1152700 Issue 1 February 2001 Section 2 Operations and Maintenance
DLP-701
Page 10 of 10
PORT 1
PORT 2
RX / TX
RX / TX
10522-B
Figure 701-7. Fiber Connectors on an 155 SM/MM CRS Card
FIBER CLIP ON FACEPLATE
10566-B
Figure 701-8. Faceplate Fiber Clip on Optical Card (622 shown)
Page 2-55
