ADC Release 3.1 User Manual page 442

1152700 Issue 1 February 2001 Section 2 Operation and Maintenance
DLP-794
Page 3 of 3
Cellworx Vision: PM Threshold Configuration AAL1 Layer
Card Type
T3 CES
Figure 794-3. Performance Monitoring T3 CES Port Configuration Window
MONTYPE MAX 15-MINUTE
THRESHOLD
SEs 900
LCs 900
BUs 900
BOs 900
SCIs 16383
DCs 900
Page 2-422
© 2000, ADC Telecommunications, Inc.
Resource
SEs LCs
8-1
60 3
Apply
Table 794-1. T3 CES Performance Monitoring Values
Sets the number of AAL1 Sequence Errors the port can incur before the
system declares a TCA.
Sets the number of Lost Cells the port can incur before the system declares a
TCA.
Sets the number of Buffer Underflows the port can incur before the system
declares a TCA.
Sets the number of Buffer Overflows the port can incur before the system
declares a TCA.
Sets the number of Stuffing Cells Inserted the port can incur before the
system declares a TCA.
Sets the number of Discarded Cells the port can incur before the system
declares a TCA.
BUs BOs SCIs
75 10 60
Close
COMMENTS
X
DCs
3
0026-005
