Page 1 FusionModule800 Smart Small Data Center V100R021C00 User Manual Issue Date 2021-02-05 HUAWEI TECHNOLOGIES CO., LTD.
Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...
Page 3: About This Document
Purpose This document describes how to install and connect cabinets, devices, pipes, and cables for the FusionModule800 Smart Small Data Center (smart module for short), and how to commission, operate, and maintain the product, providing operation guidance and technical support for onsite installation personnel and technical support engineers.
Page 4 FusionModule800 Smart Small Data Center User Manual About This Document Symbol Description Supplements the important information in the main text. NOTE is used to address information not related to personal injury, equipment damage, and environment deterioration. Change History Changes between document issues are cumulative. The latest document issue contains all updates made in previous issues.
Page 5: Table Of Contents
FusionModule800 Smart Small Data Center User Manual Contents Contents About This Document........................ ii 1 Safety Information........................1 1.1 General Safety..................................1 1.2 Personnel Requirements............................... 4 1.3 Electrical Safety..................................4 1.4 Installation Environment Requirements.......................... 6 1.5 Mechanical Safety................................... 8 1.6 Cooling System Safety.................................10 1.7 Battery Safety..................................
Page 6 FusionModule800 Smart Small Data Center User Manual Contents 3.3.2 Application Conditions..............................38 3.3.3 Key Hardware Devices..............................39 3.3.3.1 Indoor Unit..................................40 3.3.3.2 Outdoor Unit................................... 40 3.4 Monitoring System................................41 3.4.1 Overview....................................42 3.4.2 System Functions................................43 3.4.2.1 Monitoring..................................43 3.4.2.2 App View................................... 44 3.4.2.3 Alarm....................................
Page 7 FusionModule800 Smart Small Data Center User Manual Contents 3.4.4.1 System Overview................................86 3.4.4.2 Server....................................87 3.4.4.3 LAN Switch..................................87 3.4.5 (Optional) Edge Data Center Management System..................... 87 3.5 Surge Protection and Grounding System........................88 3.5.1 Surge Protection Solution............................... 88 3.5.2 Grounding Solution................................88 3.6 Integrated Cabling System..............................
Page 8 FusionModule800 Smart Small Data Center User Manual Contents 4.2.7 Installing Power Supply and Distribution Devices....................157 4.2.7.1 Installing Lithium Batteries............................157 4.2.7.2 Installing a PDU2000..............................158 4.2.7.3 (Optional) Installing an ATS Subrack........................162 4.2.8 (Optional) Installing Cable Troughs......................... 163 4.2.8.1 Removing a Binding Plate............................163 4.2.8.2 Installing a 600 mm Wide Cable Trough......................164...
Page 9 FusionModule800 Smart Small Data Center User Manual Contents 4.3.5.1.3 Connecting Input Power Cables to the Converged Cabinet..............227 4.3.5.1.4 Connecting Output Power Cables to the Converged Cabinet..............228 4.3.5.2 Bottom Cable Routing............................... 230 4.3.5.3 Connecting PDU2000 Power Cables........................232 4.3.5.4 Connecting Signal Cables for the Intelligent PDU2000..................234 4.3.5.5 Preparing Power Cables.............................237...
Page 10 FusionModule800 Smart Small Data Center User Manual Contents 5.3.7 Adding a UPS2000G............................... 276 5.3.8 Commissioning Sensors..............................277 5.3.8.1 Commissioning the Smoke Detector (Connected to the AI/DI Port on the ECC800)......277 5.3.8.2 Commissioning the T/H Sensor (BOM Number: 02312PBL)................ 278 5.3.8.3 Commissioning the WLD900 Water Sensor.......................
Page 11 FusionModule800 Smart Small Data Center User Manual Contents 5.3.13.2.2 Installing the EDCM App............................. 349 5.3.13.2.3 Allowing a User to Log in to the EDCM on a Mobile Device..............350 5.3.13.2.4 (Optional) Replacing the App Certificate on a Mobile Device.............. 350 5.3.13.2.5 Logging In to the EDCM App..........................350...
Page 12 FusionModule800 Smart Small Data Center User Manual Contents 6.4.3.2.3 Replacing a Filter Dryer............................446 6.4.3.2.4 Replacing a High Pressure Sensor........................450 6.4.3.2.5 Replacing a Pneumatic Switch..........................451 6.4.3.2.6 Replacing a Safety Valve............................453 6.4.3.2.7 Replacing a Switch for the Outdoor Unit......................455 6.4.4 Replacing Management System Components......................
Page 13: Safety Information
The "NOTICE", "CAUTION", "WARNING", and "DANGER" statements in this document do not cover all the safety instructions. They are only supplements to the safety instructions. Huawei will not be liable for any consequence caused by the violation of general safety requirements or design, production, and usage safety standards.
Page 14 FusionModule800 Smart Small Data Center User Manual 1 Safety Information General Requirements ● Do not install, use, or operate outdoor equipment and cables (including but not limited to moving equipment, operating equipment and cables, inserting connectors to or removing connectors from signal ports connected to outdoor facilities, working at heights, and performing outdoor installation) in harsh weather conditions such as lightning, rain, snow, and level 6 or stronger wind.
Page 15 FusionModule800 Smart Small Data Center User Manual 1 Safety Information ● All cable holes should be sealed. Seal the used cable holes with firestop putty. Seal the unused cable holes with the caps delivered with the cabinet. The following figure shows the criteria for correct sealing with firestop putty.
Page 16: Personnel Requirements
Do not power on the equipment before it is installed or confirmed by professionals. 1.2 Personnel Requirements ● Personnel who plan to install or maintain Huawei equipment must receive thorough training, understand all necessary safety precautions, and be able to correctly perform all operations. ●...
Page 17 FusionModule800 Smart Small Data Center User Manual 1 Safety Information General Requirements Use dedicated insulated tools when performing high-voltage operations. AC and DC Power D ANGER Do not connect or disconnect power cables with power on. Transient contact between the core of the power cable and the conductor will generate electric arcs or sparks, which may cause fire or personal injury.
Page 18: Installation Environment Requirements
FusionModule800 Smart Small Data Center User Manual 1 Safety Information ● Do not perform any improper operations, for example, dropping cables directly from a vehicle. ● When selecting, connecting, and routing cables, follow local safety regulations and rules. NO TICE...
Page 19 FusionModule800 Smart Small Data Center User Manual 1 Safety Information vents, or feeder windows of the equipment room. Ensure that no liquid enters the equipment to prevent faults or short circuits. ● If any liquid is detected inside the equipment, immediately disconnect the power supply and contact the administrator.
Page 20: Mechanical Safety
FusionModule800 Smart Small Data Center User Manual 1 Safety Information 1.5 Mechanical Safety Hoisting Devices ● Do not walk under hoisted objects. ● Only trained and qualified personnel should perform hoisting operations. ● Check that hoisting tools are available and in good condition.
Page 21 FusionModule800 Smart Small Data Center User Manual 1 Safety Information ● When climbing a ladder, take the following precautions to reduce risks and ensure safety: – Keep your body steady. – Do not climb higher than the fourth rung of the ladder from the top.
Page 22: Cooling System Safety
FusionModule800 Smart Small Data Center User Manual 1 Safety Information ● When moving the equipment by hand, wear protective gloves to prevent injuries. ● Move or lift the equipment by holding its handles or lower edges. Do not hold the handles of modules (such as power supply units, fans, and boards) that are installed in the equipment because they cannot support the weight of the equipment.
Page 23: Battery Safety
FusionModule800 Smart Small Data Center User Manual 1 Safety Information Refrigerant Frostbite Refrigerant leakage may cause frostbite. Take protective measures (for example, wear antifreeze gloves) when handling refrigerant. Storage and Recycling ● Do not store devices near a heat source or under direct sunshine.
Page 24 NO TICE To ensure battery safety and battery management accuracy, use batteries provided with the UPS by Huawei. Huawei is not responsible for any battery faults caused by batteries not provided by Huawei. Battery Installation Before installing batteries, observe the following safety precautions: ●...
Page 25 FusionModule800 Smart Small Data Center User Manual 1 Safety Information Lead-acid batteries emit flammable gas when used. Ensure that batteries are kept in a well-ventilated area and take preventive measures against fire. Battery Leakage NO TICE Battery overheating causes deformation, damage, and electrolyte spillage.
Page 26: Others
FusionModule800 Smart Small Data Center User Manual 1 Safety Information ● Do not throw a lithium battery in fire. ● When maintenance is complete, return the waste lithium battery to the maintenance office. 1.8 Others ● Exercise caution when shutting down the smart cooling product. Doing so may cause equipment and room overheating, which will damage the equipment.
Page 27: Product Description
2 Product Description Product Description 2.1 Positioning The FusionModule800 is a smart small data center solution applied to air cooled scenarios where the equipment room area is less than 40 m . This solution mainly applies to city-, district-, and county-level data centers of the government vertical industry, small-sized second-level branches and large-sized offices in the financial industry, and equipment rooms of small- and medium-sized enterprises.
Page 28 FusionModule800 Smart Small Data Center User Manual 2 Product Description Figure 2-1 Position of the FusionModule800 in the financial industry (1) FusionModule5000 (2) FusionModule2000 (3) FusionModule800 (4) FusionModule500 Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd.
Page 29: Features
FusionModule800 Smart Small Data Center User Manual 2 Product Description Figure 2-2 Position of the FusionModule800 in the government vertical industry (1) FusionModule5000 (2) FusionModule2000 (3) FusionModule800 (4) FusionModule500 2.2 Features Integration ● The smart module integrates the cabinet system, power supply and...
Page 30 FusionModule800 Smart Small Data Center User Manual 2 Product Description Small Footprint and Energy Conservation ● No specialized equipment room is required. The smart module can be deployed in a renovated room of an office building. ● The product can be installed on a concrete floor in a building, which simplifies auxiliary engineering.
Page 31: Typical Application Scenarios
FusionModule800 Smart Small Data Center User Manual 2 Product Description 2.3 Typical Application Scenarios The smart module mainly applies to government, education, medical care, transportation, energy, finance, small- and medium-sized enterprises, and branches of large companies. Target markets: ● Asia Pacific, Africa (including high-temperature areas in North Africa), Europe, and Middle East (380–415 V, 3Ph+N, 50/60 Hz power systems are supported.)
Page 32: System Architecture
FusionModule800 Smart Small Data Center User Manual 3 System Architecture System Architecture 3.1 Structure System Figure 3-1 Cabinet system (1) IT cabinets (2) Camera mounting kit on (3) Gas spring the enclosed framework (4) Side sealing plate (5) Cabinet electronic clasp...
Page 33 FusionModule800 Smart Small Data Center User Manual 3 System Architecture Cabinets used in the data center comply with the International Electrotechnical Commission (IEC) 60297-1 standard and provide stable installation space for servers, thereby ensuring the safe operation of servers. Figure 3-2 Cabinet...
Page 34: Converged Cabinet
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Item Technical Specifications Static load 1500 kg Dynamic load 1000 kg Protection level IP20 Figure 3-3 Mounting hole positions at the cabinet bottom Table 3-2 Technical specifications of mounting holes at the cabinet bottom...
Page 36: Components Of Single-Row Cold And Hot Aisle Containment
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Figure 3-5 Modules in the Converged Cabinet (1) Indicator module (2) UPS2000-G (3) Power distribution module (4) ECC800-Pro (5) Smart cooling product (6) Smart cooling product control unit indoor unit 3.1.3 Components of Single-Row Cold and Hot Aisle...
Page 37 FusionModule800 Smart Small Data Center User Manual 3 System Architecture Cabinet Door ● In cold and hot aisle containment, a sealed glass door is configured at the front and a sealed sheet metal door at the rear. ● By default, the front and rear doors of a cabinet are equipped with electronic clasp locks, which can be unlocked only by using dedicated keys.
Page 38: Power Supply And Distribution System
FusionModule800 Smart Small Data Center User Manual 3 System Architecture ● Signal cables and power cables are routed in different cable troughs to separate electrical cables from ELV cables. ● Signal cables are installed on the top of the front door of the cabinet, and power cables are installed on the top of the rear door of the cabinet.
Page 39 FusionModule800 Smart Small Data Center User Manual 3 System Architecture Category Item Specifications Maximum power ● Normal temperature and low consumption of a temperature: 7 kW single IT cabinet ● High temperature condition: 6 Power supply Single power input Supported...
Page 40: Working Principles
FusionModule800 Smart Small Data Center User Manual 3 System Architecture 3.2.2 Working Principles Conceptual Diagram for the N Power Distribution System Figure 3-10 Conceptual diagram for the N power distribution system 3.2.3 Key Hardware Devices 3.2.3.1 Power Distribution Module Table 3-4 Power distribution module specifications...
Page 41: Kva Ups
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Item Specifications General input 63 A MCB UPS input 1 x D63A/1P MCB UPS output 1×C63A/1P MCB UPS Bypass 1 x C63A/1P MCB Power Distribution for 1×C40A/1P MCB+1×C25A/1P MCB Smart Cooling Product IT power distribution 4×C40A/1P MCB...
Page 42: Battery Module
FusionModule800 Smart Small Data Center User Manual 3 System Architecture (1) Liquid crystal display (2) Maintenance bypass (MBS) (3) Battery (LCD) port management system (BMS) ports (4) RS232 (5) RS485 communications (6) USB port communications port ports (connect to northbound...
Page 43: Pdu2000
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Silk Screen Name COM_ OUT Communications port Running indicator Alarm indicator Charge indicator DCHG Discharge indicator SOC indicator Buzzer MANUAL ON/OFF Button for manual power-on/off ESMU port for connecting to an...
Page 44: Optional) Intelligent Pdu2000
FusionModule800 Smart Small Data Center User Manual 3 System Architecture 3.2.3.4.2 (Optional) Intelligent PDU2000 The intelligent PDU2000 accurately and effectively monitors the real-time status changes of the current, voltage, power, and electric energy of electrical devices in the data center.
Page 45: Ats Subrack
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Item Specifications Monitoring function Monitors the input power, voltage, current, power factor, and electric energy 3.2.3.5 ATS Subrack Figure 3-15 ATS subrack (1) Dual input indicator (2) Monitoring board (3) Route II switch button...
Page 46 FusionModule800 Smart Small Data Center User Manual 3 System Architecture Figure 3-16 ATS monitoring board Table 3-8 LED indicator status description Indicat Name Description ATS running ● Steady green: working properly status ● Steady yellow: warning or minor indicator alarm ●...
Page 47: Cooling System
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Indicat Name Description Route I switch ● Steady green: route I switched on status ● Off: route I switched off indicator ● Steady red: route I switched on abnormally Route II switch ●...
Page 48 FusionModule800 Smart Small Data Center User Manual 3 System Architecture Item NetCol5000-A013HX0E1 (Excluding Heater and Humidifier) Certification Normal-temperature model: REACH, RoHS, CE, CCC, and CQC Low-temperature model: REACH, RoHS, CE, CCC, CQC, and EAC High-temperature models: REACH, RoHS, CE, SASO Maximum current 3.3A...
Page 49 FusionModule800 Smart Small Data Center User Manual 3 System Architecture Table 3-10 Technical specifications of normal-temperature outdoor units Item NetCol500-A018 NetCol500-A021 NetCol500-A020 (Normal- (Low- (High- Temperature Temperature Temperature Outdoor Unit) Outdoor Unit) Outdoor Unit) Power system 208–240 V AC, 220–240 V AC, 220–240 V AC,...
Page 50: Application Conditions
Between the Indoor 30 m and Outdoor Units ● Indoor unit placed higher than the indoor unit: ≤ 8 Maximum Equivalent 80 m. If the length exceeds 80 m, contact Huawei Length of One-way technical support. Pipe Thermal Insulation ≥ 13 mm...
Page 51: Key Hardware Devices
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Water Supply The inlet water pressure should be in the range of Requirements 0.1–0.7 MPa, and the temperature should be in the range of 1°C–40°C. The wet film humidifier should use tap water that meets the following requirements: ●...
Page 52: Indoor Unit
FusionModule800 Smart Small Data Center User Manual 3 System Architecture 3.3.3.1 Indoor Unit The indoor unit consists of the EC fan, evaporator, electronic expansion valve, electric heater (optional), wet film humidifier (optional), light load dehumidifier, and condensate pump. Figure 3-18 Indoor unit 3.3.3.2 Outdoor Unit...
Page 53: Monitoring System
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Figure 3-20 Exterior of the outdoor unit of a high-temperature model Figure 3-21 Exterior of the outdoor unit of a low-temperature model 3.4 Monitoring System Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd.
Page 54: Overview
FusionModule800 Smart Small Data Center User Manual 3 System Architecture 3.4.1 Overview The management system implements data collection and management for various processes and infrastructure of the smart module. The ECC800-Pro manages the real-time status, alarms, and configuration information about the devices inside the smart module. It also provides a graphical user interface (GUI) for ease of operating and maintaining devices inside the smart module.
Page 55: System Functions
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Device Maximum Quantity Port Temperature sensor Water sensor Cabinet electronic clasp RS485 lock WiFi module The management system provides a GUI to implement comprehensive management functions based on requirements. The system can monitor the following equipment: ●...
Page 56: App View
FusionModule800 Smart Small Data Center User Manual 3 System Architecture ● Water leakage monitoring: Detects water leakage at the bottom of the smart module and provides real-time alarm signals. ● Smoke monitoring: Detects smoke in the smart module and provides real- time alarm signals.
Page 57: Linkage Control
FusionModule800 Smart Small Data Center User Manual 3 System Architecture ● Performance data statistics: You can view historical data of devices to help analyze data or problems. ● Operation log: You can view logs of key operations, such as user login, parameter modification, data export, device upgrade, and access control events.
Page 58 FusionModule800 Smart Small Data Center User Manual 3 System Architecture Item Specifications Storage temperature –40°C to +70°C Relative humidity 5%–95% RH (non-condensing) Altitude 0–4000 m (When the altitude is between 3000 m and 4000 m, the temperature decreases by 1°C for each additional 200 m.)
Page 59: Main Control Module
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Table 3-17 Power port pin definitions Port Type Description sequence Pin1 Pin2 Pin3 Pin1 48V+ Pin2 48VGND 3.4.3.1.2 Main Control Module Figure 3-26 ECC800-Pro collector main control module (1) USB...
Page 60 FusionModule800 Smart Small Data Center User Manual 3 System Architecture Figure 3-27 ECC800-Pro main control module (side view) (1) SIM card slot (2) Micro SD card slot (reserved) Specifications Table 3-18 Technical specifications of the ECC800-Pro main control module Item...
Page 61 FusionModule800 Smart Small Data Center User Manual 3 System Architecture Item Specifications AIDI ● Output voltage: 13–15 V DC (rated voltage: 14.5 V DC) expansion ● Provides five universal AIDI ports for connecting to sensors (RJ45) such as smoke sensors, water sensors, and NTC sensors.
Page 62 FusionModule800 Smart Small Data Center User Manual 3 System Architecture Item Specifications ● Supports USB 2.0 and 5 V, 1 A power supply. ● After installing the WiFi module, connect the WiFi module to the ECC800-Pro using the app on the mobile phone or...
Page 63 FusionModule800 Smart Small Data Center User Manual 3 System Architecture Figure 3-28 RJ45 port pins There are four GE ports, that is, two WAN ports (WAN1 and WAN2) and two LAN ports (LAN1/POE and LAN2/POE). Table 3-21 GE port pin definitions...
Page 64 FusionModule800 Smart Small Data Center User Manual 3 System Architecture Item Description Pin7 Pin8 Indicator Green Power output indicator indicator ● Steady on: The 12 V DC output is normal. ● Off: No 12 V DC output is provided. Table 3-23 COM3/12V port pin definitions...
Page 65 FusionModule800 Smart Small Data Center User Manual 3 System Architecture The following provides the AIDI_1, AIDI_2 and AIDI_3 ports pin definitions. NO TE ● Pins 1, 2, 4, and 5 identify sensor types. ● Pin 3 and Pin 8 are power output ports.
Page 66 FusionModule800 Smart Small Data Center User Manual 3 System Architecture Item Description Indicator Green Power output indicator indicator ● Steady on: The 12 V DC output is normal. ● Off: No 12 V DC output is provided. Table 3-27 USB port pin definitions...
Page 67 FusionModule800 Smart Small Data Center User Manual 3 System Architecture Indicator Color Name Status Description RF_Z Green Communication Blinking at A network is set up, and no status indicator long node access is allowed (the intervals indicator blinks at 0.5 Hz, on for 1s and then off for 1s).
Page 68: Power Module
FusionModule800 Smart Small Data Center User Manual 3 System Architecture 3.4.3.1.3 Power Module Indicator Table 3-30 PSU indicator description Indicator Color Name Status Description Green Power Steady on The converter has a power indicator input. The converter has no power input or is faulty.
Page 69: Smart Cooling Product Control Unit
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Indicator Color Name Status Description The converter delivers no output due to internal faults. The converter is working properly. 3.4.3.2 Smart Cooling Product Control Unit The control unit of the smart cooling product consists of a main control board and a display unit that is integrated in the Converged Cabinet.
Page 70: Pad
FusionModule800 Smart Small Data Center User Manual 3 System Architecture ● Displays the operating status and duration of the components of the smart cooling product in real time on the touchscreen (optional) of the Converged Cabinet. ● Provides RS485 and FE ports that support the MAC-Modbus protocol.
Page 71: Wifi Module
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Item Specifications Camera ● Rear camera: 8-megapixel, F2.4 aperture, automatic focus ● Front camera: 2-megapixel, F2.4 aperture, fixed focus ● Sensor type: BSI ● Flash: not supported ● Video recording: rear camera up to 1080 pixels at 30 FPS;...
Page 72: Eth Converter
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Item Specifications Wireless 20 dBm (MAX EIRP) transmission power Supported Windows 2000/XP/Vista/Linux/Win 7 operating system Port USB 2.0 Hi-Speed connector Voltage range 5.0 V DC±5% Operating –20°C to +70°C temperature Storage –40°C to +90°C...
Page 73 FusionModule800 Smart Small Data Center User Manual 3 System Architecture Specifications Table 3-34 ETH converter technical specifications Item Specifications Power ● DC input: terminal, with an input voltage of 36 V DC–60 V DC input ● PoE power supply: one PoE port, 10/100M communication rate, complying with IEEE802.3at...
Page 74: Smart Eth Gateway
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Indicat Color Name Status Description Blinking The indicator blinks at super short intervals for 0.5s (blinking at 10 Hz, on for 0.05s and then off for 0.05s) and then turns off for 0.5s.
Page 75 FusionModule800 Smart Small Data Center User Manual 3 System Architecture Specifications Table 3-36 Technical specifications for a smart ETH gateway Item Specifications Power input PWR_IN D-type power input terminal, for power cascading, input voltage range: 45–55 V DC Power of a single smart ETH gateway: max (2.7 A, 48 V DC);...
Page 76: Optional) Elight
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Indica Color Name Status Description Blinking The indicator blinks at super short intervals for 0.5s (blinking at 10 Hz, on for 0.05s and then off for 0.05s) and then turns off for 0.5s.
Page 77 FusionModule800 Smart Small Data Center User Manual 3 System Architecture Table 3-38 Description of the eLight strip light colors Scenario Light Color Remarks Non-associated Blue alarm severity NOTE On the ECC800-Pro WebUI, set Associated Alarm Severity to None. Associated alarm...
Page 78: Environment Monitoring System
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Item Specifications eLight strip light ● Rated input voltage: 24 V DC ● Light type: RGBW LED strip light, in different colors depending on instructions ● Power: RGB fully on under the maximum working condition, power P ≤...
Page 79: Optional) Electrode Water Sensor
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Item Specification Storage –40°C to +85°C temperature Humidity 10%–80% RH (non-condensing) 3.4.3.8.2 (Optional) Electrode Water Sensor The electrode water sensor with the BOM number of 33010444 contains electrode probes and cables.
Page 80: Temperature Sensor
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Figure 3-37 Appearance (1) RS485-OUT (2) RS485-IN (3) DIP switch (4) Button (5) NTC1–3 (6) NTC4–6 (7) Display T/H Sensor (BOM Number: 02312PBL) Table 3-42 T/H sensor specifications Item Temperature...
Page 81: Ambient T/H Sensor
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Figure 3-38 Temperature sensor Table 3-43 Temperature sensor specifications Item Specifications Measurement range –20ºC to +70ºC Measurement precision ±1ºC (25ºC) Operating temperature –10ºC to +55ºC Operating voltage 10–16 V DC Storage temperature –40ºC to +70ºC...
Page 82: Smoke Detector
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Figure 3-40 RJ45 port pins Table 3-44 RJ45 port pin definitions Description Pin1 or Pin 4 Pin2 or Pin 5 Pin3 Pin6 Pin7 Reserved Table 3-45 T/H sensor specifications Item...
Page 83: Cabinet Electronic Clasp Lock
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Figure 3-41 Smoke detector Table 3-46 Smoke detector technical specifications Item Specifications Operating voltage 9–27 V Alarm current < 20 mA Indication Monitoring: The red indicator blinks once every 3 to 8 seconds.
Page 84 FusionModule800 Smart Small Data Center User Manual 3 System Architecture Figure 3-42 Cabinet electronic clasp lock (1) LED indicator (2) DIP switch (3) RJ45 power port Table 3-47 RJ45 port definitions Pin Description Description RS485+ RS485+ RS485- RS485- +12 V power supply...
Page 85: Optional) Room Access Control System
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Table 3-48 LED indicator status Indi Color Name Operat Status Description cato Green Module Blinki ● The door lock is paired running with the host, and the indicator power supply is normal: The indicator blinks at 0.5 Hz (on for 1s and...
Page 86 FusionModule800 Smart Small Data Center User Manual 3 System Architecture Figure 3-43 Access actuator (1) 48 V power port (2) POE port (3) RS485 port COM2 (4) RS485 port COM1 (5) Address DIP switch (6) Status indicator (7) BLINK button...
Page 87 FusionModule800 Smart Small Data Center User Manual 3 System Architecture Item Specifications Wiegand Two Wiegand interfaces, 12 V DC card reader operating power interface output; two routes of card readers (non-fingerprint readers) can operate at the same time. BLINK ● Press the button for less than 1 second to start blinking.
Page 88 FusionModule800 Smart Small Data Center User Manual 3 System Architecture Indicator Color Name Status Green Communication status ● Off: The power is indicator abnormal or the board program is loading. ● Blinking at long intervals: The access actuator successfully registers...
Page 89 FusionModule800 Smart Small Data Center User Manual 3 System Architecture Indicator Color Name Status RF_Z Green Wireless ● Steady on: No communication status network parameters indicator exist, or a network is to be created. ● Blinking at long intervals: A network...
Page 90: Fingerprint And Card Reader With A Keypad
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Item Description GATE/COM GATE (door status) pin sequence 3.4.3.10.2 Fingerprint and Card Reader with a Keypad Figure 3-44 Fingerprint and card reader with a keypad (1) Fingerprint reader (2) LED indicator...
Page 91: Fingerprint And Card Reader
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Table 3-53 Access control device operating status Item New Version Standby LED indicator The indicator is steady blue. Fingerprint reader The indicator is off. Unauthorized fingerprint LED indicator The indicator blinks blue,...
Page 92: Card Reader With A Keypad
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Table 3-54 Fingerprint and card reader Item Specifications Dimensions (L x W x H) 156 mm x 53 mm x 38 mm Rated operating voltage 12 V DC±5% Rated operating current 300 mA±5%...
Page 93: Magnetic Lock
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Figure 3-46 Card reader with a keypad Table 3-56 Technical specifications of a card reader with a keypad Item Specifications Dimensions (L x W x H) 114 mm x 63 mm x 25 mm Operating voltage Operating voltage range: 10.8–13.2 V DC;...
Page 94: Video Management System
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Figure 3-48 Single door magnetic lock 3.4.3.11 Video Management System The video surveillance subsystem consists of the camera and network video recorder and implements real-time monitoring, video storage, and video playback.
Page 95: Ivs1800
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Item Specifications Video compression H.265/H.264/MJPEG standard Maximum resolution 1920x1080 Power supply 12 V DC, PoE IP rating IP67 Vandal resistant rating IK10 3.4.3.11.2 IVS1800 Figure 3-50 Appearance Table 3-58 Performance specifications...
Page 96: Vcn510
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Table 3-59 Hardware specifications Category Item Specifications Storage Hard disk capacity quantity Hard disk SATA3.0 port Hard disk Enterprise-level disks: 4 TB, 6 TB, 8 TB, or 10 TB type...
Page 97 FusionModule800 Smart Small Data Center User Manual 3 System Architecture Figure 3-51 Appearance Table 3-60 Performance specifications Item Specifications Device access and video storage Supports a maximum of eight video access channels or 128 Mbit/s video access bandwidth. Video forwarding...
Page 98: Optional) Neteco Intelligent Data Center Management System
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Item Specifications Weight in full configuration (including ≤ 5 kg disks) Maximum power consumption < 60 W (including hard disks) Dimensions (H x W x D) 43.6 mm x 442 mm x 310 mm (1 U, excluding the panel) 43.6 mm x 442 mm x 320 mm (1 U,...
Page 99: Server
FusionModule800 Smart Small Data Center User Manual 3 System Architecture 3.4.4.2 Server The NetEco can be deployed on one of the following servers according to the management capability requirement. Table 3-62 Server Model Configuration TaiShan 200 (Model 2280) 2 x Kunpeng 920 48-core@2.6 GHz, 4 x 32 standard configuration GB memory, 2 x 1.2 TB + 8 x 1.8 TB drives...
Page 100: Surge Protection And Grounding System
FusionModule800 Smart Small Data Center User Manual 3 System Architecture ● Alarm monitoring: Displays site alarm information in real time and quickly locates device faults. ● Security monitoring: Monitors the cabinet door status and cameras in sites. Figure 3-53 Networking mode 3.5 Surge Protection and Grounding System...
Page 101: Integrated Cabling System
FusionModule800 Smart Small Data Center User Manual 3 System Architecture Figure 3-54 Equipotential connection of the cabinet system (1) General ground bar Cabinet Grounding ● Metal components and parts of cabinets are properly connected. A structural connection area is protected and applied with antioxidants. An area protected with painting should ensure proper metal surface contact for two connected components.
Page 102: Fire Extinguishing System
T/H sensor, smoke detector, video, and intelligent spring lock. 3.7 Fire Extinguishing System Huawei provides only sensors for the fire extinguishing system in the smart module. Other components need to be prepared by the customer. Issue 01 (2021-02-05)
Page 103: Installation Guide
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Installation Guide 4.1 Installation Preparations 4.1.1 Tools and Instruments This section lists the tools and instruments required for installation. NO TICE ● Use insulated tools. The following figure is for reference only.
Page 104 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Name, Specifications, and Appearance Adjustable wrench Socket wrench Hex key (5 mm) Laser locator (6") M6/M8/M12 Right angle Electrician's knife Impact tool Utility knife Needle-nose Diagonal pliers RJ45 crimping Insulation tape...
Page 105 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Name, Specifications, and Appearance Electroprobe Cable tie Rubber mallet Heat-shrink tubing Electric Heat gun Hammer drill screwdriver Table 4-2 Tools and instruments for installing smart cooling products Name, Specifications, and Appearance...
Page 106: Personnel Requirements
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Name, Specifications, and Appearance Pipe bender Insulation gloves Pressure gauge (1 Rubber hose (3 PCS) PCS) Water pipe thread Nitrogen Reducing valve Vacuum pump sealant a. Pressure gauge and rubber hose: dedicated for R410A. The measuring range of the pressure gauges must be at least 4.0 MPa, and the rubber hoses must...
Page 107: Installation Environment Check
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide CA UTION Huawei will not be liable for any consequence caused by the violation of this document. The requirements are as follows: ● Customers' installation personnel must be trained by Huawei and understand how to install and operate a modular data center.
Page 108 NO TE If any of the requirements is not met, contact Huawei technical support. NO TICE The UPS can generate large leakage currents. A circuit breaker equipped with an RCD is not recommended. If leakage protection is required, select a recommended upstream circuit breaker for the smart module.
Page 109: Site Requirements
● The cabinet layouts shown in the figures are for ease of description and do not provide reference for engineering layout. ● If the site conditions do not meet the space requirements, contact Huawei technical support. Figure 4-1 Site space requirements 4.1.5 Installation Scenarios...
Page 110 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-2 Component layout in the Converged Cabinet You are advised to number cabinets and PDU2000s based on Figure 4-3. NO TE ● The following describes how to number cabinets and PDU2000s in a scenario with five cabinets.
Page 111: Smart Cooling Product Installation
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-3 Number example 4.1.6 Smart Cooling Product Installation Installation Dimension Smart cooling product outdoor units are available in three models, NetCol500- A018, NetCol500-A020, and NetCol500-A021, Figure 4-4, Figure 4-5...
Page 112: Hardware Installation
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-5 Installation dimensions of NetCol500-A020 Figure 4-6 Installation dimensions of NetCol500-A021 Unit 1 MPa ≈ 10 bar 1 MPa ≈ 145 psi 1 MPa ≈ 10.2 kgf/cm 4.2 Hardware Installation The angle of door opening by the gas spring is 110°.
Page 113: Cabinet Transportation And Unpacking
Check against the packing list that the equipment and fittings are correct and complete. If some fittings are missing or do not comply with the packing list, record the information and contact your local Huawei office immediately. After checking that the cabinet is intact, remove the screw assemblies that...
Page 114 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-7 Removing an ordinary cabinet Remove the cabinet from the pallet and move the cabinet to the installation position. NO TICE To avoid personal injury, prevent the cabinet from falling over during transportation.
Page 115 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-8 Removing the cabinet lower sealing plates Figure 4-9 Removing the L-shaped brackets Figure 4-10 Installing the cabinet lower sealing plates Connect the ramps to the rear door side of the pallet and extend the ramps,...
Page 116: Smart Cooling Product Transportation And Unpacking
For position of safety valve, see the overtemperature mark. ● If the marks with 60, 65 turn black or all the marks turn black, ask Huawei to confirm whether the unit can be used. ----End Issue 01 (2021-02-05)
Page 117 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Unpacking the Outdoor Unit Step 1 Verify that the outdoor unit package is intact. If any damage is found, notify the carrier immediately. Step 2 Remove the package. Remove the straps, outer packing materials, cushioning materials, and then plastic film.
Page 118: Optional) Removing Aisle Containments
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-15 Hoisting a NetCol500-A020 outdoor unit Figure 4-16 Hoisting a NetCol500-A021 outdoor unit ----End 4.2.2 (Optional) Removing Aisle Containments Prerequisites The cabinets have been transported to the destination place and unpacked.
Page 119 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide NO TICE The cabinet front door is made of glass. Pay attention to the following during transportation: ● Move the cabinet with caution. ● Ensure that the glass door does not collide with sharp objects.
Page 120 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-18 Removing the gas springs Step 4 Remove the ground cable from the Converged Cabinet. Step 5 Lift the cabinet doors off the hinges. Remove the front and rear doors.
Page 121 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-20 Removing the top plate Step 7 (Optional) Remove the screws from the air director in the Converged Cabinet, and pull out the air director. Figure 4-21 Removing the air director Step 8 Remove the screws securing the aisle containment to the cabinet using a Phillips screwdriver, and remove the aisle containment from the cabinet.
Page 122 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-22 Removing an aisle containment Step 9 Remove other aisle containments in the same way. Step 10 Move the removed air directors, glass doors, gas springs, top plates, aisle containments, and cabinets to the specified installation position using an elevator.
Page 123: Adjusting The Positions Of Aisle Side Sealing Plates
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-23 Positioning pin on an air director (1) Positioning pin ----End 4.2.3 Adjusting the Positions of Aisle Side Sealing Plates Context ● The Converged Cabinet has been configured with aisle side sealing plates on both sides before delivery.
Page 124 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-24 Removing aisle side sealing plates from the Converged Cabinet Step 2 Remove other aisle side sealing plates in the same way. Step 3 Secure the sealing plate fasteners to the aisle frame of the end cabinet using M5 tapping screws.
Page 125 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Step 4 Install floating nuts for the end cabinet. NO TE ● The floating nuts are packed in the IT cabinet. ● Install floating nuts for other aisle side sealing plates in the same way.
Page 126: Installing A Cabinet
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide 4.2.4 Installing a Cabinet Prerequisites The floor levelness meets engineering requirements. Context To position cabinets, perform the following steps: Determine the position of an end cabinet based on the engineering layout diagram.
Page 127 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-28 Leveling a cabinet Step 4 Combine cabinets. Level the cabinets adjacent to the end cabinet using the method in Step Remove the screws securing connecting kits from the cabinet, take off the connecting kits, and properly store the removed screws.
Page 128: Optional) Installing The Elight
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Combine adjacent cabinets by installing the connecting kits at the combination positions on the front and rear doors of the cabinets with screws Step 5 Install other cabinets in the same way.
Page 129 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-30 Routing a strip light extension cable (1) Strip light extension cable (2) ETH converter Route the strip light from the top of the cabinet at one end to the top of the cabinet at the other end, and secure the strip light using the fastener.
Page 130 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Align one end of the support with the notch on the rear door side of the top panel, and hook the other end of the support to the long strip hole on the top...
Page 131: Installing A Smart Cooling Product
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-34 Cable connection for the eLight system NO TE Whether the PE cable to the power module needs to be connected depends on the actual power port. ----End 4.2.6 Installing a Smart Cooling Product 4.2.6.1 Materials...
Page 132 User Manual 4 Installation Guide NO TICE Do not use unqualified refrigerant. Huawei will not be liable for any equipment damage caused by unqualified refrigerant. Customers can purchase this material from Huawei or other vendors. Verify that the refrigerant is authentic in the following ways: Dial the refrigerant manufacturer's hotline to confirm the refrigerant authenticity.
Page 133 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Saturation Gauge Saturation Gauge Saturation Gauge Temperatu Pressure Temperatu Pressure Temperatu Pressure re (°C) (MPa) re (°C) (MPa) re (°C) (MPa) 0.93 1.65 0.96 1.69 2.76 0.99 1.74 2.83 1.02 1.79...
Page 134 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Table 4-6 Specifications Item Specifications Gas pipe ● L ≤ 60 m, 5/8 inch (15.88 mm), wall thickness: 1.0 mm; pressure withstanding capacity ≥ 4.5 MPa ● 60 m < L ≤ 80 m, 7/8 inch (22.2 mm), wall thickness: 1.2 mm;...
Page 135 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Pipe Support Figure 4-38 shows a support for a refrigerant or water pipe. Select supports based on site conditions. Figure 4-38 Pipe support (unit: mm) NO TE ● The height of a U-shaped pipe clamp equals the pipe diameter with thermal insulation foam minus 5 mm.
Page 136: Layout Principles
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Application Specifications Remarks Scenario Delivered with the Naked crimping terminal: OT, 6 mm fittings M6, 50 A, tin plating, 12-10 AWG, yellow Signal cable to Electrical power cable, 300 V, SJTW,...
Page 137: Installing An Outdoor Unit
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-39 Layout of upward piping (1) Oil trap (2) Tilted gas pipe (3) Indoor unit (4) Tilted liquid pipe Figure 4-40 Layout of downward piping (1) Oil trap (2) Tilted gas pipe...
Page 138 ● If the site installation environment is complicated and the preceding conditions are not met, contact Huawei technical support. Concrete Base Requirements Install an outdoor unit on the base to prevent it from falling down in an earthquake or a strong wind.
Page 139: Space Requirements
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-41 Concrete base requirements 4.2.6.3.2 Space Requirements Single Outdoor Unit ● A single outdoor is recommended to be installed against a wall, as shown in Figure 4-42. Figure 4-42 Space requirements for installing single outdoor unit If the outdoor unit cannot be installed against a wall or the local outdoor temperature may be below –10°C (NetCol500-A018) or 0°C (NetCol500-A020)
Page 140 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-43 Space requirements for installing an air baffle ● Installing an outdoor unit on a wall, as shown in Figure 4-44. Figure 4-44 Requirements for installing an outdoor unit on a wall NO TE ●...
Page 141: Securing An Outdoor Unit
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-45 Space requirements for installing multiple outdoor units 4.2.6.3.3 Securing an Outdoor Unit Prerequisites ● The M10 expansion bolts used for securing an outdoor unit have been prepared. ●...
Page 142: Exhausting Nitrogen From An Indoor Unit
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-46 Installing an outdoor unit NO TE It is recommended that the NetCol500-A021 outdoor unit be secured to the concrete foundation using M8 expansion bolts. ----End 4.2.6.4 Exhausting Nitrogen from an Indoor Unit...
Page 143 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-48 Open a stop valve plug Step 3 Remove the needle valve bonnets at the gas pipe and liquid pipe of the indoor unit, connect rubber hoses and pressure gauges to the needle valves on the gas...
Page 144: Connecting The Refrigerant Pipe
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Step 4 After the airflow sound disappears, reinstall the needle valve bonnet. ----End 4.2.6.5 Connecting the Refrigerant Pipe 4.2.6.5.1 Laying Out Pipes Inside a Cabinet The gas pipe and liquid pipe used inside cabinets have been delivered to the site...
Page 145 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-51 Top pipe routing inside the converged cabinet ● (Optional for installing the second smart cooling product) Laying out pipes inside the IT cabinet Remove the ten cable rings from the side-routed pipe in the rear of the IT...
Page 146 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-53 Top pipe routing inside the IT cabinet Bottom Pipe Routing ● Laying out pipes inside the converged cabinet Figure 4-54 shows the pipe layout. Figure 4-54 Bottom pipe routing inside the converged cabinet ●...
Page 147: Laying Out Pipes Outside A Cabinet
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-55 Bottom pipe routing inside the IT cabinet 4.2.6.5.2 Laying Out Pipes Outside a Cabinet Prerequisites Check that the nuts on the needle valve and rear cover of the smart cooling product are tightened.
Page 148 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide NO TICE ● When connecting the indoor and outdoor units, seal the pipe after the welding break exceeds 15 minutes to prevent dust and water from entering the pipe. ● To avoid burning the bottom panel, top panel, side panel, internal components, other pipes, thermal insulation foam, power cables, and labels, take protective measures, such as spreading a piece of wet cloth, around the welding position.
Page 149 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-57 Support positions for refrigerant pipes NO TE Ask the site engineering personnel to prepare and install pipe supports. For details about the pipe support requirements, see Pipe Support 4.2.6.1...
Page 150 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-58 Connecting indoor unit stop valves CA UTION Wrap the stop valves of the liquid pipe and gas pipe, and the connecting pipe for the stop valves with thermal insulation foam (thickness: 5 mm).
Page 151: Connecting Water Pipes
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Step 4 Take out the outdoor unit stop valve pipe from the outdoor unit fitting bag and connect the pipe by referring to Step 3.1, Step 3.2, and Step 3.3.
Page 152: Optional) Connecting The Humidifier Water Inlet Pipe
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-60 Holes in the smart cooling product (1) Water inlet hole (2) Strong-current cable hole (3) Water outlet hole (4) Signal cable hole (5) Gas pipe stop valve (6) Liquid pipe stop valve 4.2.6.6.1 (Optional) Connecting the Humidifier Water Inlet Pipe...
Page 153 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-61 Connecting a water inlet pipe (1) Outer thread connector: G (2) Adapter with inner screw (3) Pipe: matched with the 3/4 inch, reserved for the smart threads: G 3/4 inch. Plastic...
Page 154 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide NO TICE The other end is a reserved G 1/2 inch connector with inner screw threads. Connect the other end to a hose or rigid pipe based on site requirements.
Page 155: Connecting The Condensate Drainpipe
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-64 Bottom routing of the water inlet pipe NO TICE After routing water pipes, secure them to the pipe assembly using cable ties, and seal the cable hole using firestop putty.
Page 156 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-65 Connecting a drainpipe (1) Drainpipe connector: BSPT (2) Rigid pipe conversion (3) Rigid pipe: made of PP-R or 1/2-inch, delivered with the adapter: BSPP 1/2 inch, other material...
Page 157 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-66 Connecting a drainpipe Step 2 Secure the check valve and sheet metal to the right rack rail of the cabinet, as shown in Figure 4-67. Step 3 Connect the top drainpipe, as shown in Figure 4-67.
Page 158 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-67 Top routing of the drainpipe ----End Bottom Pipe Routing Step 1 Take out a drainpipe connector from the fitting bag and put the connector on the other end of the drainpipe, as shown in Figure 4-68.
Page 159 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-68 Connecting a drainpipe Step 2 Route the bottom drainpipe. NO TICE ● The smart cooling product fitting bag contains drainpipe connectors. Choose hoses or rigid pipes based on site requirements.
Page 160: Injecting Nitrogen To Preserve Pressure
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-69 Bottom drainpipe routing NO TICE After routing water pipes, secure them to the pipe assembly using cable ties, and seal the cable hole using firestop putty. ----End 4.2.6.7 Injecting Nitrogen to Preserve Pressure...
Page 161 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Procedure Step 1 Open the stop valves for the gas pipe and liquid pipe of the indoor unit. NO TICE Before opening the indoor unit stop valves, ensure that the stop valves for the gas pipe and liquid pipe of the outdoor unit are closed.
Page 162: Connecting Cables
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Step 4 If welding defects exist, locate and repair the leak point. If the pressure does not change, exhaust the nitrogen through the injection needle valves. ----End 4.2.6.8 Connecting Cables The indoor unit uses the single-phase power supply from the smart cooling product control unit.
Page 163 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-73 Electrical ports on the indoor unit (1) Electric heater contactor (required if an (2) Wiring terminals for customer electric heater is configured) (3) Fan fuse base (4) Power transfer terminal for fan...
Page 164 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-74 Cable connections to the smart cooling product Table 4-9 Cable connection description Cable Name From Cable Specifications Outdoor unit L (converged cabinet L, N, and PE 3 x 6 mm...
Page 165 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Cable Name From Cable Specifications Control unit X1.1, X1.2, X1.3, and OUT1 port on output power FU1-FU3 ports on the the control cable indoor unit unit J3 cable X101, X102, X103, and...
Page 166 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide The following figures show the power and signal cable routing of indoor units. ● Figure 4-75 shows the power and signal cable routing of the second indoor unit. Figure 4-75 Cable routing of the second indoor unit ●...
Page 167: Vacuumization
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-76 Cable routing of the third indoor unit 4.2.6.9 Vacuumization Prerequisites ● Check that all pipe connectors are correct, and the refrigerant pipe tilts and has supports. ● All pipes have been checked for leaks, and all pipes are not bent by a large angle.
Page 168 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-77 Vacuumization (1) Vacuum pump (2) Pressure gauge (3) Gas pipe needle (4) Liquid pipe needle valve valve Step 2 In the beginning, the vacuum pump makes loud noises and exhausts white smoke from the exhaust vent.
Page 169: Installing Power Supply And Distribution Devices
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide NO TICE ● After the outdoor unit stop valve is opened, the refrigerant in the outdoor unit flows to the engineering pipe and indoor unit pipe. When performing other operations, be careful to prevent refrigerant from spraying out.
Page 170: Installing A Pdu2000
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide NO TICE ● The weight of an ESM-48100B1 is about 44 kg. Check the load-bearing capability of the rack tray before installation. ● The depth of an ESM-48100B1 is 396 mm. Check the rack depth before installation.
Page 171 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Procedure Step 1 (Optional) Install a half-height PDU2000. Open the rear door of the cabinet. Secure the half-height PDU2000 to the installation position using screws. Figure 4-80 Installing a PDU2000 (in the Converged Cabinet with lithium...
Page 172 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-81 Installing a PDU2000 (in the IT cabinet with the second or third smart cooling product) Step 2 (Optional) Install a non-intelligent full-height PDU2000. Open the rear door of the cabinet.
Page 173 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-83 Installing a mounting kit Secure the PDU2000 to the installation position using screws. Figure 4-84 Installing a PDU2000 Step 4 (Optional) Install a horizontal PDU2000. Open the rear door of the cabinet.
Page 174: Optional) Installing An Ats Subrack
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-85 Installing a PDU2000 (in the Converged Cabinet with lithium batteries) ----End 4.2.7.3 (Optional) Installing an ATS Subrack Install guide rails. Install the subrack. Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd.
Page 175: Optional) Installing Cable Troughs
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-86 Installing an ATS Subrack NO TE The ATS subrack needs to be installed at the 33–40 U position in the IT cabinet to the right of the converged cabinet.
Page 176: Installing A 600 Mm Wide Cable Trough
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-87 Binding plate installation position Procedure Step 1 Remove the two M5 tapping screws from the binding plate and then remove the binding plate from the cabinet top. Figure 4-88 Removing a binding plate Step 2 Remove other binding plates in the same way.
Page 177 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-89 600 mm wide cable trough (1) Partition plate (2) Side panel (3) Supporting plate When installing cable troughs, be aware of PDU2000 cables at the top of the cabinet: ●...
Page 178 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-91 Rotating the vertical plate by 90 degrees Step 3 Install the other vertical plate into the mounting hole in the second row counting from the front door to the rear door in the same way. Tighten one M5x10 tapping...
Page 179 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-93 Installing a supporting plate Step 5 Install a partition plate. Press both sides of the V-shaped partition plate with hands to decrease the angle to a proper degree, and clamp the clasps at the...
Page 180: Optional) Installing An 800 Mm Wide Cable Trough
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-95 Installing an interconnecting wrench (1) Interconnecting wrench Step 8 Install the cable trough above the rear door in a similar way. ----End 4.2.8.3 (Optional) Installing an 800 mm Wide Cable Trough Install an 800 mm wide cable trough (BOM number: 21501140) on the top of an 800 mm wide cabinet.
Page 181: Installing A Pad
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-96 Removing an ECC800-Pro main control module Figure 4-97 Installing a SIM card Step 3 Reconnect the signal cable to the panel of the ECC800-Pro main control module based on the recorded position.
Page 182 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Context The PAD needs to be installed on the door of the Converged Cabinet. Figure 4-99 PAD installation position (1) PAD installation position Procedure Step 1 Adjust the width and height of the PAD support to match the dimensions of the PAD to be installed.
Page 183 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-101 Removing the nut Step 3 Route the PAD power cable to the cable hole in the PAD mounting support and connect the cable to the PAD. Step 4 Adjust the feet above the PAD support and clamp the PAD to the PAD support.
Page 184: Optional) Installing A Lan Switch
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide 4.2.9.3 (Optional) Installing a LAN Switch Context The LAN switch needs to be installed in the 38 U position on the top of the front of the IT cabinet to the right of the Converged Cabinet.
Page 185: Installing T/H Sensors And Aisle Temperature Sensors (02312Pbl)
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-104 Installing a LAN switch Step 3 Connect the LAN switch power cable to the PDU2000. Step 4 Connect any port among the 1–24 ports of the LAN switch to the WAN_1 port on the ECC800-Pro using a network cable.
Page 186 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-106 T/H sensor configuration ● If the total number of IT cabinets and network cabinets is greater than six, four aisle T/H sensors are configured. Install two sensors on the front and rear right posts of the Converged Cabinet, and the other two on the front and rear right posts of the IT cabinet where the second or third NetCol is installed.
Page 187: Installing T/H Sensors
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-109 Temperature sensor configuration (example 1) Figure 4-110 Temperature sensor configuration (example 2) 4.2.9.4.2 Installing T/H Sensors Procedure Step 1 Install T/H sensors. Open the front door of a cabinet.
Page 188 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-111 Installing an T/H sensor in an aisle Step 2 Set device addresses for the T/H sensors. Set the device address for a T/H sensor by operating the DIP switch on the sensor.
Page 189 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Table 4-10 T/H sensor Dip switch T/H Sensor Toggl Toggl Toggl Toggl Toggl Toggl Toggl Toggl Address Switc Switc Switc Switc Switc Switc Switc Switc Step 3 Connect the communications cables to the T/H sensors.
Page 190: Optional) Installing Temperature Sensors
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-114 Cable connections to T/H sensors (1) ECC800-Pro (2) T/H sensor 2 (3) T/H sensor 1 (4) Temperature sensor ----End 4.2.9.4.3 (Optional) Installing Temperature Sensors Procedure Step 1 Bind the temperature sensors to the right posts of the front and rear doors about 1.6 m above the floor using cable ties.
Page 191: Installing Remote T/H Sensors (33010516) For Smart Cooling Products
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-115 Installing temperature sensors ----End 4.2.9.5 Installing Remote T/H Sensors (33010516) for Smart Cooling Products T/H sensor configuration depends on the number of smart cooling products. (For example, if there are three smart cooling products, three T/H sensors are configured.)
Page 192 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-116 T/H sensor configuration A: Position for installing the T/H sensor for the NetCol at the bottom of the Converged Cabinet, 28 U ● Installing T/H sensors when two NetCols are configured (Optional) Figure 4-117 T/H sensor configuration ●...
Page 193: Installing T/H Sensors
DIP Switch Sequence No. NO TICE ● The default addresses of T/H sensors purchased from Huawei are 1. ● After the addresses are set, set Cold-aisle sensor to Enable on the ECC800-Pro WebUI. Otherwise, the T/H sensors will not work. The path is as follows: Monitoring >...
Page 194: Installing A Camera
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-120 Connecting the T/H sensor cable ----End 4.2.9.6 Installing a Camera Prerequisites ● A camera and tools for installing it have been prepared. ● The network cable used for camera communication has been prepared.
Page 195 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-121 Installing a Camera NO TE This camera model provides triple-axis adjustment design. Connect the auxiliary video cable delivered with the camera to a display device such as the monitor. Rotate the camera 0-355 degrees horizontally, 0-75 degrees vertically, or 0-355 degrees in the revolving direction to achieve an appropriate angle.
Page 196 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-123 Installing a camera mounting plate Step 3 Connect the camera monitoring cable. Connect one end of a network cable to the Ethernet port on the camera and the other end to any network port on the smart ETH gateway (with PoE power supply).
Page 197 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-124 Adjusting focal length (1) Lens adjustment pole NO TE Use a flat-head screwdriver to loosen the screw during first adjustment of focal length. Step 5 Before installing the inner cover, adjust the infrared light panel of the camera to...
Page 198: Installing An Ivs1800
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-126 Installing a front cover ----End 4.2.9.7 Installing an IVS1800 Context By default, the IVS1800 is delivered without disks. After the IVS1800 is delivered to the site, install hard disks as required and then install the IVS1800 in the cabinet.
Page 199 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Place the hard disks with ports facing upwards and align the screw holes on the hard disk tray with the hard disks and fasten the screws. Before the installation, ensure that the fastener of the hard disk tray is on a different side from the hard disk port, as shown in the lower left figure.
Page 200 If the vents are blocked, change the guide rails. ● Huawei provides guide rails that can be adjusted from 500 mm to 800 mm for additional purchase if required for IVS1800 installation.
Page 201 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-133 Installing a cage nut Install guide rails. Horizontally place a guide rail to the installation location through the positioning block at the front of the guide rail and the positioning hook at the rear of the guide rail.
Page 202 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-135 Installing a filler panel for guide rails Install the cage nuts that secure the IVS1800. The cage nut installation locations are the first and sixth holes along the guide rails, as shown in the following figure.
Page 203: Installing A Smart Eth Gateway And An Eth Converter
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-137 Installing mounting ears Install the IVS1800 in the cabinet. 1. Lift the device from both sides and carefully position it at the front of the cabinet. 2. Lift the device slightly above the guide rails, gently place it on the guide rails, and then slide it into the cabinet until the mounting ears of the subrack contact the mounting bars at the front of the cabinet.
Page 204 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Context A smart ETH gateway can be installed in the following two positions based on the project conditions: ● If the M-shaped cable troughs are deployed for the smart module, install the smart ETH gateway on the M-shaped cable trough on the top of the cabinet.
Page 205 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-141 Position 3 for installing a smart ETH gateway (1) Smart ETH gateway The methods for installing a smart ETH gateway on the three positions are similar. This section describes how to install a smart ETH gateway on the M-shaped cable trough.
Page 206: Routing The Cable To A Wlds900 Water Sensor
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide 4.2.9.9 Routing the Cable to a WLDS900 Water Sensor If the water sensor is required, perform the following steps to install it. Context ● The water sensor is composed of the water detection cable (BOM number: 33010445), water detector (BOM number: 33010352), and conversion cable (packed with the water detector).
Page 207 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-144 Water sensor (1) Water detector (2) Conversion cable end A, (3) Conversion cable connected to the water detector (4) Conversion cable end B, (5) Water detection cable end...
Page 208 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide NO TICE Do not contact the water detector cable to metal, for this action will cause a false alarm. Take protective measures when routing a water detector cable. Procedure Step 1 Install the water detector.
Page 209 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-147 Installing a water detector bottom plate Reinstall the water detector cover by referring to Step Step 2 Figure 4-148 shows how to connect the water detection cable to the conversion cable.
Page 210 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-149 Connecting the water detector Step 4 Plan the installation position for the fastener of the water detection cable. Ensure that the water detection cable placed on the fastener is in good contact with the floor.
Page 211: Installing An Electrode Water Sensor
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-151 Securing a water detection cable NO TE If multiple water detection cables are connected in series, connect the male connector of one cable to the female connector of another.
Page 212: Optional) Installing An In-Room Access Actuator
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide 4.2.9.11 (Optional) Installing an In-Room Access Actuator Context ● The BOM number of an access actuator is 52271874. ● It is recommended that the access actuator be installed 0.5 m away from the door edge and 2.2 m above the floor at the inner side of a door.
Page 213 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-154 Drilling holes and installing expansion anchor bolt sleeves (1) Expansion anchor bolt (2) M6 nut (3) Spring washer (4) Flat washer (5) Expansion sleeve (6) Wall (7) Rubber mallet (8) Socket wrench Step 4 Secure the waterproof box to the wall.
Page 214: Optional) Installing An In-Room Double Door Magnetic Lock
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide NO TICE ● Before installing the access actuator, ensure that the clip spring on the back of the actuator is loose. ● Verify that the access actuator indicator faces leftwards so that the indicator status can be observed through the window in the waterproof box cover after the waterproof box cover is reinstalled.
Page 215 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Context ● The BOM number of a double door magnetic lock is 02070261. ● A double door magnetic lock is installed on a room door. Procedure Step 1 Fold the cutout template delivered with the device 90 degrees along the dotted...
Page 216 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-160 Installing a magnetic lock Step 5 Route the electronic lock cable through the cable hole, and secure the electronic lock using a hex key, as shown by (2) in Figure 4-160.
Page 217: Optional) Installing An In-Room Single Door Magnetic Lock
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-162 Installing the magnet (1) Rubber pad Step 7 (Optional) Adjust the magnet. If the magnet cannot attract the door properly after power-on, place a magnetized metal part near the magnet to check whether the magnet provides a proper magnetic force.
Page 218 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-163 Marking mounting holes (1) Door frame (2) Cutout template (3) Door panel Step 3 Remove the hoisting strip using the delivered hex key. NO TE Two hex socket screws need to be removed in this step.
Page 219 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-165 Installing a magnetic lock Step 5 Remove the small cover from the magnetic lock, and route the cable out of the cable hole, as shown in Figure 4-166.
Page 220: Optional) Installing An In-Room Fingerprint And Card Reader With A Keypad
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-167 Installing positioning pins of a magnet Insert the assembled magnet into the positioning holes in the door, and secure the magnet to the door using the screws and rubber pad delivered...
Page 221 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide ● It is recommended that the device be installed outside a room 1.4-1.6 m above the floor. ● Do not install the product in a place with heavy dust or exposed to sunlight.
Page 222: Optional) Installing An In-Room Fingerprint And Card Reader
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide NO TE The fingerprint and card reader with a key pad is connected to the access actuator by a network cable. Step 5 Check that cables are correctly connected. Step 6 Secure the fingerprint and card reader with a keypad to the baseplate, as shown...
Page 223: Optional) Installing An In-Room Card Reader With A Keypad
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-172 Marking mounting holes (unit: mm) Step 3 Install the baseplate, as shown by (3) in Figure 4-171. Step 4 Route the fingerprint and card reader cable through the cable hole in the...
Page 224 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-173 Installing a card reader with a keypad Step 2 Mark the mounting holes using a marker, and drill holes using a hammer drill. Figure 4-174 Marking mounting holes (unit: mm)
Page 225: Optional) Installing An In-Room Exit Button
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide 4.2.9.17 (Optional) Installing an In-Room Exit Button Context The BOM number of an exit button is 52220135. Procedure Step 1 Remove the exit button cover using a flat-head screwdriver. Step 2 Remove screws from the exit button, remove the base, and mark mounting holes using the base and a marker.
Page 226: Optional) Installing An In-Room Camera
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Remove screws from the emergency door release button using a Phillips screwdriver, as shown by (1) in Figure 4-175. Remove the glass panel of the emergency door release button, as shown by...
Page 227: Cable Routing
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide For the detailed installation method, see documents delivered with the camera. 4.3 Cable Routing 4.3.1 System Cabling Rules Attaching Cable Labels NO TICE A cable label must be consistent with the corresponding IT cabinet number.
Page 228 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Keep a large number of cables neat and appealing in the network cabinet by using cable organizers. Move the excess parts of cables in unnoticeable positions. See Figure 4-179. Figure 4-179 Cable organizer Route and lay out a large number of cables in different areas to ensure neat cabling and facilitate cable search and maintenance.
Page 229 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide – Common cable: R ≥ 3d – Optical cable: R ≥ 40 mm NO TE R indicates the bend radius, and d indicates the cable diameter. Reserve slack at cable connection positions to facilitate connection and disconnection and to prevent stress.
Page 230 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Table 4-12 Cable binding interval Cable Diameter (mm) Binding Interval (mm) < 10 10–30 > 30 Bind cables with a moderate force and ensure that cables are not misshapen to prevent compromising the signal quality.
Page 231: Cable Routes
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-185 Direction for securing cable ties 4.3.2 Cable Routes General Cable Route NO TE When routing cables, leave a distance of at least 100 mm between power cables and signal cables.
Page 232 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-186 Cable routes (1) Power cable (2) Signal cable The Converged Cabinet fitting bag contains 70 plastic cable ties that can be installed on holes at the top of the cabinet for binding cables, as shown in Figure 4-187.
Page 233 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Smart ETH Gateway Cable Route Figure 4-188 Smart ETH gateway cable route (1) Signal cable (2) Power cable Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd.
Page 234: Power Cable Routing
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide 4.3.3 Power Cable Routing Figure 4-189 Power cable routing (1) PDU2000 power cables (2) Mains input power cables 4.3.4 Grounding the Smart Module Connect the general ground point in each cabinet to the general ground bar in the Converged Cabinet.
Page 235 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-190 Converged Cabinet ground bar Figure 4-191 Cabinet ground point Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd.
Page 236: Cable Connections To The Power Supply And Distribution System
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-192 Grounding the Smart Module (1) General ground bar 4.3.5 Cable Connections to the Power Supply and Distribution System 4.3.5.1 Top Cable Routing 4.3.5.1.1 Cable Routing Description Figure 4-193 Cable holes for routing cables over the top of the Converged Cabinet...
Page 237 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide (5) Holes for battery power cables and output power cables Figure 4-194 Cable holes for routing cables over the top of the IT Cabinet (1) Holes for pipes and cables...
Page 238: Optional) Connecting Cables To The Ats Subrack
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-196 Cutting a notch in a wire bushing Cables can be bound to the side panel or mounting bar of the Converged Cabinet. Figure 4-197 Cable binding position inside the Converged Cabinet (1) Place binding cables routed across the cabinet interior 4.3.5.1.2 (Optional) Connecting Cables to the ATS Subrack...
Page 239: Connecting Input Power Cables To The Converged Cabinet
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-198 Connecting cables to the ATS subrack (1) ATS I input (2) ATS II input (3) ATS output (to the Converged Cabinet) 4.3.5.1.3 Connecting Input Power Cables to the Converged Cabinet...
Page 240: Connecting Output Power Cables To The Converged Cabinet
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-199 Connect input power cables to the PDU. ----End 4.3.5.1.4 Connecting Output Power Cables to the Converged Cabinet Context NO TE Cable ● For details about cable connection positions in the Converged Cabinet, see the Connection Diagram .
Page 241 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-201 Preparing an OT terminal (1) Cable (2) Heat shrink tubing (3) OT terminal (4) Hydraulic pliers (5) Heat gun Procedure Step 1 Connect output power cables to the PDU.
Page 242: Bottom Cable Routing
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-203 Connecting output power cables to the PDU (for outdoor units of smart cooling products in Asia, Europe, and Africa) ----End 4.3.5.2 Bottom Cable Routing Cables connect to the same positions on the power distribution subrack irrespective of whether cables are routed through the top or bottom of the Converged Cabinet, but the cable routes inside the cabinet are different.
Page 243 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-204 Cable holes for routing cables through the bottom of the Converged Cabinet (1) Holes for the smart cooling product water (2) Hole for the signal cable and water sensor...
Page 244: Connecting Pdu2000 Power Cables
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-205 Example of bottom cable routing 4.3.5.3 Connecting PDU2000 Power Cables Context If the PDU2000 is not provided with industrial connectors, connect the PDU2000 cables and lay out the cables on the cabinet top.
Page 245 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-206 Connecting PDU2000 cables Step 2 Remove the rodent-proof mesh from the top of the cabinet, use diagonal pliers to cut an opening that allows cables to run through, and take out the PDU2000 cables through the opening.
Page 246: Connecting Signal Cables For The Intelligent Pdu2000
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-207 Connecting a PDU2000 power cable ----End Follow-up Procedure Before connecting the power plug of a device to the PDU2000, loosen the locking device on the PDU2000. After connecting the power plug, tighten the locking device.
Page 247 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide NO TICE ● Connect the ETH converter for the intelligent PDU2000 based on site requirements. ● Connect cables from the ETH converter to the smart ETH gateway based on site requirements. The figure is for reference only.
Page 248 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-209 Wiring sequence for a standard network cable port Table 4-13 Function description Color Function Description Orange-and-white RS485-A Orange RS485-B Green-and-white Blue RS485-A Blue-and-white RS485-B Green Brown-and-white Brown Issue 01 (2021-02-05)
Page 249: Preparing Power Cables
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide 4.3.5.5 Preparing Power Cables NO TICE ● You are advised to install a disconnector for the UPS input. ● A 2-pole disconnector must be used if the UPS is used to power IT systems.
Page 250: Management System Cable Connection
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide ● Input power cables from batteries to the BCB box need to be connected. Cables between the BCB box, busbars, and UPS are preinstalled. ● The actual number of batteries depends on the onsite configuration. Excess pre-installed battery cables need to be disposed of.
Page 251: Connecting A Monitoring Cable To The Smart Eth Gateway
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Procedure Step 1 Install cabinet electronic clasp lock cables according to the cabinet electronic clasp lock layout. The cabinet electronic clasp locks of odd- and even-numbered cabinets have been cascaded in hand-in-hand mode respectively.
Page 252: Connecting Ivs Cables
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-212 Ports on a smart ETH gateway (1) PWR_IN cascading power (2) FE_1 cascading signal port (3) PoE_1–2 ports port (4) PoE_3–4 ports (5) 48V_OUT1 power output (6) 48V_OUT2 power output...
Page 253: Connecting A Cable To The Wlds900 Water Sensor
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Step 2 Connect one end of the network cable to any GE network port on the IVS. Figure 4-213 IVS Rear panel Step 3 Connect one end of the power cable to the input power port on the power module and the other end to the PDU2000 in the cabinet.
Page 254: Optional) Connecting Cables For The In-Room Access Control System
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Figure 4-214 Routing a signal cable ----End 4.3.6.5 (Optional) Connecting Cables for the In-Room Access Control System Prerequisites ● The required cables have been prepared. ● It is recommended that cables of the in-room access control system be routed through a trough in a wall.
Page 255 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Context Figure 4-215 Description of ports on the access actuator (1) 48 V power port (2) PoE port (3) RS485 port (COM2) (4) RS485 port (COM1) (5) Address DIP switch...
Page 256: Optional) Connecting Cables To The Ats Subrack
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Connect the emergency door release button to the access actuator using a cable. Connect the emergency door release button to the single/double door magnetic lock using a cable. Figure 4-216 Connecting cables for the in-room access control system...
Page 257: Verifying The Installation
FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Context Figure 4-217 shows the ports on the ATS subrack. Figure 4-217 Ports on the ATS subrack (1) RS485 port (2) Fire port (fire extinguishing (3) Diesel Generator port (DG...
Page 258 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Item Check That Check Result The fasteners for the liquid □ Passed □ Failed level detector are secured. The low liquid level detector □ Passed □ Failed functions flexibly. Table 4-16 Outdoor unit installation checklist...
Page 259 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Cabinet Installation Check Table 4-18 Cabinet installation check items Check That Check Result The cabinet layout position is consistent with the □ Passed □ Failed equipment room layout diagram. All bolts are tightened, especially the bolts used □...
Page 260 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Check That Check Result Routed cables should be convenient for future □ Passed □ Failed maintenance and expansion. All labels at the cable ends are clear. □ Passed □ Failed The excess section of a cable strip is cut evenly.
Page 261 FusionModule800 Smart Small Data Center User Manual 4 Installation Guide Check That Check Result DIP switches on devices are correctly set. □ Passed □ Failed Customer Sign: Check Data: Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd.
Page 262: Power-On Commissioning
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Power-On Commissioning 5.1 Power-On Commissioning for the Power Supply and Distribution System Prerequisites The installation has been verified. NO TICE Configure an upstream protective device that meets the overload and short-circuit protection requirements for the cabinet.
Page 263: Ups Power-On Commissioning
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning NO TE ● Perform this step if the ATS subrack is configured. ● If the ATS is not in I (primary input) On state, operate the handle on the ATS to switch to I (primary input).
Page 264 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning to access the login screen for parameter settings. The initial password is 123. Enter the correct password to access the UPS setting mode. Figure 5-1 Password setting screen Figure 5-2 Bypass mode Step 2 Set the battery capacity.
Page 265: Shutting Down A Ups
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Figure 5-3 Normal mode Step 4 After you ensure that the UPS runs properly, switch on the AC output circuit breaker Q for the UPS to start the load. ----End 5.1.1.2.2 Shutting Down a UPS...
Page 266: Parallel System Operations
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Figure 5-4 EPO cable connection on a single UPS 5.1.1.3 Parallel System Operations 5.1.1.3.1 Starting the UPSs Using Mains Power Procedure Step 1 Switch on the external battery circuit breaker (if any).
Page 267: Shutting Down A Parallel System
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Step 3 Operate the UPSs one by one to set the number of parallel output UPSs. Press SELECT, go to the setting screen, and set parallel system parameters. Press ON/ MUTE+SELECT to return to the standby screen.
Page 268 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Figure 5-6 Wiring diagram for parallel communications cables and parallel current equalization cables (using two UPSs connected in parallel as an example) Step 3 Switch off the external battery circuit breaker (if any), or disconnect battery power cables for the UPS.
Page 269: Performing Epo
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning 5.1.1.3.3 Performing EPO Turn on the EPO switches (provided by the customer). The UPSs enter the EPO state. That is, the UPSs shut down the inverters, and do not transfer to the bypass mode.
Page 270: Performing Initial Configuration
The electric heating belt of the crankcase starts working. Before starting the compressor, ensure that the electric heating belt of the crankcase has been preheated for more than 12 hours. Otherwise, Huawei will not repair the compressor. Step 2 Commission the system after the electric heating belt of the crankcase has been preheated for 12 hours.
Page 271: Setting Teamwork Control Parameters
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning NO TE 1 in NetCol5000-A1 is variable and subject to changes with the smart cooling product connection sequence. The displayed value prevails. Step 3 Set the DIP switch address of the T/H sensor, see Set addresses.
Page 272 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Parameter Smart Cooling Product No. Number of air conditioners in this group Number of running air conditioners in this group Rotation Enable Rotation period The parameter can be set by the day ranging from one day to 30 days as required.
Page 273 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Parameter Smart Cooling Product No. Rotation time The parameter can be set by the hour ranging from midnight to 23:00 as required. Requirement Competitive running control avoidance Table 5-3 Setting teamwork control parameters for four smart cooling products Parameter Smart Cooling Product No.
Page 274: Setting The Maximum Outdoor Fan Speed
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Parameter Smart Cooling Product No. Rotation time parameter can be set by the hour ranging from midnight to 23:00 as required. Requirement Competitive control running avoidance Step 4 After setting teamwork control parameters, choose Monitoring > Cooling >...
Page 275 (L). L should be less than or equal to 80 metes. If L exceeds 80 meters, contact Huawei technical support. Table 5-4 Equivalent length of pipe assemblies...
Page 276 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning CA UTION Wear antifreeze gloves when performing refrigerant related operations. The following are the tools used for commissioning and refrigerant charging: ● Charging tools: pressure gauge (measuring range ≥ 4.0 MPa), leather hose (withstanding a pressure of at least 4.5 MPa), vacuum pump...
Page 277 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning On the Diagnostic Mode Parameters page, set Wet film humidifier manual control to 100% and click Submit. The water inlet valve automatically opens to inject water to the wet film.
Page 278 Tighten the needle valve nuts when the charge is complete. Check whether a needle valve leaks by applying soapy water to the valve vent or using a halogen leak detector. If it leaks, contact Huawei technical support. Figure 5-8 Charging refrigerant...
Page 279: Management System Power-On Commissioning
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Step 9 Choose Controls > Control Information, set Diagnostic mode to Exit, and click Submit. ----End Exception Handling Step 1 Check that you have exited the diagnostic mode on the ECC800-Pro WebUI.
Page 280 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning NO TICE ● In ECC800 V100R002C10 and earlier versions, the default IP address of port WAN_1 is 192.168.1.10. ● The WAN_1 port IP address cannot be set to an IP address in any of the following network segments: 192.168.0.x, 192.168.245.x, 192.168.246.x and...
Page 281 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Figure 5-9 Setting internet options Step 4 Set Internet Explorer parameters. When you use Internet Explorer for access, set Internet Explorer to ensure the normal display of and operations on the WebUI. Choose Tools >...
Page 282 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Figure 5-11 Setting parameters NO TE When switching between different versions of the ECC800-Pro on your PC, you are advised to clear the historical Internet Explorer cache. Failing to do so may cause some information missed or exception after login.
Page 283: Preparations And App Login
Save. Install the Huawei AppGallery. If the downloaded file exists in the drop- down list box, tap the file to install the Huawei AppGallery. If the downloaded file does not exist in the drop-down list box, choose File > Local on the desktop, find the Download folder, and tap the Huawei AppGallery installation package.
Page 284 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning NO TICE After you open the Huawei AppGallery, select NOT NOW if "New Version" is displayed. ● Log in to the ECC800-Pro WebUI using a PC. Choose Maintenance > App Obtaining, scan QR code, and save the app installation package to the PC or a path on the mobile storage device.
Page 285: Initial Startup Password Authentication
WebUI and app at the same time. If you use the same user name to log in to the WebUI and app at the same time, either of them will be forcibly logged out. ----End 5.3.3 Initial Startup Password Authentication When the system type is FusionModule800, perform the following steps to configure it. Context ●...
Page 286 Save. Install the Huawei AppGallery. If the downloaded file exists in the drop- down list box, tap the file to install the Huawei AppGallery. If the downloaded file does not exist in the drop-down list box, choose File > Local on the desktop, find the Download folder, and tap the Huawei AppGallery installation package.
Page 287: How Can I Set The Date And Time
Use the Service Expert app to authenticate the startup password. Open the mobile phone app or pad app, and log in to the FusionModule800 device login page using the administrator account. Ensure that the IP address is 192.168.245.10, the default administrator name is admin, and the default password is Changeme.
Page 288: Adding A Southbound Device
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Step 3 (Optional) If you want to use the NTP server for time synchronization, select NTP server sync. Set NTP primary server IP, NTP backup server IP, Port number, and Sync interval (min), and click Submit.
Page 289: Commissioning Sensors
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Procedure Step 1 Add a UPS2000G-L. Log in to the ECC800-Pro WebUI as an administrator. Add a UPS2000G-L. Table 5-8 Adding a UPS2000G-L Path Parameter Setting Choose Device Select UPS from the drop-down list box.
Page 290: Commissioning The T/H Sensor (Bom Number: 02312Pbl)
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Context ● If the sensor is prefabricated, only check its settings. ● The actual value prevails. Only the method of the parameter settings is described. Procedure Step 1 Set smoke sensor parameters.
Page 291 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Prerequisites One end of the straight-through cable has been connected to the RS485_IN port on the T/H sensor, and the other end has been connected to the COM1/12V port on the ECC800-Pro.
Page 292 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Table 5-11 Adding a T/H sensor Path Parameter Setting Choose Device Select Sensor from the drop-down list box. System attribute Settings > Device type Select T/H sensor from the drop-down list Device box.
Page 293: Commissioning The Wld900 Water Sensor
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Table 5-13 Default alarm thresholds for T/H sensors Signal Default Value High temperature alarm threshold 35.0°C Low temperature alarm threshold 5.0°C High humidity alarm threshold 85.0% RH Low humidity alarm threshold 15.0% RH...
Page 294: Commissioning Cabinet Electronic Clasp Locks
WebUI. automatically. ----End 5.3.9 Commissioning Cabinet Electronic Clasp Locks When the system type is FusionModule800 and the cabinet electronic clasp locks are installed, perform the following steps to configure it. Prerequisites ● The cabinet electronic clasp locks of odd- and even-numbered cabinets have been cascaded in hand-in-hand mode respectively.
Page 295 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Procedure Step 1 (Optional) Check whether the cabinet door lock is leveled to 2000 (+3) mm. If not, adjust it. Step 2 (Optional) If the cabinet door still cannot be opened after step 1 is performed, adjust the position of the cabinet electronic clasp lock by using the slotted holes until the cabinet door can be opened and closed properly.
Page 296 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Address Toggle Toggle Toggle Toggle Toggle Toggle Switch 1 Switch 2 Switch 3 Switch 4 Switch 5 Switch 6 Step 4 Add the cabinet electronic clasp locks. Log in to the ECC800-Pro WebUI as an administrator.
Page 297 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning running properly, and whether the parameter settings are consistent with the device parameters. Repeat Step 4.3–Step 4.4 to connect other cabinet electronic clasp locks. Step 5 Commission the cabinet electronic clasp locks.
Page 298 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Figure 5-16 Adjusting the installation position Check whether there is interference between the lock tongue and the cabinet post. If they interfere with each other, adjust the installation position of the lock tongue.
Page 299 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Figure 5-17 Adjusting the installation position Check whether there is interference between the castors and the door sill at the bottom of the cabinet. If they interfere with each other, remove the fastener that secures the castors.
Page 300: Event Notification
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Figure 5-18 Removing the fastener NO TICE To close the door, rotate the lock handle vertically downwards. If the door cannot be opened or closed properly, check the following items: ●...
Page 301 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Procedure Step 1 Choose System Settings > Event Notification. Step 2 Set related outbox parameters. Set related parameters in the Outbox Settings area on the Mailbox Settings page. If the address type of the outbox is Domain name, choose System Settings >...
Page 302 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Table 5-18 Main parameters on the outbox configuration page Email Email Mailbox Server Encryption Remarks Type Server IP Address Mode and Domain SMTP port Name Sina Mail smtp.sina.co How to obtain: Non- ●...
Page 303 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Figure 5-20 Adding an email address to receive emails NO TE Click Test to check whether the added mailbox is available. If it is available, Successfully to send the test email. is displayed. If it is unavailable, Failed to send the test email. is displayed.
Page 304 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Figure 5-21 Adding a mobile number NO TE Click Test to check whether the added mobile phone number is available. If it is available, Successfully to send the test short message. is displayed. If it is unavailable, Failed to send the test short message.
Page 305: Video Management
Before commissioning a camera, prepare the following documents in addition to this document. Table 5-19 Commissioning documents Component Document C3220 Huawei C Series SDC 8.0.1 Product Documentation VCN510/VCN520/ VCN510&VCN520&VCN540 Product Documentation VCN540 IVS1800 IVS1800 8.1.0 Product Documentation Issue 01 (2021-02-05)
Page 306: Networking Scenarios
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning 5.3.11.2 Networking Scenarios Smart ETH Gateway Networking Scenario ● If there are multiple VCNs or IVS1800s for multiple smart modules, you are advised to evenly distribute the cameras to each VCN or IVS1800.
Page 307: Commissioning A Camera (Lan Switch Networking Scenario)
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning 5.3.11.3 Commissioning a Camera (LAN Switch Networking Scenario) 5.3.11.3.1 Commissioning a C3220 Camera Prerequisites If multiple cameras are accessed, retain the connection of one camera and disconnect connections from other cameras. After commissioning the connected camera, commission other cameras in the same way.
Page 308 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Settings Procedure Enable the ActiveX controls and 1. Choose Tools > Internet plug-ins or set them to the prompt Options. mode. The Internet Options dialog box is displayed. 2. Click the Security tab.
Page 309 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Step 2 Commission cameras and set parameters for them. For details, see the delivered documents. Preview the site situation in real time and check the camera coverage through videos. Adjust the lens if necessary.
Page 310 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning On the View tab page, click the General tab to access the General tab page. Select Video and set the parameters, as shown in the following figures. Figure 5-27 Setting primary stream parameters...
Page 311 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Table 5-22 Video stream parameters Parameter Description Primary stream/ Set the stream type based on the site requirements. Secondary – Primary stream: The primary streams feature high stream bit rate, definition, and bandwidth usage. They are applicable to local storage.
Page 312 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Parameter Description Resolution A higher resolution indicates clearer images and higher bandwidth consumption. Bit rate type This parameter is available only when you set Encoding protocol to H.264 or H.265.
Page 313: Commissioning A C3220 Camera (Sd Card Configured)
If the VCN or IVS1800 is not configured and an SD card is chosen, perform the following procedure. Procedure Step 1 Log in to the Huawei camera WebUI. Configure the PC IP address and the camera IP address in the same network segment. Enter the camera IP address (192.168.0.120 by default) in the address bar of the Internet Explorer and press Enter.
Page 314 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Figure 5-29 Setting the IP address of the camera Format the SD card. Choose Settings > System Configuration > Storage Management. The Storage Management page is displayed. Format the SD card.
Page 315 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning NO TE If longer-time video storage is required, set camera parameters according to the following table. Table 5-23 Camera configuration parameters Condition Result Encoding Resolutio Frame I-Frame Minimum Supporte Protocol...
Page 316: Commissioning A Camera (Smart Eth Gateway Networking Scenario)
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Figure 5-32 Setting the alarm linkage policy ----End 5.3.11.4 Commissioning a Camera (Smart ETH Gateway Networking Scenario) 5.3.11.4.1 Commissioning a C3220 Camera Prerequisites ● If multiple cameras are connected, commission one camera first and then commission other cameras in the same way.
Page 317 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Table 5-24 IP address planning Device Internal IP Address External IP Address Camera Example: 192.168.248.50; range: Camera external IP 192.168.248.50–192.168.248.199 address NOTE The 192.168.246.X network segment cannot be set. VCN/ Example: 192.168.248.51;...
Page 318 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Table 5-25 Internet Explorer settings Settings Procedure Disable the proxy server. 1. Choose Tools > Internet Options. The Internet Options dialog box is displayed. 2. Click the Connections tab. 3. Click LAN Settings.
Page 319 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Settings Procedure Set Use Pop-up Blocker to Disable. 1. Choose Tools > Internet Options. The Internet Options dialog box is displayed. 2. Click the Security tab. 3. Select Internet. 4. Click Custom level.
Page 320 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Enter https://192.168.248.10 in the address box of the browser and press Enter to access the WebUI login page. After login, choose System Settings > Video Management. (Optional) Click Search. NO TE –...
Page 321 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning ● Video Type: Select the video type based on the customer's device. ● Link: Enter the external IP address of the camera (for example, https:// external IP address of the camera ).
Page 322 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Choose Settings > Video/Audio/Image > Video, and set camera stream type, primary stream, and secondary stream 1 parameters, as shown in the following figures. NO TICE Set the encoding protocol to H.265.
Page 323: Commissioning A C3220 Camera (Sd Card Configured)
If the VCN or IVS1800 is not configured and an SD card is chosen, perform the following procedure. Procedure Step 1 Log in to the Huawei camera WebUI. Step 2 Format the SD card. Choose Settings > System Configuration > Storage Management.
Page 324 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Figure 5-41 Setting audio and video parameters NO TE If longer-time video storage is required, set camera parameters according to the following table. Table 5-26 Camera configuration parameters Condition Result...
Page 325: Commissioning A Network Video Recorder (Vcn Scenario)
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Step 5 Set the deployment policy. Figure 5-42 Setting the deployment policy Step 6 Set the alarm linkage policy. Figure 5-43 Setting the alarm linkage policy ----End 5.3.11.5 Commissioning a Network Video Recorder (VCN Scenario) 5.3.11.5.1 Logging In to the OMU Portal...
Page 326: Initializing Vcn510 Disks
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Step 2 On the login page, enter the user name admin and preset password Change_Me, and click Log In to enter the OMU portal page. A message is displayed upon the first login indicating that you should change the password.
Page 327 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Figure 5-46 Initializing disks Step 4 Choose whether to create a RAID group. To set disks as a RAID group, select RAID1. To set disks to work independently, select NON-RAID.
Page 328 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Figure 5-47 RAID group status of RAID 1 When two disks are configured, if NON-RAID is selected for the disks, RAID 1 is created for the system partition. Figure 5-48 RAID group status of disks that work independently (two disks) If only one disk is configured, RAID 0 is created for the system partition after disks are initialized.
Page 329: Setting Parameters On The Vcn Webui
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning 5.3.11.5.3 Setting Parameters on the VCN WebUI Prerequisites The description and links in this section are for reference only. For detailed Configuration Guide . For details, see the documentation configuration, see the delivered with the device or obtain the documentation by referring to the "Reference Documentation"...
Page 330 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning NO TE Currently, the VCN and NTP source server must be in the same LAN for NTP synchronization. For details, see Step If the VCN and the NTP source server are not in the same LAN, you need to manually set the time as follows: Choose Local Configuration >...
Page 331 ----End Follow-up Procedure ● (Optional) Set up a VCN stack. For details, log in to the https:// e.huawei.com/, search for the VCN product documentation, open the documentation, and see the section (Optional) Deploying IVS in Stack Mode. ● (Optional) Create a VCN cluster. For details, log in to the https:// e.huawei.com/, search for the VCN product documentation, open the...
Page 332: Setting Parameters On The Vcn Ivs Client
Method 2 1. Log in to the VCN OMU Portal, choose Local Configuration > Basic Configuration, and view Current version. 2. Log in to https://support.huawei.com/enterprise/, and search for Client Package.zip followed by the VCN model (Client Package.zip VCN540 for example). In the search result, click...
Page 333 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Click Log In to access the client home page. A message is displayed upon the first login indicating that you should modify the password. After modifying the password, keep it properly.
Page 334: Commissioning A Network Video Recorder (Ivs1800 Scenario)
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning NO TE If you set the recording plan policy is to All, you do not need to set the recording plan time. Click Next to complete the recording plan setting. When is displayed in the status bar, the recording plan has been set successfully.
Page 335 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Prerequisites For details about the IVS1800 hardware description and installation, see the Quick Start in the corresponding IVS1800 product documentation. For details about the IVS1800 configuration, see the Configuration Guide. For details, see the documentation delivered with the device or obtain the documentation by referring to the "Reference Documentation"...
Page 336 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning NO TE Recording data can be stored only after you install and initialize the disks. Choose Local Configuration > Local Disk. In the upper right corner of the RAID Groups area, click Initial Disk Configure disk initialization.
Page 337 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning NO TE Currently, the IVS1800 and NTP source server must be in the same LAN for NTP synchronization. For details, see 5. If the IVS1800 and the NTP source server are not in the same LAN, you need to manually set the time as follows: Choose Local Configuration >...
Page 338: Setting Parameters On The Iclient
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Step 5 Enable camera NTP synchronization. The camera NTP synchronization function for the server is disabled by default. The camera NTP synchronization function needs to be enabled for the server that connects to the camera.
Page 339 Method 2 1. Log in to the OMU portal, choose Local Configuration > Basic Configuration, and view Current version. 2. Log in to https://support.huawei.com/enterprise/, and search for and choose iClient. In the search result, click the Software Download tab, click the version and patch number corresponding to the current version, and download the software package as required.
Page 340 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Figure 5-64 Logging in to the iClient Select Micro Edge Access. Add an IVS1800. Figure 5-65 Adding a device NO TE – If the iClient and IVS1800 are deployed in the same LAN, set Address to the internal IP address of the IVS1800.
Page 341 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning On the home page of the iClient, click Device Management. Right-click an IVS1800 and choose Camera Access. Figure 5-66 Camera Access Select Auto Batch Access and click Start. Set the IP address segment.
Page 342 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning NO TE – The driver protocol of IPC6325 and C3220 cameras is HWSDK. – The IP address segment indicates the start and end IP addresses of cameras. You can use IP Address and Vendor to filter the required cameras in the camera search result and select the required cameras.
Page 343 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Figure 5-69 Selecting Storage Management Click Storage Policy and configure a storage policy. Figure 5-70 Configuring a storage policy Step 4 Configure a server video recording plan. Select Local mode to log in to the iClient. On the home page, click Device Management.
Page 344: Linkage Control
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Figure 5-71 Server Recording Plan Configure a server recording plan. NO TE If you set the recording plan policy to All, you do not need to set the recording plan time.
Page 345 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Linkage Grouping Table 5-29 FusionModule800 linkage grouping Linkage Default Function Category Status Link When this linkage status is set to on: emergency ● If the smart cooling product communicates ventilation...
Page 346: Linking The Emergency Ventilation With Cabinet Electronic Clasp Lock Open
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Linkage Default Function Category Status Link fire When this linkage status is set to on: control with ● If a fire alarm (dry contact alarm) is generated, the Cabinet rear door of the IT cabinet is opened.
Page 347: Link Fire Control With Lock Open
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Procedure Step 1 Log in to the ECC800-Pro WebUI as an administrator. Step 2 Choose System Settings > Linkage Control. Step 3 Ensure that Enable linkage control function is Yes.
Page 348: Optional) Neteco Management
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Step 3 Ensure that Enable linkage control function is Yes. Step 4 On the Linkage Group tab page, set Link fire control with Cabinet Electronic Clasp lock open to on.
Page 349: Setting Neteco Parameters
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Figure 5-72 Connecting the communications cable ----End 5.3.13.1.2 Setting NetEco Parameters When the smart module can be connected to the NetEco, perform the following steps to configure parameters. Procedure Step 1 Apply for a fixed IP address to the equipment room network administrator.
Page 350: Obtaining The Neteco Software License
5.3.13.1.3 Obtaining the NetEco Software License The NetEco software license is not provided together with software to the customer. Therefore, obtain the NetEco software license in advance. Obtain the license from the Huawei's enterprise support website. ● For enterprise users: Issue 01 (2021-02-05) Copyright ©...
Page 351: Powering On A Server
Data Center > iManager NetEco 6000. Then, apply for the license of the NetEco software by referring to the guide. ● For carrier users: Log in to Huawei's carrier support website https://support.huawei.com. Browse or search iManager NetEco 6000 License Application Guide, iManager NetEco 6000 License Application Guide from Support > obtain Product Support >...
Page 352: Loading A Neteco License
Huawei will not be liable for any security issues caused by your failure to change the preset password in time or password loss after changing.
Page 353: Installing Ne Adapters
You have obtained the adapter software installation packages. Procedure Step 1 Obtain the adapter software installation packages. ● For enterprise users: Log in to Huawei's enterprise support website https:// support.huawei.com/enterprise. Obtain iManager NetEco 6000 V600R021C00SPCXXX ReleaseDoc_ENG.zip, NetEco6000_V600R021C00SPCXXX_Adapters.zip, and NetEco6000_V600R021C00SPCXXX_DomainAdapters.zip from Support >...
Page 354: Adding A Management Domain
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning required for the installation is related to the number of adapters. Wait for the installation to complete. ----End 5.3.13.1.8 Adding a Management Domain This section describes how to configure managed domains.
Page 355: Adding A Smart Module
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning In the Domain area which is below the navigation tree, drag a managed domain icon to the required position in the view. NO TE You can adjust the shape of Room, Building–ShapeNode, Floor–ShapeNode, Container–ShapeNode, and NetecoSite.
Page 356 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Step 5 Select the Modular to be added and drag the module icon to the Room area. Figure 5-75 Adding a smart module in the room area Step 6 Modify Management Info of the smart module or retain the default values, and...
Page 357 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning If You Then... Need To... Delete You can delete one smart module or multiple smart modules in smart batches on the current page. modules NOTE If a smart module contains subdevices, you cannot delete it. You can delete the smart module only after you delete subdevices in the module.
Page 358 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning If You Then... Need To... Figure 5-77 Deleting multiple smart modules in batches Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd.
Page 359: Creating An Ecc800-Pro On The Neteco
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning If You Then... Need To... 2. Add filter conditions, select multiple smart modules, and click Delete. 3. In the displayed Confirm dialog box, click Yes. Add tools 1. Select the smart module for which you want to add a pillar.
Page 360: Cloudopera Neteco Management
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning ● You have created modules in Data Center Planning. Context iManager NetEco 6000 Device Installation and For detailed operations, see Commissioning Guide of the corresponding version. Procedure Choose System > Configuration > Data Center Planning from the main menu.
Page 361: Installing The Edcm App
Huawei will not be liable for any security issues caused by your failure to change the preset password in time or password loss after changing.
Page 362: Allowing A User To Log In To The Edcm On A Mobile Device
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning 5.3.13.2.3 Allowing a User to Log in to the EDCM on a Mobile Device Prerequisites You have logged in to the EDCM. Procedure Step 1 Choose System > System Management > User Management.
Page 363: Setting Edcm Communication Parameters On The Ecc800-Pro
Step 2 Open the EDCM app, and enter the Organization, Username, and Password. NO TE ● Organization and Username are the tenant name registered on HUAWEI CLOUD. ● If you fail to log in for three consecutive times, the system automatically displays Verification code.
Page 364: Connecting To The Network
FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Prerequisites ● You have obtained the IP address of the ECC800-Pro as well as the user name and password used for WebUI login. ● You have obtained the IP address of the EDCM server.
Page 365 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Procedure Step 1 On the CloudOpera NetEco app, tap in the upper right corner. Step 2 On the Create network screen, enter network information as prompted and tap Confirm. Figure 5-80 Creating a network...
Page 366 FusionModule800 Smart Small Data Center User Manual 5 Power-On Commissioning Parameter Description Address Address of the network. ----End Issue 01 (2021-02-05) Copyright © Huawei Technologies Co., Ltd.
Page 367: Routine Maintenance
FusionModule800 Smart Small Data Center User Manual 6 O&M O&M 6.1 Routine Maintenance NO TICE ● Only trained personnel are allowed to perform maintenance tasks. Before performing operations on devices, wear ESD clothes, ESD gloves, and an ESD wrist strap. Remove conductive objects such as jewelry and watches to avoid electric shocks or burns.
Page 368 FusionModule800 Smart Small Data Center User Manual 6 O&M Maintenance Item Operation Expected Result Troubleshooting Surge protection Check the surge ● The surge ● If the surge module protection module protection module protection module indicator and MCB indicator is green.
Page 369 FusionModule800 Smart Small Data Center User Manual 6 O&M Maintenance Item Operation Expected Result Troubleshooting Operating ● Ambient If the humidity and environment temperature: –20°C temperature are to +65°C abnormal, check the smart cooling product ● Humidity: 0–95% status. RH (non-...
Page 370 FusionModule800 Smart Small Data Center User Manual 6 O&M Maintenance Item Operation Expected Result Troubleshooting Camera On the ECC800-Pro The camera web page If the monitoring WebUI, choose is displayed after you image is not displayed System Settings > click an address under...
Page 371: Quarterly Maintenance
FusionModule800 Smart Small Data Center User Manual 6 O&M Maintenance Item Operation Expected Result Troubleshooting Check that the Replace the operating compressor compressor. generates no abnormal noise. Check that the Check for leakage and refrigerant pipe is free repair the pipe.
Page 372: Yearly Maintenance
FusionModule800 Smart Small Data Center User Manual 6 O&M 6.1.3 Yearly Maintenance Table 6-3 Yearly preventive maintenance table Maintenance Item Operation Expected Result Troubleshooting Power distribution Check whether there The white paper that If the white paper is subrack is dust on the power...
Page 373 FusionModule800 Smart Small Data Center User Manual 6 O&M Maintenance Item Operation Expected Result Troubleshooting Battery appearance 1. The surface is clean If the battery and tidy without appearance is stains. abnormal, contact Huawei technical 2. The battery support. terminals are intact.
Page 374 FusionModule800 Smart Small Data Center User Manual 6 O&M Maintenance Item Operation Expected Result Troubleshooting Battery string charge ● Equalized charging 1. If the voltage drop voltage voltage: (2.35 V/cell between the ±1%) x number of battery string battery cells...
Page 375 FusionModule800 Smart Small Data Center User Manual 6 O&M Maintenance Item Operation Expected Result Troubleshooting Battery voltage ● Equalized charging 1. Check whether the voltage: 2.35±0.02 equalized charging V/cell voltage and float charging voltage of ● Float charging a battery are voltage: 2.25±0.02...
Page 376 FusionModule800 Smart Small Data Center User Manual 6 O&M Maintenance Item Operation Expected Result Troubleshooting Battery connection 1. When battery 1. Rectify any strings are powered abnormal off, check the connection. reliability of each 2. If the fault persists, connection point...
Page 377 FusionModule800 Smart Small Data Center User Manual 6 O&M Maintenance Item Operation Expected Result Troubleshooting Smart cooling product Monitoring unit Export smart cooling Rectify the fault or product logs, alarms, contact Huawei temperature, humidity, technical support. the operating status of...
Page 378: Troubleshooting
FusionModule800 Smart Small Data Center User Manual 6 O&M Maintenance Item Operation Expected Result Troubleshooting Check that the electric Replace the electric heater contactor heating contactor if it works properly. is faulty. 1. When the smart cooling product is on, set Diagnostic...
Page 379 UPS again. Otherwise, the fault may be extended, or the UPS may be damaged. ● If the fault is not rectified, contact Huawei technical support. Table 6-4 Power supply and distribution system troubleshooting...
Page 380 FusionModule800 Smart Small Data Center User Manual 6 O&M Symptom Possible Cause Measure The indicators are off. ● Cables are loose. ● Connect the cables again. ● The fuse holder trips. ● Turn on the fuse ● The fuse is damaged.
Page 381 FusionModule800 Smart Small Data Center User Manual 6 O&M Symptom Possible Cause Measure The mains indicator is The mains voltage or Use a multimeter to off. frequency exceeds the verify that the input UPS input range. voltage and frequency meet specifications.
Page 382: Smart Cooling Product Troubleshooting
FusionModule800 Smart Small Data Center User Manual 6 O&M 6.2.2 Smart Cooling Product Troubleshooting CA UTION Do not maintain or replace outdoor units during thunderstorms. Otherwise, your personal safety will be in danger. NO TICE ● You are not advised to maintain or replace outdoor units in rainy days. If unavoidable, take protective measures to prevent water from entering the outdoor unit.
Page 383 FusionModule800 Smart Small Data Center User Manual 6 O&M Sympt Possible Cause Measure The water inlet pipe Check the water inlet pipe and or drainpipe leaks. drainpipe and their connectors, and repair or replace them based on site requirements. Humidi For a single smart ●...
Page 384 FusionModule800 Smart Small Data Center User Manual 6 O&M Sympt Possible Cause Measure The outdoor units are Install outdoor units in the right temper not installed in right positions based on the installation ature is positions. (The requirements. installation distances high.
Page 385: Management System Troubleshooting
FusionModule800 Smart Small Data Center User Manual 6 O&M Sympt Possible Cause Measure Liquid The indoor Increase the temperature setting. temperature is too returni low. ng to The electronic Replace the electronic expansion valve expansion valve coil is coil. compre faulty.
Page 386 FusionModule800 Smart Small Data Center User Manual 6 O&M Symptom Possible Cause Measure The Alarm indicator Overtemperature ● The ambient (yellow) is steady on. protection temperature exceeds the upper threshold. Increase the cooling capacity of the smart cooling product. ● The air channel is blocked.
Page 387: Alarm Reference
FusionModule800 Smart Small Data Center User Manual 6 O&M Symptom Possible Cause Measure The monitoring Reinstall the module is faulty or not monitoring module. If securely installed. the fault persists, replace the monitoring module. RJ45 power output The corresponding Energize corresponding...
Page 388 FusionModule800 Smart Small Data Center User Manual 6 O&M Component Alarm Name Alarm Possible Cause Measures Severit Rectifier fault Critical ● The mains has ● Rectify the fault, and experienced a power on the UPS transient high again. voltage. ● Check that the load ●...
Page 389 FusionModule800 Smart Small Data Center User Manual 6 O&M Component Alarm Name Alarm Possible Cause Measures Severit BCB Tripping Critical ● The battery has Identify the alarm discharged to the cause, rectify the fault, end-of-discharge and switch on the BCB (EOD) threshold.
Page 390 FusionModule800 Smart Small Data Center User Manual 6 O&M Component Alarm Name Alarm Possible Cause Measures Severit Teamwork Major 1. The DIP switch is set 1. Set the DIP switch networking failed incorrectly for correctly for teamwork. teamwork. 2. Check the teamwork 2.
Page 391 FusionModule800 Smart Small Data Center User Manual 6 O&M Component Alarm Name Alarm Possible Cause Measures Severit Group units Major 1. Teamwork settings 1. Modify teamwork number not match are incorrect for settings for slave slave units. units to enable slave units to join the 2.
Page 392 FusionModule800 Smart Small Data Center User Manual 6 O&M Component Alarm Name Alarm Possible Cause Measures Severit Power underfreq Major 1. The power supply 1. Check the power frequency is too low. supply frequency. 2. The SPD three-phase 2. Replace the SPD test board is faulty.
Page 393 FusionModule800 Smart Small Data Center User Manual 6 O&M Component Alarm Name Alarm Possible Cause Measures Severit Cold-aisle HT Critical 1. The cold-aisle T/H 1. Adjust the position of sensors are located the cold-aisle T/H in inappropriate sensors. position. 2. Check the ambient 2.
Page 394 FusionModule800 Smart Small Data Center User Manual 6 O&M Component Alarm Name Alarm Possible Cause Measures Severit High humidity Warnin 1. The load is low. 1. Please consult Huawei technical 2. The T/H sensors are support. located in inappropriate 2. Adjust the position of position.
Page 395 FusionModule800 Smart Small Data Center User Manual 6 O&M Component Alarm Name Alarm Possible Cause Measures Severit Cold-aisle T/H brd Major 1. The cables to the 1. Check the cables to comm failed T/H sensor are loose the T/H sensor.
Page 396 FusionModule800 Smart Small Data Center User Manual 6 O&M Component Alarm Name Alarm Possible Cause Measures Severit Comp discharge Major 1. The refrigerant leaks. 1. Identify and repair the leaking point, 2. The condenser fins and refill refrigerant are blocked.
Page 397 FusionModule800 Smart Small Data Center User Manual 6 O&M Component Alarm Name Alarm Possible Cause Measures Severit Comp HP switch Major 1. The outdoor unit 1. Check the outdoor input power has an unit power supply. open phase, 2. Check the signal...
Page 398 FusionModule800 Smart Small Data Center User Manual 6 O&M Component Alarm Name Alarm Possible Cause Measures Severit Comp discharge Major 1. The outdoor unit 1. Check the outdoor input power has an unit power supply. open phase, 2. Check the signal...
Page 399 FusionModule800 Smart Small Data Center User Manual 6 O&M Component Alarm Name Alarm Possible Cause Measures Severit Suction pressure Major 1. The cables to the 1. Check the cables to sensor fault press sensor are the press sensor. loose or damaged.
Page 400 FusionModule800 Smart Small Data Center User Manual 6 O&M Component Alarm Name Alarm Possible Cause Measures Severit Comp drive comm Critical 1. The cables to the 1. Check the cables to failed comp driver are the comp driver. loose or damaged.
Page 401 FusionModule800 Smart Small Data Center User Manual 6 O&M Component Alarm Name Alarm Possible Cause Measures Severit Comp drive Major 1. The comp is in lack 1. Fill oil to the comp. overload of oil. 2. Clean the condenser 2. The condenser fins fins.
Page 402 FusionModule800 Smart Small Data Center User Manual 6 O&M Component Alarm Name Alarm Possible Cause Measures Severit Comp LP switch Major 1. The refrigerant leaks. 1. Check for any leakages. Fill 2. The solenoid valve is refrigerant after faulty. maintenance or 3.
Page 403 FusionModule800 Smart Small Data Center User Manual 6 O&M Component Alarm Name Alarm Possible Cause Measures Severit Outdoor unit input Major 1. The comp is in lack 1. Fill oil to the comp. overcurrent of oil. 2. Clean the condenser 2.
Page 404 FusionModule800 Smart Small Data Center User Manual 6 O&M Component Alarm Name Alarm Possible Cause Measures Severit Indoor fan Major 1. The cables to the 1. Check the cables to overspeed indoor fan are loose the indoor fan. or damaged.
Page 405 FusionModule800 Smart Small Data Center User Manual 6 O&M Component Alarm Name Alarm Possible Cause Measures Severit Full water Critical 1. The low liquid level 1. Check the cables to sensor is faulty. the low liquid level sensor, clear the 2.
Page 406 FusionModule800 Smart Small Data Center User Manual 6 O&M Component Alarm Name Alarm Possible Cause Measures Severit Cond pump fault Major 1. Cables to the water 1. Verify pump cable pump are not connections. properly connected. 2. Replace the water 2.
Page 407 FusionModule800 Smart Small Data Center User Manual 6 O&M Component Alarm Name Alarm Possible Cause Measures Severit EEV low Major 1. The electronic 1. Reinstall the overheating degree expansion valve coil electronic expansion is loose. valve coil. 2. The electronic 2.
Page 408 FusionModule800 Smart Small Data Center User Manual 6 O&M Component Alarm Name Alarm Possible Cause Measures Severit EEV auto control Critical 1. The suction pressure 1. Verify that the fault sensor is faulty. suction pressure sensor works 2. The suction properly.
Page 409 FusionModule800 Smart Small Data Center User Manual 6 O&M Component Alarm Name Alarm Possible Cause Measures Severit Outdoor fan speed Major 1. The external fan 1. If the fan is working abnormal speed is too high. properly, add a baffle plate at the air 2.
Page 410: Parts Replacement
FusionModule800 Smart Small Data Center User Manual 6 O&M Component Alarm Name Alarm Possible Cause Measures Severit Comp drive Major 1. The fans in the comp 1. Check the fans in the module overheat driver are faulty. comp driver. 2. Dirt exists in the air 2.
Page 411: Replacing A Gas Spring
FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-1 Removing a cabinet electronic clasp lock Step 4 Install the new cabinet electronic clasp lock at the front or rear door of a cabinet. NO TE ● Before removing a cabinet electronic clasp lock, remember the DIP switch settings on the cabinet electronic clasp lock.
Page 412: Replacing A Pdu2000
FusionModule800 Smart Small Data Center User Manual 6 O&M Step 3 Remove the gas spring. Figure 6-2 Removing a gas spring Step 4 Tighten the new air spring using an adjustable wrench. ----End 6.4.1.3 Replacing a PDU2000 Prerequisites ● Tools: Phillips screwdriver, step ladder ●...
Page 413: Replacing Power Supply And Distribution System Components
FusionModule800 Smart Small Data Center User Manual 6 O&M 6.4.2 Replacing Power Supply and Distribution System Components D ANGER ● Only qualified personnel can replace components of the power supply and distribution system. ● Wear protective tools such as insulation gloves and shoes before replacing a power supply and distribution component.
Page 414 FusionModule800 Smart Small Data Center User Manual 6 O&M Step 3 Measure the L1, L2, L3, and N voltages to PE using an electroprobe, as shown in Figure 6-4, and verify that the faulty SPD has no voltage before replacing the faulty surge protection module.
Page 415: Replacing A Fuse
FusionModule800 Smart Small Data Center User Manual 6 O&M 6.4.2.2 Replacing a Fuse Prerequisites CA UTION When replacing a fuse, wear insulation gloves and do not touch the input copper bar. ● Tool: insulation gloves ● Material: The new fuse of the same model is available and functional.
Page 416 FusionModule800 Smart Small Data Center User Manual 6 O&M ● Material: A spare indicator of the same model is available and functional. Procedure Step 1 Open the rear door of the Converged Cabinet, and push out the fuse terminal block to disconnect the circuit. For details about the fuse position and how to remove the fuse, see 6.4.2.2 Replacing a...
Page 417: Replacing A Ups2000-G
FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-8 Replacing an indicator Step 4 Remove the retaining ring from the indicator and remove the indicator from the mounting hole. Step 5 Put a new indicator into the mounting hole, secure the retaining ring, connect the cables, and close the fuse terminal block.
Page 418 FusionModule800 Smart Small Data Center User Manual 6 O&M Step 3 Open the front door of the cabinet. Remove the protective cover from the maintenance bypass switch, and manually turn on the maintenance bypass switch (the UPS will automatically transfer to bypass mode and generate an alarm indicating that the maintenance bypass switch is turned on).
Page 419 FusionModule800 Smart Small Data Center User Manual 6 O&M Scenario with Two UPSs (One Faulty) Step 1 Ensure that the TN system is reliably grounded, and that the main ground cable of the smart module is reliably connected. NO TICE After removing cables, wrap exposed terminals with insulation tape and do not block cable labels.
Page 420 FusionModule800 Smart Small Data Center User Manual 6 O&M Scenario with Two UPSs (Two Faulty) Step 1 Ensure that the TN system is reliably grounded, and that the main ground cable of the smart module is reliably connected. NO TICE After removing cables, wrap exposed terminals with insulation tape and do not block cable labels.
Page 421: Replacing A Lithium Battery
FusionModule800 Smart Small Data Center User Manual 6 O&M connected in parallel, set parallel parameters. After that, close the output switches of the two UPSs, and open the manual maintenance bypass switch. Then the loads are energized by the UPS bypass.
Page 422: Replacing The Monitoring Board From The Ats Subrack
● Fill in the fault card with the information about the removed component. ● Contact your local Huawei office to handle the faulty component. 6.4.2.6 Replacing the Monitoring Board from the ATS Subrack Prerequisites ●...
Page 423: Replacing An Ats Subrack
FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-9 Replacing the monitoring board from the ATS subrack Install the spare monitoring board. 6.4.2.7 Replacing an ATS Subrack Prerequisites ● Tools: insulation gloves, Phillips screwdriver ● Materials: A spare ATS subrack of the same model is available and functional.
Page 424: Replacing Cooling System Components
FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-10 Replacing an ATS subrack Install the spare ATS subrack. Connect the ATS input and output power cables and monitoring cables. 6.4.3 Replacing Cooling System Components 6.4.3.1 Replacing Indoor Unit Components...
Page 425 FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-11 Indoor unit components (rear) (1) Electric control box (2) Water inlet solenoid valve (3) High liquid level detector (4) Low liquid level detector (5) Condensate pump (6) Low pressure sensor...
Page 426: Replacing An Indoor Fan
FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-12 Indoor unit components (front) (1) Fan (2) Electric heater (optional) (3) Evaporator 6.4.3.1.1 Replacing an Indoor Fan Prerequisites ● Tools: Phillips screwdriver, diagonal pliers or scissors. ● An indoor fan needs to be replaced.
Page 427 FusionModule800 Smart Small Data Center User Manual 6 O&M Tap the smart cooling product to be set in the cabinet layout diagram. Choose Real-time Data > OFF. ● Method 2: Log in to the ECC800-Pro WebUI as user admin. Choose Monitoring >...
Page 428 FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-14 Removing a fan baffle plate Step 5 (Optional) Cut the cable tie securing the NTC sensor on fan 3 using scissors or diagonal pliers, and remove the NTC sensor.
Page 429 FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-15 Removing the fan Step 8 Install a new fan in the original position by performing the preceding steps in reverse order, and install the air director and fan baffle plate (if any).
Page 430: Replacing A Condensate Pump
FusionModule800 Smart Small Data Center User Manual 6 O&M 6.4.3.1.2 Replacing a Condensate Pump Prerequisites ● Tool: Phillips screwdriver ● A condensate pump needs to be replaced. ● A spare condensate pump of the same model is available and functional.
Page 431 FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-16 Removing a condensate pump Step 4 Remove the hose clamps at the water inlet and outlet hoses of the condensate pump using a Phillips screwdriver, remove the hoses and take out the pump, as...
Page 432: Replacing A Psu, Rectifier, Or Main Control Module
The PSU, rectifier, and main control module can be replaced in the same way. This section describes how to replace a PSU. ● To replace the main control module, download the software and Software Upgrade Guide from Huawei websites, and upgrade it on the PAD or ECC. ● Figure 6-17 shows the front panel of a smart cooling product control unit.
Page 433 FusionModule800 Smart Small Data Center User Manual 6 O&M Tap the smart cooling product to be set in the cabinet layout diagram. Choose Real-time Data > OFF. ● Method 2: Log in to the ECC800-Pro WebUI as user admin. Choose Monitoring >...
Page 434: Replacing An Ntc Temperature Sensor
FusionModule800 Smart Small Data Center User Manual 6 O&M 6.4.3.1.4 Replacing an NTC Temperature Sensor Prerequisites ● Tools: Phillips screwdriver (optional, required for removing the air director and fan baffle plate), diagonal pliers or scissors. ● An NTC temperature sensor needs to be replaced.
Page 435: Replacing A Low Pressure Sensor
FusionModule800 Smart Small Data Center User Manual 6 O&M Step 8 Choose Monitoring > Cooling > NetCol5000-A1 > Running Info > T/H Sensor Information, read the value of supply-air temperature sensor, and determine whether the value is proper. ----End 6.4.3.1.5 Replacing a Low Pressure Sensor Prerequisites ●...
Page 436: Replacing A Fuse
FusionModule800 Smart Small Data Center User Manual 6 O&M When replacing the low pressure sensor, use one adjustable wrench to fix the bottom needle valve of the sensor, and use another adjustable wrench to rotate the sensor counter-clockwise. NO TE If it is difficult to remove the sensor, use a heat gun to heat the threads.
Page 437 FusionModule800 Smart Small Data Center User Manual 6 O&M Choose Home. Tap the cabinet that houses the smart cooling product in the micro- module view. Tap the smart cooling product to be set in the cabinet layout diagram. Choose Real-time Data > OFF.
Page 438: Replacing A Contactor
FusionModule800 Smart Small Data Center User Manual 6 O&M Step 7 Choose Running Parameters > Diagnostic Mode Parameters, set Indoor fan manual control to 50%, and click Submit. If the indoor fan works properly for 5 minutes and there is no alarm, the indoor fan is functional. Set Indoor fan manual control to 0% and click Submit.
Page 439: Replacing An Eev And Coil
FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-20 Removing a contactor Step 4 Install a new contactor in the original position by performing the preceding steps in reverse order, and connect the cable. Step 5 After powering on the smart cooling product, log in to the ECC800-Pro WebUI as user admin, choose Monitoring >...
Page 440 FusionModule800 Smart Small Data Center User Manual 6 O&M Procedure Step 1 Shut down the smart cooling product over the EMS. ● Method 1: Log in to the ECC800-Pro mobile phone or pad app as user admin. Choose Home. Tap the cabinet that houses the smart cooling product in the micro- module view.
Page 441 FusionModule800 Smart Small Data Center User Manual 6 O&M Step 6 Weld a new EEV, and install the coil for the EEV. NO TICE Protect the surrounding components during the welding process. Step 7 Inject nitrogen and preserve the pressure. After checking that the EEV and system do not leak, perform vacuumization and inject refrigerant.
Page 442: Replacing Outdoor Unit Components
FusionModule800 Smart Small Data Center User Manual 6 O&M Tap the smart cooling product to be set in the cabinet layout diagram. Choose Real-time Data > Perf Maint, and clear up the EEV total runtime. ● Method 2: Log in to the ECC800-Pro WebUI as user admin. Choose Monitoring >...
Page 443 FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-22 NetCol500-A018 components (1) Outdoor fan blade (2) Safety valve (3) High pressure switch (4) Low pressure switch (5) High pressure sensor (6) Compressor (7) Oil heating belt Issue 01 (2021-02-05)
Page 444 FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-23 NetCol500-A020 components (1) Outdoor fan (2) Handle (3) Control board (4) Suction temperature sensor (5) High pressure switch (6) Low pressure switch (7) High pressure sensor (8) Filter dryer...
Page 445 FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-24 NetCol500-A021 components (1) Outdoor fan blade (2) Freon pump (3) Oil heating belt (4) Compressor (5) Low pressure switch (6) High pressure sensor (7) High pressure switch Figure 6-25 NetCol500-A020 components (top view)
Page 446: Replacing An Outdoor Fan
FusionModule800 Smart Small Data Center User Manual 6 O&M (7) Transformer Figure 6-26 NetCol500-A018 components (top view) (1) Circuit breaker (2) Surge protection board (3) Outdoor unit control board (SPD) (4) PFC board (5) Large capacitor (6) Compressor drive (IPM)
Page 447 FusionModule800 Smart Small Data Center User Manual 6 O&M Procedure Step 1 Shut down the smart cooling product over the EMS. ● Method 1: Log in to the ECC800-Pro mobile phone or pad app as user admin. Choose Home. Tap the cabinet that houses the smart cooling product in the micro- module view.
Page 450 FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-30 Removing panels (for NetCol500-A021) Step 4 Cut the cable ties on the fan cable using diagonal pliers and take out the outdoor fan cable from the electric control box.
Page 453 FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-33 Removing the outdoor fan blades (for NetCol500-A021) Step 6 If the motor of the outdoor fan needs to be replaced, use a socket wrench to remove the four screws that secure the motor, and remove the motor.
Page 454: Replacing A Compressor
FusionModule800 Smart Small Data Center User Manual 6 O&M there is no alarm, the outdoor fan is functional. Set Outdoor fan manual control to 0% and click Submit. Step 13 Choose Controls > Control Information, set Diagnostic mode to Exit, and click Submit.
Page 455 FusionModule800 Smart Small Data Center User Manual 6 O&M Tap the smart cooling product to be set in the cabinet layout diagram. Choose Real-time Data > OFF. ● Method 2: Log in to the ECC800-Pro WebUI as user admin. Choose Monitoring >...
Page 456 FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-34 Position of the compressor (for NetCol500-A018) (1) Welding point for the (2) Compressor (3) Bolts on the compressor suction pipe base (4) Oil separator (5) Welding point for the...
Page 457 FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-36 Position of the compressor (for NetCol500-A021) (1) Oil separator (2) Bolts on the compressor (3) Compressor base (4) Welding point for the (5) Welding point for the discharge pipe...
Page 458: Replacing A Filter Dryer
FusionModule800 Smart Small Data Center User Manual 6 O&M Information and read the air suction pressure and air exhaust pressure. Check that the air suction/exhaust pressure of the compressor is within the proper range. Choose Running Info > Electronic Expansion Valve Information. Check that the EEV suction overheating degree is within the proper range.
Page 459 FusionModule800 Smart Small Data Center User Manual 6 O&M Context ● Tools: welding tool, refrigerant retrieval device (required based on local conditions), nitrogen injection and pressure preservation tool, vacuumization tool, refrigerant injection tool, Phillips screwdriver, protective gloves. ● Preparation: Power off the outdoor unit and empty system of the refrigerant.
Page 460 FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-37 Position of the filter dryer (for NetCol500-A018) (1) Filter dryer (2) Welding point Figure 6-38 Position of the filter dryer (for NetCol500-A020) (1) Filter dryer (2) Welding point Issue 01 (2021-02-05)
Page 461 FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-39 Position of the filter dryer (for NetCol500-A021) (1) Filter dryer (2) Welding point Step 6 Weld the new filter dryer to the pipe. Step 7 Secure the new filter dryer using cable ties.
Page 462: Replacing A High Pressure Sensor
FusionModule800 Smart Small Data Center User Manual 6 O&M Step 14 Choose Controls > Control Information, set Diagnostic mode to Exit, and click Submit. ----End 6.4.3.2.4 Replacing a High Pressure Sensor Prerequisites ● A high pressure sensor needs to be replaced.
Page 463: Replacing A Pneumatic Switch
FusionModule800 Smart Small Data Center User Manual 6 O&M Step 6 Remove the high pressure sensor using an adjustable wrench. Step 7 Apply sealant to the threads of the new high pressure sensor. Install a new high pressure sensor in the original position using an adjustable wrench and connect the cable.
Page 464 FusionModule800 Smart Small Data Center User Manual 6 O&M ● Tools: Phillips screwdriver, flat-head screwdriver, socket wrench, diagonal pliers, welding tool, refrigerant retrieval device (required based on local conditions), nitrogen injection and pressure preservation tool, vacuumization tool, refrigerant injection tool.
Page 465: Replacing A Safety Valve
FusionModule800 Smart Small Data Center User Manual 6 O&M Step 9 Perform a leakage test with nitrogen again. After checking that the smart cooling product does not leak, vacuumize the smart cooling product and charge refrigerant. Step 10 Reinstall the right rear panel and top cover.
Page 466 FusionModule800 Smart Small Data Center User Manual 6 O&M Choose Home. Tap the cabinet that houses the smart cooling product in the micro- module view. Tap the smart cooling product to be set in the cabinet layout diagram. Choose Real-time Data > OFF.
Page 467: Replacing A Switch For The Outdoor Unit
FusionModule800 Smart Small Data Center User Manual 6 O&M Step 10 After powering on the smart cooling product, log in to the ECC800-Pro WebUI as an admin, choose Monitoring > Cooling > NetCol5000-A1 > Controls > Control Information, set Startup/Shutdown control to ON, and click Submit.
Page 468: Replacing Management System Components
FusionModule800 Smart Small Data Center User Manual 6 O&M ● Method 2: Log in to the ECC800-Pro WebUI as admin. Choose Monitoring > Cooling > NetCol5000-A1 > Controls > Control Information, choose Startup/Shutdown control > OFF, and then click Submit.
Page 469: Replacing An Ecc800-Pro Main Control Module
FusionModule800 Smart Small Data Center User Manual 6 O&M 6.4.4.1 Replacing an ECC800-Pro Main Control Module Prerequisites NO TICE ● The ECC800-Pro main control module is hot-swappable. ● Before disconnecting cables from the ECC800-Pro main control module, label the cables based on the corresponding ports.
Page 470: Replacing An Ecc800-Pro Psu
FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-43 Installing the Micro SD and SIM card Step 7 Install the spare ECC800-Pro main control module in the ECC800-Pro subrack and tighten the screws on both sides of the ECC800-Pro main control module.
Page 471: Replacing An Ecc800-Pro Antenna
FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-44 Replacing a PSU ----End 6.4.4.3 Replacing an ECC800-Pro Antenna Prerequisites ● Tools: ESD wrist strap, ESD gloves ● Materials: A spare ECC800-Pro antenna of the same model is available and functional.
Page 472 FusionModule800 Smart Small Data Center User Manual 6 O&M Prerequisites ● Tools: ESD wrist strap, ESD gloves ● Materials: A spare SIM card of the same model is available and functional. Procedure Step 1 Record the positions of the signal cables connected to the panel of the ECC800- Pro main control module, and then disconnect the signal cables.
Page 473: Replacing A Smart Eth Gateway
FusionModule800 Smart Small Data Center User Manual 6 O&M Step 6 Insert the ECC800-Pro main control module into the slot. Step 7 Tighten the screws on both sides of the panel of the ECC800-Pro main control module. Step 8 Connect the signal cables to the panel of the new ECC800-Pro main control module based on the recorded information.
Page 474 FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-49 Position 1 for installing a smart ETH gateway (1) Smart ETH gateway ● If M-shaped cable troughs are not deployed for the module, install the smart ETH gateway on the top of the Converged Cabinet, as shown in Figure 6-50.
Page 475: Replacing An Eth Converter
FusionModule800 Smart Small Data Center User Manual 6 O&M Procedure Step 1 Label each cable based on the corresponding ports on the smart ETH gateway. Step 2 Disconnect cables from the smart ETH gateway. Step 3 Remove the faulty smart ETH gateway from the guide rail, as shown in Figure 6-51.
Page 476: Replacing A Camera
FusionModule800 Smart Small Data Center User Manual 6 O&M Preparations Tools: ESD wrist strap, ESD gloves, step ladder, label, marker Material: ETH converter Documents: none Skill requirement: ELV engineer Procedure Step 1 Label each cable based on the corresponding ports on the ETH converter.
Page 477 FusionModule800 Smart Small Data Center User Manual 6 O&M Step 2 Remove the inner cover, as shown in Figure 6-53. Figure 6-53 Removing the inner cover NO TE In the scenario with an SD card, remove the SD card and install it to a new camera.
Page 478: Replacing An Ivs1800
FusionModule800 Smart Small Data Center User Manual 6 O&M Step 6 Commission the camera by referring to the ECC800-Pro user manual of the appropriate version. Step 7 Check whether the new camera works properly and adjust the camera angle. If video images are properly displayed on the video screen of the management system client, the new camera works properly.
Page 479: Replacing A Hard Disk For The Ivs1800
FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-55 Installing a device Step 4 Reconnect the cables to the new IVS1800. Step 5 Turn on the power switch of the IVS1800. Step 6 Commissioning the IVS1800. If the video recording function works properly after commissioning, the IVS1800 is functional.
Page 480 FusionModule800 Smart Small Data Center User Manual 6 O&M Remove two black screws on each side of the chassis and the silvery white one on top of the hard disk tray, raise the hard disk tray by 45 degrees, and take out the upper and then lower layers of hard disk tray.
Page 481: Replacing An Aisle T/H Sensor (02312Pbl)
Figure 6-61 Closing the chassis cover Step 4 Observe the hard disk indicator to check whether the hard disk works properly. ----End Follow-up Procedure If the hard disk works abnormally, contact Huawei technical support. 6.4.4.10 Replacing an Aisle T/H Sensor (02312PBL) Prerequisites ●...
Page 482 FusionModule800 Smart Small Data Center User Manual 6 O&M NO TICE After removing cables, wrap exposed terminals with insulation tape and do not block cable labels. If cable labels are blocked, cables may be connected incorrectly later. Step 3 Remove the T/H sensor from its base, as shown in Figure 6-62.
Page 483: Replacing A Remote T/H Sensor (33010516)
FusionModule800 Smart Small Data Center User Manual 6 O&M Step 7 Choose Monitoring > Aisle > T/H Sensor Group and check whether the T/H sensor works properly. If yes, the T/H sensor is functional. Step 8 Choose Home > Plan View and add a new T/H sensor in the appropriate position.
Page 484: Replacing A Temperature Sensor
FusionModule800 Smart Small Data Center User Manual 6 O&M 6.4.4.12 Replacing a Temperature Sensor Prerequisites ● Recommended tools and materials: diagonal pliers, insulation tape, cable tie, step ladder (2 m) ● A temperature sensor needs to be replaced. ● Spare temperature sensors of the same model are available and functional.
Page 485: Replacing A Smoke Sensor
FusionModule800 Smart Small Data Center User Manual 6 O&M NO TICE ● When installing temperature sensors, bind the cables behind the sensors to the cable bridge, keeping them 20 mm away from the sensor probes. ● Temperature sensors must not be in touch with metal parts or cabinets.
Page 486 FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-64 Sensor positions (1) Smoke detector Procedure Step 1 Remove the smoke detector from the base. Step 2 Remove the cables from the smoke detector and apply insulation measures such as wrapping the cables with insulation tape to avoid hazards.
Page 487: Replacing A Wlds900 Water Sensor And Water Detection Rope
FusionModule800 Smart Small Data Center User Manual 6 O&M 6.4.4.14 Replacing a WLDS900 Water Sensor and Water Detection Rope Prerequisites ● Recommended tools and materials: Phillips screwdriver, crimping tool ● A water sensor needs to be replaced. ● A spare water sensor of the same model is available and functional.
Page 488 FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-66 Water sensor components (1) Water detector (2) Conversion cable end A, (3) Conversion cable connected to the water detector (4) Conversion cable end B, (5) Water detection cable end A,...
Page 489 FusionModule800 Smart Small Data Center User Manual 6 O&M Remove the bottom plate of the water detector from the Converged Cabinet. Figure 6-68 Removing the bottom plate of the water detector Install a new water detector in the Converged Cabinet by referring to the preceding steps.
Page 490: Replacing An Electrode Water Sensor
FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-70 Connecting a new water detection cable (1) Conversion cable end B, connected to the (2) Water detection cable end A, connected to water detection cable the conversion cable NO TE The water detection cable and conversion cable are interconnected through the male and female connectors.
Page 491: Replacing An Elight Actuator
FusionModule800 Smart Small Data Center User Manual 6 O&M Preparations ● Tool: ESD gloves ● Material: eLight strip light Procedure Step 1 Remove the fastener from the strip light to be replaced. Step 2 Remove the strip light. Step 3 Take out the new strip light and reserve the end with a wiring terminal on the top of the IT cabinet at an end of the row.
Page 492: Replacing An Elight Power Supply
FusionModule800 Smart Small Data Center User Manual 6 O&M Step 5 On the ECC800-Pro WebUI, choose Monitoring > Aisle > eLight Actuator Group > eLight Actuator, and check the parameters and communication status of the eLight actuator to ensure that the device communication is normal.
Page 493 FusionModule800 Smart Small Data Center User Manual 6 O&M ● A spare access actuator of the same model is available and functional. Context Figure 6-73 Access actuator Procedure Step 1 Remove the cover from the waterproof box. Figure 6-74 Removing the cover of a waterproof box Step 2 Remove the cable connected to the power over Ethernet (PoE) port on the access actuator.
Page 494: Replacing A Fingerprint And Card Reader With A Keypad
FusionModule800 Smart Small Data Center User Manual 6 O&M Step 7 Choose Monitoring > System > ECC800-Pro > Controls and delete the device failing in communication. Step 8 Refer to the section about commissioning the in-room access control system in the installation guide and check that the access actuator functions properly.
Page 495: Replacing A Fingerprint And Card Reader
FusionModule800 Smart Small Data Center User Manual 6 O&M Figure 6-76 Replacing a fingerprint and card reader with a keypad Step 2 Remove the original bottom plate, as shown by (4) in Figure 6-76. Step 3 Take out the bottom plate of the new fingerprint and card reader with a keypad and secure it.
Page 496 FusionModule800 Smart Small Data Center User Manual 6 O&M Context Figure 6-77 Fingerprint and card reader Procedure Step 1 Remove the screws that secure the fingerprint and card reader, and remove the cable, as shown by (1), (2), and (3) in Figure 6-78.
Page 497: Replacing A Card Reader With A Keypad
FusionModule800 Smart Small Data Center User Manual 6 O&M Step 5 Secure the fingerprint and card reader to the bottom plate. Step 6 Configure the new fingerprint and card reader by following the instructions provided in the document delivered with it.
Page 498: Replacing An Emergency Door Release Button
FusionModule800 Smart Small Data Center User Manual 6 O&M Procedure Step 1 Remove the screw that secures the card reader with a keypad, and remove the cable, as shown by (1), (2), and (3) in Figure 6-80. Figure 6-80 Removing the bottom plate...
Page 499 FusionModule800 Smart Small Data Center User Manual 6 O&M Context Figure 6-81 Emergency door release button Procedure Step 1 Remove the emergency door release button. Remove the screw that secures the emergency door release button, as shown by (1) in Figure 6-82.
Page 500 FusionModule800 Smart Small Data Center User Manual 6 O&M Tighten the screw, as shown by (4) in Figure 6-83. Figure 6-83 Installing an emergency door release button Step 3 Close the room door, and open the protection box of the emergency door release button.
Page 501: Technical Specifications
FusionModule800 Smart Small Data Center User Manual 7 Technical Specifications Technical Specifications Table 7-1 Key technical specifications Item Asia, Europe, and Africa Version Specifications Module Cold and hot aisle containment: 2000 x L x 1350, L ≤ 7400 dimensions (H x W x D)
Page 502 FusionModule800 Smart Small Data Center User Manual 7 Technical Specifications Item Asia, Europe, and Africa Version Specifications Cable and ● Pipes are routed from the top or bottom. pipe routing ● Input power cables of the Converged Cabinet can be routed in from the top or bottom, and other power cables can be routed out from the top.
Page 503: A Fluorine Pump Principles
FusionModule800 Smart Small Data Center User Manual A Fluorine Pump Principles Fluorine Pump Principles Working principles of fluorine pump: ● The fluorine pump is efficient and energy-saving. When the ambient temperature is lower than –8°C (switches back to the compressor system when the outdoor temperature is higher than –5°C), the cooling system...
Page 504 FusionModule800 Smart Small Data Center User Manual A Fluorine Pump Principles (9) Fluorine pump (10) High pressure (11) Fluorine pump (12) High pressure bypass check valve sensor 2 sensor 3 (13) Fluorine pump (14) Outdoor unit (15) Indoor unit (16) Electronic...
Page 505: B Equipment Derating Coefficients
FusionModule800 Smart Small Data Center User Manual B Equipment Derating Coefficients Equipment Derating Coefficients NO TE The coefficients listed in the Table B-1 are based on the dry air density being 1.225 kg/m (sea level +15ºC). Table B-1 Derating coefficients of the UPS2000-G...
Page 506: C Acronyms And Abbreviations
FusionModule800 Smart Small Data Center User Manual C Acronyms and Abbreviations Acronyms and Abbreviations alternating current auto transformer switch ATSE auto transformer switch equipment ASIC application-specific integrated circuit battery interface module control area network communication interface module CPLD complex programmable logical device...
Page 507 FusionModule800 Smart Small Data Center User Manual C Acronyms and Abbreviations HTTPS Hypertext Transfer Protocol Secure liquid crystal display large-scale integrated LCD user interface management information base network management system protective earthing power factor correction parallel load RS232 Recommended Standard 232...

This manual is also suitable for:

V100r021c00

Huawei FusionModule800 User Manual

About this Document

1 Safety Information

2 Product Description

3 System Architecture

4 Installation Guide

5 Power-On Commissioning

6 O&M

Quick Links

Troubleshooting

Related Manuals for Huawei FusionModule800

Summary of Contents for Huawei FusionModule800
