- Page 1 HiGain HiGain HiGain LOOP B8ZS RS-232 H2TU-R-402 List 4E Remote Unit Part Number: 150-2450-45 CLEI: VARH1UUC ANUAL...
- Page 2 Contents herein are current as of the date of publication. ADC reserves the right to change the contents without prior notice. In no event shall ADC be liable for any damages resulting from loss of data, loss of use, or loss of profits, and ADC further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages.
-
Page 3: Using This Manual
Unpack each container and inspect the contents for signs of damage. If the equipment has been damaged in transit, immediately report the extent of damage to the transportation company and to ADC DSL Systems, Inc. Order replacement equipment, if necessary. -
Page 4: Table Of Contents
Table of Contents ABLE OF ONTENTS Overview ____________________________________________________________________________ 1 Features... 1 Compatibility... 2 Applications... 2 Front Panel __________________________________________________________________________ 3 Installation ___________________________________________________________________________ 5 Verification... 6 Verification without an Upstream Device ... 6 Verification with an Upstream Device... 6 Viewing System Screens ________________________________________________________________ 7 Connecting to a Maintenance Terminal ... - Page 5 152-402-145-02, Issue 2 IST OF ABLES 1. Front-Panel Description...4 Logon Screen Menus ...8 3. Navigational Keys for the HiGain HDSL2 Maintenance Terminal Screens...9 4. Monitor Screen Descriptions ...11 5. Error Acronyms Used on the DS1 Performance History Screens ...16 6. Error Acronyms Used on the HDSL2 Performance History Screens...19 7.
- Page 6 List of Figures IST OF IGURES 1. H2TU-R-402 List 4E Front Panel... 3 2. Installing the H2TU-R-402 List 4E ... 5 3. Logon Screen ... 8 4. Monitor Screen - Active Loopback with Alarms... 10 5. H2TU-R DS1 31-day Performance History... 12 6.
-
Page 7: Overview
The HiGain HDSL2 product family from ADC Digital Subscriber Line 2 (HDSL2). ADC products are fully compliant with the HDSL2 standard. Providing full-rate T1 access using just a single copper pair, HDSL2 is a cost-effective solution that offers an open architecture. -
Page 8: Compatibility
Overview OMPATIBILITY The H2TU-R-402 is designed to mount in any 400 or 200 mechanics shelf. For a list of compatible shelves see “Appendix C - Compatibility” on page PPLICATIONS HiGain HDSL2 systems provide a cost-effective, easy-to-deploy method for delivering T1 High Capacity Digital Service (HCDS) over a single copper pair. -
Page 9: H2Tu-R-402 List 4E Front Panel
152-402-145-02, Issue 2 RONT ANEL Figure 1 shows the H2TU-R-402 List 4E front panel. pinout diagrams of the H2TU-R card-edge connector and craft port, refer to page DS1 framing LEDs DS1 line code LEDs Loopback LED CLEI/ECI bar code label Configuration number label (inside handle) Figure 1. -
Page 10: Front-Panel Description
Front Panel Front-panel Feature Function List number Identifies the list number of the H2TU-R-402. Alarm (ALM) LED Shows alarm states for remote and local Loss of Signal (LOS). Steady red Indicates a Loss of Signal (LOS) condition at the T1 input of the H2TU-R-402. Blinking Indicates an LOS condition at the T1 input of the H2TU-C line unit. -
Page 11: Installation
152-402-145-02, Issue 2 NSTALLATION H2TU-R-402 Figure 2. Installing the H2TU-R-402 List 4E Wear an antistatic wrist strap when installing the H2TU-R. Avoid touching components on the circuit board. Check the setting of the SCURR switch. The default setting is disabled (up position). If the H2TU-R is locally powered, and your application requires sealing current, place the SCURR switch in the down position. -
Page 12: Verification
Installation ERIFICATION Verification without an Upstream Device Verify that the H2TU-R powers up. The following should occur: • The front-panel ALM LED is a steady red. • The LOOP LED is flashing green. • If receiving a DS1 signal, one of the DS1 framing LEDs (ESF or SF) and one of the DS1 line code LEDs (B8ZS or AMI) is a steady green. -
Page 13: Viewing System Screens
Initial provisioning of the HiGain HDSL2 system is performed at the H2TU-C line unit. For more information about the HiGain HDSL2 screens, provisioning, and troubleshooting, download the appropriate H2TU-C line unit user manual from the ADC website at www.adc.com. To order a hard copy, please contact your sales representative. -
Page 14: Logon Screen Menus
To logoff the remote unit, press unit is now locally logged on until remote logon. Provides a glossary of terms used in the HiGain HDSL2 maintenance screens, a list of navigational keys, and ADC contact information. June 16, 2000 152-402-145-02, Issue 2 Rlogon... -
Page 15: Navigational Keys For The Higain Hdsl2 Maintenance Terminal Screens
152-402-145-02, Issue 2 Table 3. Navigational Keys for the HiGain HDSL2 Maintenance Terminal Screens Function Cycle through selections. SPACEBAR Activate the current setting or choice, or display a menu. ENTER Return to the parent menu. (VT100) Select the submenu or item above the current one, or return to the previous menu. CTRL Select the submenu or item below the current one. -
Page 16: Monitoring System Activity And Performance
Monitoring System Activity and Performance ONITORING ERFORMANCE The HiGain HDSL2 system provides the following maintenance screens for monitoring system activity and assessing performance. • The Monitor screens provide a graphical representation of circuit activity and allow initiation of loopbacks. • The Performance screens provide current, 25-hour, 48-hour, and 31-day performance histories and a continuous alarm history. -
Page 17: Monitor Screen Descriptions
152-402-145-02, Issue 2 To initiate a loopdown of all active loopbacks, press the . When prompted with the message: Are you sure (Y/N)?, press cancel. Field Description Active Loopback An active loopback is indicated on the lower third of the Monitor screen. Available loopbacks are indicated by gray text. -
Page 18: Using The Performance Screens To View Performance Data
Monitoring System Activity and Performance SING THE ERFORMANCE To access the Performance history screens: Press to select the Performance screen. Press the SPACEBAR to select either interface (H2TU-C DS1, H2TU-R DS1, H2TU-C HDSL2, or H2TU-R HDSL2), then press ENTER Press the SPACEBAR to select the type of statistics (Current, Alarm History, 25 Hour History, 48 Hour History, or 31 Day History), then press... -
Page 19: H2Tu-R Ds1 48-Hour Performance History
152-402-145-02, Issue 2 Monitor Performance Event Log H2TU-C DS-1 31 Day History (Page 1 of 3) ------------------------------------------------------------------------------ Date ES-L SES-L 04/03 04/04 04/05 04/06 04/07 04/08 04/09 04/10 04/11 04/12 04/13 04/14 04/15 Press: (N)ext Page, (P)revious Page, C(l)ear History ------------------------------------------------------------------------------ Press <Space>... -
Page 20: H2Tu-C Ds1 48-Hour Performance History
Monitoring System Activity and Performance Monitor Performance Event Log H2TU-C DS-1 48 Hour History (Page 1 of 4) ------------------------------------------------------------------------------ Time ES-L SES-L 23:00 1:00 2:00 3:00 4:00 5:00 6:00 7:00 8:00 9:00 10:00 11:00 12:00 Press: (N)ext Page, (P)revious Page, C(l)ear History ------------------------------------------------------------------------------ Press <Space>... -
Page 21: H2Tu-C Ds1 25-Hour Performance History
152-402-145-02, Issue 2 Monitor Performance Event Log H2TU-C DS-1 25 Hour History (Page 1 of 9) ------------------------------------------------------------------------------ Time ES-L SES-L 9:30 9:45 10:00 10:15 10:30 10:45 11:00 11:15 11:30 11:45 12:00 12:15 12:30 Press: (N)ext Page, (P)revious Page, C(l)ear History ------------------------------------------------------------------------------ Press <Space>... -
Page 22: Error Acronyms Used On The Ds1 Performance History Screens
Monitoring System Activity and Performance Table 5. Error Acronyms Used on the DS1 Performance History Screens Error Acronym Description ES-L Errored Seconds - Line Seconds with BPV 1. SES-L Severely errored seconds - Line Seconds with BPV plus EXZ UAS-L Unavailable seconds - Line Seconds with LOS 1. -
Page 23: Performance History At The Hdsl2 Interface
152-402-145-02, Issue 2 Performance History at the HDSL2 Interface Figure 12 is an example of a 31-Day History screen for the H2TU-R HDSL2 interface. The HDSL2 interface has 31-day, 48-hour, 25-hour, and current statistic screens for the H2TU-R and H2TU-C. the kinds of errors reported for these screens. -
Page 24: H2Tu-R Hdsl2 25-Hour Performance History
Monitoring System Activity and Performance Monitor Performance Event Log H2TU-R HDSL2 25 Hour History (Page 1 of 9) ------------------------------------------------------------------------------ Time 9:45 10:00 10:15 10:30 10:45 11:00 11:15 11:30 11:45 12:00 12:15 12:30 12:45 Press: (N)ext Page, (P)revious Page, C(l)ear History ------------------------------------------------------------------------------ Press <Space>... -
Page 25: Using The Performance Screens To View Alarm Data
152-402-145-02, Issue 2 Table 6. Error Acronyms Used on the HDSL2 Performance History Screens Error Acronym LOSWS SING THE ERFORMANCE To access the alarm history screens: Press to select the Performance menu. Press the SPACEBAR to select an interface (H2TU-C DS1, H2TU-R DS1, H2TU-C HDSL2, or H2TU-R HDSL2), then press ENTER Press the... -
Page 26: H2Tu-R Ds1 Alarm Descriptions
Monitoring System Activity and Performance Monitor Performance ------------------------------------------------------------------------------ Alarm First LLOS 04/10/00 00:00 LAIS DBER 04/10/00 00:37 ------------------------------------------------------------------------------ Press <Space> to cycle through choices and <Enter> to view ID: xxxx--xxxx--xxxx--xxxx Figure 17. H2TU-C DS1 Alarm History Screen Screen Alarm Front-Panel Alarm Description RLOS RLOS RAIS... -
Page 27: Alarm History At The Hdsl2 Interface
152-402-145-02, Issue 2 Alarm History at the HDSL2 Interface Figure 18 Figure 19 are examples of Alarm History screens for the H2TU-R HDSL2 interface and the H2TU-C HDSL2 interface, respectively. Current alarms are shown in reverse video. The types of alarms reported for the H2TU-R are described in Monitor Performance... -
Page 28: Using The Event Log To Track System Events
Monitoring System Activity and Performance Table 8. H2TU-R HDSL2 Alarm Descriptions Screen Alarm Front-Panel Alarm Description LOSW LOSW HBER HBER SING THE VENT OG TO To view a running log of system events, press time of the 100 most recent events (most recent displayed first) and provides a description of each event. See Table 9 on page 23 for a complete list of event log messages. -
Page 29: Event Log Messages
152-402-145-02, Issue 2 DS1 Alarm History reset DS1 PM register reset HDSL2 Alarm History reset HDSL2 PM register reset Loop Down (any segment) Loop Up (any segment) Provisioning option change: <provisioning mnemonic>: changed from <old> to <new> CPE DBER alarm (1-day threshold crossed of any PM data except PRM-NE or PRM-FE) CPE DS1 AIS begins/ends CPE DS1 LOS begins/ends CPE PRM-NE BER alarm (at the remote only: 1-day threshold crossed of PRM-NE: trouble on CPE receive) -
Page 30: Loopback Operation
Loopback Operation OOPBACK PERATION HiGain HDSL2 has a family of loopback options for analyzing circuit functionality. The loopback signal is transmitted and returned to the sending device for comparison. This allows you to verify the integrity of the HDSL2 channels to the H2TU-C, the H2TU-C DSX-1 interface, and the DS1 channels to the customer. Loopback options include: •... -
Page 31: Summary Of Higain Hdsl2 Loopback Codes And Activation Methods
152-402-145-02, Issue 2 Table 10. Summary of HiGain HDSL2 Loopback Codes and Activation Methods Loopback Code Description NLOC 1111000 DSX-1 signal is looped back to the network at the H2TU-C. 4-in-7 NREM 1110000 DSX-1 signal is looped back to the network at the H2TU-R. 3-in-7 CLOC 1111100... -
Page 32: Special Loopback Commands
In addition to the GNLB loopback command mode, a HiGain HDSL2 system can be configured for one of three special loopback command modes. These command modes, A2LB, A3LB, and A4LB, are selected from the ADC Options maintenance terminal screen or by using the MODE and SEL buttons on the H2TU-C front panel. Once a loopback mode is activated, other loopback commands can be sent by a test set connected to the craft port on the H2TU-C or H2TU-R front panel. -
Page 33: Loopback Modes
152-402-145-02, Issue 2 Repeat Step 2. If the test passes, the problem is in the downstream direction. If it fails, the problem is in the upstream direction. H2TU-R-402 Figure 22. Loopback Modes June 16, 2000 Loopback Operation... -
Page 34: A2Lb Test Procedures
Loopback Operation A2LB Test Procedures Using the codes listed in Table 11, a network tester can activate NLOC, NRG or NREM loopbacks (or SMJK, if enabled). A tester at the customer premises can activate CLOC, CRG, or CREM loopbacks. Table 11. Addressable Repeater Loopback Commands (A2LB) Name ARMING or NI LPBK (inband) ARMING or NI LPBK (ESF Datalink) - Page 35 152-402-145-02, Issue 2 Once armed, the H2TU-R-402 can be looped back by sending Intelligent Office Repeater (IOR) LPBK activation code 1101-0011-1101-0011 (D3D3) for at least 5 seconds. You should observe the following activation response pattern: 2 seconds of AIS (all ones pattern) 2 seconds of returning data pattern Logic errors (including the frame bit) occurring in the returned pattern comprising: –...
-
Page 36: A3Lb And A4Lb Test Procedures
Loopback Operation A3LB and A4LB Test Procedures The H2TU-C can be looped back by sending the Addressable Office Repeater (AOR) LPBK activation code 1111-1111-0001-1110 (FF1E) for at least 5 seconds. This causes the H2TU-R-402 to enter the NLOC state. The H2TU-C Loopback Time-out (LBTO) setting determines the duration of this loopback unless it is overridden by the reception of a second identical 16-bit loopup command before the timer expires. -
Page 37: Appendix A - Specifications
152-402-145-02, Issue 2 A - S PPENDIX Power HDSL2 Span Voltage Line or Local Power Consumption Electrical Protection Environmental Operating Temperature Operating Humidity Physical Height Width Depth Weight Mounting HDSL2 Line Rate Transmission Media Output Line Impedance Maximum Loop Attenuation Start-up Time DS1 Line Impedance DS1 Line Rate... -
Page 38: Loop Attenuation
Appendix A - Specifications TTENUATION Each loop has no more than 35 dB of loss at 196 kHz, with driving and terminating impedances of 135 (see Table 13 below). Table 13. HDSL2 Cable Attenuation Chart Cable Gauge 26/0.4 mm 24/0.51 mm 22/0.61 mm 19/0.91 mm H2TU-R-402 L... -
Page 39: Craft Port
152-402-145-02, Issue 2 RAFT Figure 24 shows the pinout for the craft port connector and its connection to a DB-9 or DB-25 connector on a maintenance terminal. H2TU-R-402 DB-9 Connector (DCE) H2TU-R-402 TD (Transmit Data) RD (Receive Data) Figure 24. RS-232 Craft Port Pinouts June 16, 2000 Appendix A - Specifications Terminal... -
Page 40: Appendix B - Functional Operation
B - F PPENDIX ADC HDSL2 technology provides full-duplex services at standard DS1 rates over copper wires between an H2TU-C and an H2TU-R, which comprise one HiGain HDSL2 system. HiGain HDSL2 systems use ADC Overlapped PAM Transmission with Interlocking Spectra (OPTIS) transceiver systems to establish full-duplex, 1.552 kbps data channels between the remotely located H2TU-R-402 List 4E and an H2TU-C. -
Page 41: Appendixc - Compatibility
152-402-145-02, Issue 2 C - C PPENDIX The HiGain HDSL2 system uses HDSL2 transmission technology as recommended by Bellcore TA-TSY-001210. HiGain HDSL2 complies with GR-63-CORE, TR-TSY-000499, and GR-1089-CORE. The H2TU-R-402 List 4E is compatible with the following shelves (for indoor use): •... -
Page 42: Appendix D - Product Support
D - P PPENDIX ADC Customer Service Group provides expert pre-sales and post-sales support and training for all its products. Technical support is available 24 hours a day, 7 days a week by contacting the ADC Technical Assistance Center (TAC). Sales Assistance 800.366.3891 extension 73000... -
Page 43: Appendix E - Abbreviations
Appendix E - Abbreviations E - A PPENDIX ACO: Alarm Cutoff ACON: Auto Conversion ADSL: Asymmetrical Digital Subscriber Line AIS: Alarm Indication Signal AIS-CI: Alarm Indication Signal-Customer Installation ALM: Alarm ALMP: Alarm Pattern ANSI: American National Standards Institute AOR: Addressable Office Repeater ARM: Armed AUTO:... - Page 44 152-402-145-02, Issue 2 NREM: Network Remote Loopback NTF: No Trouble Found OOF: Out-of-Frame OPTIS: Overlapped Pulse Amplitude Modulation Transmission with Interlocking Spectra OUT: Receive PBOC: Power Back Off Customer PBON: Power Back Off Network Payload POTS: Plain Old Telephone Service PRM: Performance Report Messaging PRM-FE: Performance Report Messaging-Far End...
-
Page 45: Certification And Warranty
ADC during the 90-day warranty period is, at ADC’s option, either (a) return of the price paid or (b) repair or replace of the software. ADC also warrants that, for a period of thirty (30) days from the date of purchase, the media on which software is stored will be free from material defects under normal use. - Page 46 ADC DSL Systems, Inc. 14402 Franklin Avenue Tustin, CA 92780-7013 Tel: 714.832.9922 Fax: 714.832.9924 Technical Assistance Tel: 800.638.0031 Tel: 714.730.3222 Fax: 714.730.2400 : 152-402-145-02, I OCUMENT SSUE ISO 9001/TL 9000 ´+z.¶9G¨ 1214394 DNV Certification, Inc. REGISTERED FIRM...
