 33 To prevent the effect of misoperation on the system during the O&M, log in as the operator user first before modifying parameters. Confirm with Huawei before modifying parameters that cannot be modified by operator users; otherwise, Huawei will not be liable for any consequences of the unauthorized modification.
  • Page 34 FusionModule5000 Smart Modular Data Center Commissioning Guide 5 Commissioning the Cooling System Menu Parameter Description Configuration Principle Select Choose language Set the parameter Language of the ACC according to the actual situation. Date & Time Date format Specifies the date...
  • Page 35 FusionModule5000 Smart Modular Data Center Commissioning Guide 5 Commissioning the Cooling System Menu Parameter Description Configuration Principle the actual control over an FE port. networking mode. Otherwise, the teamwork control function will be unavailable. Number of smart Number of the...
  • Page 36 FusionModule5000 Smart Modular Data Center Commissioning Guide 5 Commissioning the Cooling System Menu Parameter Description Configuration Principle that the dehumidification function will be enabled when the main power is active and the ambient humidity exceeds the certain humidity range of the humidity set point.
  • Page 37 FusionModule5000 Smart Modular Data Center Commissioning Guide 5 Commissioning the Cooling System Menu Parameter Description Configuration Principle value collected by the collector. Temperature setpoint After the Set this parameter as Temperature and required. humidity control  Return air type and the temperature: 26–35°...

  • Page 38: Setting Communications Parameters (Ip Address Settings)

    FusionModule5000 Smart Modular Data Center Commissioning Guide 5 Commissioning the Cooling System Menu Parameter Description Configuration Principle communicates with the smart cooling product through this address. ----End 5.2 Setting Communications Parameters (IP Address Settings) Prerequisites You have logged in to the system as admin.
  • Page 39 FusionModule5000 Smart Modular Data Center Commissioning Guide 5 Commissioning the Cooling System Figure 5-3 Setting temperature and humidity values Step 2 Set Cold aisle sensor 1 to Enable. Step 3 Set the temperature and humidity values by referring to Table 5-3.
  • Page 40 FusionModule5000 Smart Modular Data Center Commissioning Guide 5 Commissioning the Cooling System Parameter Description Configuration Principle the temperature is to be controlled based on the minimum data value collected by the collector. Control point After the Temperature and humidity Set this parameter as required.

  • Page 41: Optional) Setting The Pressure Difference Control

    FusionModule5000 Smart Modular Data Center Commissioning Guide 5 Commissioning the Cooling System Figure 5-4 Cold aisle temperature and humidity ----End 5.4 (Optional) Setting the Pressure Difference Control Prerequisites If the differential pressure sensor is installed, perform the following operations accordingly. If the differential pressure sensor is not installed, skip this part.

  • Page 42: Setting Teamwork Control Parameters

    FusionModule5000 Smart Modular Data Center Commissioning Guide 5 Commissioning the Cooling System Parameter Description Configuration Principle differential pressure sensors are configured, change to Pressure diff ctrl. Indoor fan pressure Sets the value for the The default value is 10 Pa.
  • Page 43 FusionModule5000 Smart Modular Data Center Commissioning Guide 5 Commissioning the Cooling System Figure 5-5 Teamwork settings Step 2 Set teamwork control parameters. All teamwork control parameters can be set on the master smart cooling product. Only Teamwork group No., Air conditioner address, Enable teamwork CAN resistor, Teamwork function and Networking mode can be set on slave smart cooling products.
  • Page 44 FusionModule5000 Smart Modular Data Center Commissioning Guide 5 Commissioning the Cooling System Parameter Description Configuration Default Principle Value disabled, this device is distribution. operating according to its own control. If the teamwork function is enabled, this device works in harmony with others that in the same group.
  • Page 45 FusionModule5000 Smart Modular Data Center Commissioning Guide 5 Commissioning the Cooling System Parameter Description Configuration Default Principle Value period Rotation time 24 hours in a day (0–23). 0 by default Forced rotation Forced rotation This item is set to No by specifies whether to default.
  • Page 46 FusionModule5000 Smart Modular Data Center Commissioning Guide 5 Commissioning the Cooling System Parameter Description Configuration Default Principle Value Cascade After the requirement If the heat load to the Disable function control is enabled, you device increases, the can configure Cascade cascade function is function.
  • Page 47 FusionModule5000 Smart Modular Data Center Commissioning Guide 5 Commissioning the Cooling System Parameters Note Standby: responds to the requirement control when active one is faulty (critical alarms, shutdown, and offline) or cannot meet cooling requirements. M indicates the master unit, and S indicates a slave unit. Blue indicates that the device is operating, and gray indicates that the device is idle.

  • Page 48: Optional) Setting Wifi Parameters

    FusionModule5000 Smart Modular Data Center Commissioning Guide 5 Commissioning the Cooling System If no, check the cable connection and the settings of teamwork control parameters. − Check whether the number of active devices on the topology is the same as the actual device number.

  • Page 49: Startup

    Commissioning Guide 5 Commissioning the Cooling System 5.7 Startup Download the Service Expert app from Huawei app store and runs on Android. Apply for permission after downloading the app. Step 1 Tap Start on the home screen of the ACC.
  • Page 50 Service Expert app for initial startup verification. The Service Expert app can be downloaded from Huawei app store and runs on Android. User interfaces displayed in this document correspond to the APP software version V100R001C00B043T007 and are for reference only.
  • Page 51 FusionModule5000 Smart Modular Data Center Commissioning Guide 5 Commissioning the Cooling System Figure 5-10 Offline boot Step 3 Tap Offline Activation and the screen shown in Figure 5-11 is displayed. Figure 5-11 Generating a startup password If the software version is after V200R002C00SPC050, an icon will generate in the right of BarCode.
  • Page 52 FusionModule5000 Smart Modular Data Center Commissioning Guide 5 Commissioning the Cooling System Step 5 Tap Password on the home screen of the ACC and enter the generated startup password in the displayed dialog box. ----End Online Boot Step 1 Insert the WiFi module to the USB port on the ACC.

  • Page 53: Startup Wizard

    FusionModule5000 Smart Modular Data Center Commissioning Guide 5 Commissioning the Cooling System Parameter Setting Method IP, Port, and Enter the values as planned. For details, see values on the Modbus devAddr settings screen. Step 6 Tap Login after the parameters are set.
  • Page 54 FusionModule5000 Smart Modular Data Center Commissioning Guide 5 Commissioning the Cooling System Tapping No or Exit, submission timeout, and system exception all result in commissioning failures. Choose Maint > Wizard Startup to enter the Wizard Startup screen for new commissioning.
  • Page 55 FusionModule5000 Smart Modular Data Center Commissioning Guide 5 Commissioning the Cooling System Figure 5-16 Selecting commissioning items  If the system is not configured with the humidifier components, the humidifier commissioning items will not appear on the screen.  If the humidification function are disabled, you cannot select the humidifier item.

  • Page 56: Optional) Power-Off

    FusionModule5000 Smart Modular Data Center Commissioning Guide 5 Commissioning the Cooling System Figure 5-18 Commissioning successfully  Figure 5-19 is displayed if component commissioning fails, which ends startup wizard commissioning. Figure 5-19 Commissioning unsuccessfully If commissioning fails, tap Commissioning failed. in Figure 5-19 to view the details.
  • Page 57 FusionModule5000 Smart Modular Data Center Commissioning Guide 5 Commissioning the Cooling System Figure 5-20 Shutdown Step 2 Tap Confirm. If the device is successfully shut, the system displays a message, indicating that the command is successfully triggered. Step 3 Turn off the power switch (AC1, AC2).

  • Page 58: Commissioning The Management System

    FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Commissioning the Management System 6.1 Preparations and WebUI Login Prerequisites  The operating system of Windows 7 or later is supported.  It is recommended that the screen resolution be 1366 x 768 or higher.
  • Page 59 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System If the port IP address is 192.168.1.10, subnet mask is 255.255.255.0, and default gateway is 192.168.1.1, set the PC IP address to 192.168.1.11, subnet mask to 255.255.255.0, and default gateway to 192.168.1.1.
  • Page 60 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Figure 6-1 Setting internet options Step 4 Set Internet Explorer parameters. When you use Internet Explorer for access, set Internet Explorer to ensure the normal display of and operations on the WebUI. Choose Tools > Compatibility View, and add the web access address to the compatibility view.
  • Page 61 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Figure 6-2 Adding an address Enable file download and set the security level of the trusted site to low. Figure 6-3 Setting parameters When switching between different versions of the ECC800 on your PC, you are advised to clear the historical Internet Explorer cache.

  • Page 62: Configuration Wizard

    After the first login, change the password in time to ensure account security and prevent unauthorized network attacks, such as data tampering. Huawei will not be liable for any security issues caused by your failure to change the preset password in time or password loss after changing.

  • Page 63: Commissioning Alarm Notification

    FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Procedure Step 1 Log in to the ECC800 WebUI as an administrator. The deployment wizard is displayed when you log in to the ECC800 WebUI for the first time or the system type is switched.
  • Page 64 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Figure 6-5 Setting the Outbox Setting parameter  Click Test to test whether the email is sent successfully. If the email fails to be sent, check the sender's email parameter settings; if the email is sent successfully, click Submit.
  • Page 65 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Step 3 Click Add in the Email Receiving Settings area and enter the receiver's email address. Step 4 Click Confirm to access the re-authentication page. Enter Login password and click Submit.
  • Page 66 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Figure 6-7 Setting the Alarm notification delay time parameter Figure 6-8 Adding alarm notification Mailbox Address in Alarm Notification can be selected after it is added in Mailbox Settings.

  • Page 67: Commissioning The Smart Busway

    FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System ----End Follow-up Procedure To modify or delete the email parameter settings, click Modify or Delete. 6.4 Commissioning the Smart Busway Context If the smart busway is used, general input units and power distribution units communicate with the ECC800 using the Modbus-MAC protocol.
  • Page 68 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Path Parameter Default Setting Name Value System CT ratio to 250.  If Rated system current is 160 A, set System CT ratio to 200. Set the parameters for other general input units in the same way or by synchronizing parameters.

  • Page 69: Commissioning The Ac Actuator (Wireless Networking)

    FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System 6.5 Commissioning the AC Actuator (Wireless Networking) If an AC actuator with wireless networking is configured, perform the following steps to set its parameters. Prerequisites The upstream power input circuit breaker of the AC actuator is turned on.

  • Page 70: Feature Commissioning

    FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Path Operation Parameters Set Route 2 Control Mode to PAD Charging, and click Submit. NOTE If two AC actuators are configured, you only need to set the Route 2 Control Mode for one AC actuator.
  • Page 71 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Context  The ECC800 can generate an alarm using the multi-functional sensor or smoke sensor in the aisle. This alarm, however, cannot be used to trigger the customer's fire extinguishing system.
  • Page 72 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Procedure Step 1 Install cables between the fire controller and ECC800. Figure 6-9 Installing cables between the fire controller and ECC800 Step 2 Log in to the ECC800 WebUI as an administrator.
  • Page 73 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Figure 6-11 Modifying a signal name Step 5 Enable the AI/DI device. Choose Monitoring > System > ECC800 > Running Parameters > AI/DI_6 Port Settings. Select Fire sensor to Enable, and click Submit, then enter the AI/DI_6 port settings page.

  • Page 74: Pue Configuration

    FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System  Set Set light mode of the AC actuator to Automatic. WebUI path: Monitoring > Aisle > AC Actuator Group > AC Actuator. 6.6.2 PUE Configuration The PUE configuration mode can be set to Standard and User-defined on the ECC800 WebUI.
  • Page 75 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Step 4 Set the PUE configuration mode to Standard, and click Submit. Step 5 View the PUE. Choose Query > Performance Data and set Device to ECC800 from the drop-down list box.

  • Page 76: Configuring Pue User-Defined Mode

    FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System 6.6.2.2 Configuring PUE User-defined Mode Context This section describes how to configure PUE for the integrated PDC connected. The functions of configuration buttons for the PUE user-defined mode are described as follows.

  • Page 77: Viewing Pue Data

    FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Figure 6-15 IT cabinet power consumption configuration Under Total Power Consumption Configuration and IT Cabinet Power Consumption Configuration, click the edit icon on the right to modify the multiple for...
  • Page 78 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Step 2 Choose Home > Plan View to view real-time PUE data. Figure 6-17 Viewing real-time PUE data Step 3 Choose Query > Performance Data to view historical PUE data.

  • Page 79: Commissioning The Access Control System

    FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System 6.6.3 Commissioning the Access Control System 6.6.3.1 Commissioning a Door Status Sensor (Connected to the AI/DI Port on the Rack Environment Unit) If a door status sensor is installed, perform the following steps to configure it.
  • Page 80 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Prerequisites  A maximum of eight access actuators are supported.  When the fingerprint reader is connected to the ECC800 for the first time, the permissions need to be synchronized.
  • Page 81 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Figure 6-19 Adding access users On the Authorization Information and Term of Authorization tab pages, select access users whose access permissions are to be set, and set Authorized Device, Authorization Mode, Cabinet Lock, Start time, and End time.
  • Page 82 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Figure 6-20 Adding access permissions You can authorize and delete access users in batches. Click OK to complete the task of adding access management settings. On the Authorization Operations tab page, click Synchronize to Device, select the modified access control devices, and click Start Synchronization.
  • Page 83 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System  If the access control system uses a Card and password reader, choose Monitoring > Aisle > Access Actuator Group > Access Actuator n on the ECC800 WebUI, click Running Parameters, and set Logical level configuration for reader removed of the corresponding card reader to High level alarm.

  • Page 84: Commissioning The Exit Button, Skylight Button, Atmosphere Light, Emergency Button, And Magnetic Lock

    FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Check Method Normal Connection Status of this access control event. ----End 6.6.3.3 Commissioning the Exit Button, Skylight Button, Atmosphere Light, Emergency Button, and Magnetic Lock Procedure Step 1 Check functions of the exit button.

  • Page 85: Neteco Management

    FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Check Method Normal Connection Follow-up Procedure Status when the aisle door is closed. Step 5 Check functions of the magnetic lock. Table 6-20 Function commissioning Check Method Normal Connection...
  • Page 86 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Procedure Step 1 Apply for a fixed IP address to the equipment room network administrator. Step 2 Set the IP address, subnet mask, and default gateway on the ECC800 WebUI.

  • Page 87: Creating An Ecc800 On The Neteco

    FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Path Parameter Default Setting Value include at least three of the Password following types: lowercase letters, uppercase letters, digits, and special characters) Confirm authentication password Step 5 Click Submit.

  • Page 88: Video Management

    FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Figure 6-23 Adding an ECC800 device to the modular  Click OK, and you can view the task information, including Type, Device Name, Region, Progress, Status, Start Time, End Time, and Information in the displayed Progress window.

  • Page 89: Commissioning A Camera (Smart Eth Gateway Networking Scenario)

    FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System  To ensure the normal operating of the ECC800, avoid high data traffic, such as the concurrent display of dynamic monitoring of cameras and VCN500 video playback. ...
  • Page 90 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System the IPC6325 camera automatically obtains an IP address that is in the same network segment as the ECC800 IP address.  Before commissioning the IPC6325 camera, set the IP address for the IPC6325 camera based on customer requirements.
  • Page 91 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Add the camera that has been found to Video Information. Click Add under the Video Information list, and enter the camera information in the displayed New Video Information window.
  • Page 92 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Step 5 For details about how to commission IP cameras and set parameters for them, see the documentation delivered with the equipment or obtain the documentation by referring to the "Preparing Documentation"...

  • Page 93: Commissioning Ipc6325 Camera (Sd Card Configured)

    If the VCN is not configured and an SD card is chosen, perform the following procedure. Procedure Step 1 Log in to the Huawei IPC WebUI. Step 2 Format the SD card. Choose Settings > System Configuration > Storage Management.
  • Page 94 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Figure 6-30 Setting audio and video parameters If longer-time video storage is required, set camera parameters according to the following table. Table 6-25 Camera configuration parameters Condition Result...

  • Page 95: Commissioning A Camera (Lan Switch Networking Scenario)

    FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System ----End 6.6.5.3 Commissioning a Camera (LAN Switch Networking Scenario) If the camera web version is IPC V200R003C00, refer to this topic to commission the camera. 6.6.5.3.1 Commissioning IPC6325 Cameras...
  • Page 96 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Figure 6-31 Setting primary stream parameters Figure 6-32 Setting secondary stream 1 parameters Issue 06 (2020-03-20) Copyright © Huawei Technologies Co., Ltd.

  • Page 97: Commissioning Ipc6325 Camera (Sd Card Configured)

    FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System ----End Follow-up Procedure Commission the other cameras by referring to this section. 6.6.5.3.2 Commissioning IPC6325 Camera (SD Card Configured) Context If the VCN is not configured and an SD card is chosen, perform the following procedure.
  • Page 98 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Figure 6-34 Setting audio and video parameters If longer-time video storage is required, set camera parameters according to the following table. Table 6-26 Camera configuration parameters Condition Result...

  • Page 99: Setting Parameters On The Vcn Webui

    FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Condition Result Coding Resolution Frame rate I-frame Minimum Supported protocol interval required bit video storage rate duration (h) H.264 1080P H.265 720P 0.8M H.264 720P H.265 720P 0.6M H.264...
  • Page 100 After the first login, change the password in time to ensure account security and prevent unauthorized network attacks, such as data tampering. Huawei will not be liable for any security issues caused by your failure to change the preset password in time or password loss after changing.

  • Page 101: Setting Parameters On The Vcn Ivs Client

    OMU Portal system.  (Optional) Deploying IVS in Stack Mode. For details, log in to the https://e.huawei.com/, search for the VCN product documentation, open the documentation, and see the section (Optional) Deploying IVS in Stack Mode.  (Optional) Deploying MPUs in Cluster Mode. For details, log in to the https://e.huawei.com/, search for the VCN product documentation, open the...
  • Page 102 After the first login, change the password in time to ensure account security and prevent unauthorized network attacks, such as data tampering. Huawei will not be liable for any security issues caused by your failure to change the preset password in time or password loss after changing.
  • Page 103 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Item Value access Mount Server Select the server that cameras need to access There are multiple VCNs for multiple smart modules, you are advised to evenly distribute the cameras to each VCN.

  • Page 104: Power Management

    FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Figure 6-38 Creating a user Set Multi-point logins to a value greater than 2. In the Assign Device View Rights area, select the cameras to be browsed and queried by the user.
  • Page 105 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System  2N non-isolation scenario: The system has only one power distribution cabinet and is working in dual-power supply mode.  2N isolation scenario: The system has two power distribution cabinets and is working in single-power supply mode.
  • Page 106 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Parameter Setting Description 2QF10(L1), the branches for subsequent cabinets are 1QF9(L3), 2QF9(L3), and the like. Figure 6-39 Power configuration Issue 06 (2020-03-20) Copyright © Huawei Technologies Co., Ltd.

  • Page 107: Querying Power Parameters

    FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System  If Apply to all cabinets is selected, all other cabinets use this configuration.  If Clear the power distribution configuration of all cabinets is selected, the power distribution configuration of all cabinets will be cleared.

  • Page 108: Cooling Capacity Management

    FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Figure 6-41 Viewing IT power information Step 4 Choose Home > Plan View. In the PUE area, you can view the transient mPUE.  Transient mPUE = Total input power/Total IT power of the smart module. For example, if a PDU8000 with the total input power of 5 kW connects to the smart module, whose total IT power is 3.6 kW, the transient mPUE = 5 kW/3.6 kW = 1.39.

  • Page 109: Querying Cooling Capacity Parameters

    FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Figure 6-42 Setting running parameters Step 4 Choose Monitoring > Cooling > Running Parameters. In the Cooling Capacity Management area, set the parameters related to cooling capacity management for the watercooled smart cooling product, such as the target cooling load factor and recommended supplywater temperature statistics cycle.
  • Page 110 FusionModule5000 Smart Modular Data Center Commissioning Guide 6 Commissioning the Management System Figure 6-44 Cooling capacity parameters Step 4 Choose Monitoring > System. Click Cooling Capacity Information on the Running Info tab page to query the cooling capacity parameters of the smart module.

  • Page 111: Faq

    FusionModule5000 Smart Modular Data Center Commissioning Guide 7 FAQ 7.1 WebUI Operations 7.1.1 How to Set and Add the Multi-functional Sensor If a multi-functional sensor is installed, perform the following steps to configure it. Prerequisites One end of the straight-through cable has been connected to the POE port on the multi-functional sensor, and the other end has been connected to the POE port on the ETH converter.
  • Page 112 FusionModule5000 Smart Modular Data Center Commissioning Guide 7 FAQ Check Method Normal Connection Status Smoke generation methods: ALM indicator turns on, and the app or WebUI Generate smoke. Place the paper displays a smoke alarm. 5–10 cm away from the smoke ...

  • Page 113: How To Set And Add The Wlds900 Water Sensor

    FusionModule5000 Smart Modular Data Center Commissioning Guide 7 FAQ Figure 7-1 Detecting smoke (1) Smoke compartment (2) ALM indicator ----End 7.1.2 How to Set and Add the WLDS900 Water Sensor If a water sensor is installed, perform the following steps to configure it.

  • Page 114: How To Set And Add The Smoke Detector (Connected To The Ai/Di Port On The Skylight Actuator)

    FusionModule5000 Smart Modular Data Center Commissioning Guide 7 FAQ  In this example, the water sensor is connected to the AI/DI_1 port on the ECC800.  The default alarm severity of the AI/DI port is Minor. If you want to change the alarm severity, see How Should I Configure Alarm Parameters.

  • Page 115: How To Set And Add The Temperature Sensor (Connected To The Ntc Port On The Rack Environment Unit)

    FusionModule5000 Smart Modular Data Center Commissioning Guide 7 FAQ Wire of the Network Cable Smoke Detector Cable Core wire 3 (green-white) +12 V (red) Core wire 6 (green) Normally closed end (yellow) Core wire 7 (brown-white) Common end (green) None (reserved; no connection needed and...

  • Page 116: How To Set And Add The T/H Sensor (Bom Number: 33010346)

    FusionModule5000 Smart Modular Data Center Commissioning Guide 7 FAQ Prerequisites One end of the straight-through cable has been connected to the RJ45 port on the temperature sensor, and the other end has been connected to the NTC port on the rack environment unit.

  • Page 117: How To Set And Add The T/H Sensor (Bom Number: 02310Nbs)

    FusionModule5000 Smart Modular Data Center Commissioning Guide 7 FAQ Path Parameter Setting Name and click Add Connect To Select ECC800 from the drop-down list box. Device. The parameters for Communicatio Select COM3 from the drop-down list box. adding devices ns Port NOTE are displayed.
  • Page 118 FusionModule5000 Smart Modular Data Center Commissioning Guide 7 FAQ Prerequisites One end of the straight-through cable has been connected to the RS485_IN port on the T/H sensor, and the other end has been connected to the COM port on the ECC800.

  • Page 119: How To Manage Webui Users

    FusionModule5000 Smart Modular Data Center Commissioning Guide 7 FAQ Click Test Connect to check whether the T/H sensor connects to the ECC800 properly. − If the T/H sensor connects to the ECC800 properly, click Confirm. The connected devices are displayed in the Number of connected devices list.

  • Page 120: Creating A Smart Module Plan View

    FusionModule5000 Smart Modular Data Center Commissioning Guide 7 FAQ Choose the user to be modified and click Modify. Reset the login password on the displayed page. Figure 7-2 Changing the login password Step 2 Add a WebUI user. Choose Maintenance > User Management. The user management page is displayed.
  • Page 121 FusionModule5000 Smart Modular Data Center Commissioning Guide 7 FAQ Procedure Step 1 Choose Home > Plan View and click Create smart module in Smart Module View. The Modify Basic Config dialog box is displayed. Set the layout and device quantity in Layout and Half-size cabinet qty./row based on the actual smart module scenario.

  • Page 122: How Can I Change The Ecc800 Ip Address On The Webui

    FusionModule5000 Smart Modular Data Center Commissioning Guide 7 FAQ Figure 7-4 Example plan view without room monitoring Figure 7-5 Example plan view with room monitoring ----End Follow-up Procedure To modify the smart module plan view, perform the following steps: Choose Home > Plan View.

  • Page 123: How Do I Configure Ecc800 Alarm Parameters

    FusionModule5000 Smart Modular Data Center Commissioning Guide 7 FAQ Procedure Step 1 Log in to the ECC800 WebUI as an administrator. Step 2 Choose System Settings > System Parameters > Monitor IP and change the IP, subnet mask, and default gateway information for the ECC800 as planned.

  • Page 124: How Is A Signal Name Changed

    FusionModule5000 Smart Modular Data Center Commissioning Guide 7 FAQ Step 7 Click Select in the Output Dry Contact column corresponding to Operation log full as required, select Yes or No for DO1 or DO2, and click OK. Select a DO not used by other functions. Otherwise, the association setting fails.

  • Page 125: How Should I Link The Ai/Di Alarm With The Alarm Beacon Over The Ecc800 Webui

    FusionModule5000 Smart Modular Data Center Commissioning Guide 7 FAQ Procedure Step 1 Choose System Settings > Alarm Parameter > Alarm Linkage. Step 2 Select Multi-Func Sensor for Device Type, select Device Type or Device for Linkage type, and click Confirm.

  • Page 126: How Can I Rectify Camera Access Restriction

    7 FAQ 7.1.14 How Can I Rectify Camera Access Restriction Prerequisites If Huawei S12700 series switch is used, refer to this section to rectify the fault. For more information, consult network engineers. Context The camera is inaccessible after the MAC address and IP address are bound in network configuration.
  • Page 127 FusionModule5000 Smart Modular Data Center Commissioning Guide 7 FAQ Figure 7-6 Installing a WiFi module  Method 2: Connect cables between the WiFi converter and a smart ETH gateway as well as between the smart ETH gateway and the ECC800.

  • Page 128: How To Prepare And Login App

    FusionModule5000 Smart Modular Data Center Commissioning Guide 7 FAQ Figure 7-7 Installing a WiFi converter The WiFi antenna should be installed on the planned position by using the magnet. ----End 7.2.2 How to Prepare and Login App Prerequisites App operating environment requirements: ...
  • Page 129 Install the HUAWEI App Store. If the downloaded file exists in the drop-down list box, tap the file to install the HUAWEI App Store. If the downloaded file does not exist in the drop-down list box, choose File > Local on the desktop, find the Download folder, and click the HUAWEI App Store installation package.

  • Page 130: How Can I Handle App Login Failure

    FusionModule5000 Smart Modular Data Center Commissioning Guide 7 FAQ  If you have set a password when enabling WiFi for the first time, you do not need to set the password again.  The WiFi function is disabled by default. If you need to use the WiFi function, enable it over the WebUI.
  • Page 131 FusionModule5000 Smart Modular Data Center Commissioning Guide 7 FAQ Use the user name and password that previously failed the login to log in to the app again. Step 2 If you have not obtained the user name and password used in a previous successful login, perform the following operations: Close the app and wait 4–5 minutes.

  • Page 132: A Verifying The Switchover Between Two Power Supplies

    FusionModule5000 Smart Modular Data Center A Verifying the Switchover Between Two Power Commissioning Guide Supplies Verifying the Switchover Between Two Power Supplies Prerequisites  The system is powered on, commissioned, and working properly.  Devices that have two power supplies have been properly powered on by both supplies.

  • Page 133: B (Optional) Powering Off The Power Supply And Distribution System

    FusionModule5000 Smart Modular Data Center B (Optional) Powering Off the Power Supply and Commissioning Guide Distribution System (Optional) Powering Off the Power Supply and Distribution System Prerequisites If the customer server has been powered on, do not power it off unless you have obtained prior consent from the customer.
  • Page 134 FusionModule5000 Smart Modular Data Center B (Optional) Powering Off the Power Supply and Commissioning Guide Distribution System The system meets requirements if its components are intact and systems are normal after power-off, and systems run stably after power-on. ----End Issue 06 (2020-03-20)

  • Page 135: C Acronyms And Abbreviations

    FusionModule5000 Smart Modular Data Center Commissioning Guide C Acronyms and Abbreviations Acronyms and Abbreviations alternating current analog input application battery control I/O board direct current digital input digital output energy control center equipment serial number Ethernet fast Ethernet iBAT intelligent Battery...
  • Page 136 FusionModule5000 Smart Modular Data Center Commissioning Guide C Acronyms and Abbreviations IEEE Institute of Electrical and Electronics Engineers Internet Protocol Internet technology light emitting diode Media Access Control monitoring display unit MTBF mean time between failures MTTR mean time to repair...
  • Page 137 FusionModule5000 Smart Modular Data Center Commissioning Guide C Acronyms and Abbreviations short message service SSID service set identifier Transport Layer Security uninterruptible power system universal serial bus video cloud node WiFi wireless fidelity WiFi protected setup Issue 06 (2020-03-20) Copyright © Huawei Technologies Co., Ltd.

Table of Contents
