Cellworx Vision: PM Threshold Configuration AAL1 Layer
Card Type
T1 MULTI
Figure 729-3. Performance Monitoring T1 Multi Port Configuration Window
Table 729-1. T1 Multi 1 CRS Performance Monitoring Values
MONTYPE MAX 15 MIN.
THRESHOLD
CV-L 16383
ES-L 900
SES 900
CV-P 16383
UAS 900
BES 900
CSS 900
SEFS 900
DM 2
ES 900
1152700 Issue 1 February 2001 Section 2 Operation and Maintenance
Slot-Port ESs SESs
S4-P1
0 0
Apply
COMMENTS
Sets a count of line code violations that the port can incur before creating a
TCA on the system. Line code violation is a count of *BPVs and *ExZs.
Sets a count of line errored seconds that the port can incur before creating a
TCA on the system. ES-L is determined as number of seconds that BPV and
ExZ >=1 or LOS (loss of Signal) >=1.
Sets a count of line severely errored seconds that the port can incur before
creating a TCA on the system. SES is determined as the number of seconds
CV-L >=1547 or LOS (Loss of Signal) >=1.
Sets a count of path code violations that the port can incur before creating a
TCA on the system. CV-P determined from SF count of FE, or ESF count of
CRC errors.
Sets a count of unavailable seconds that the port can incur before creating a
TCA on the system. UAS determined as the number of seconds that the path is
unavailable.
Sets a count of Burst Errored Seconds that the port can incur before creating a
TCA on the system.
Sets a count of Controlled Slip Seconds that the port can incur before
creating a TCA on the system. CSS is determined as a count of 1 second
intervals where CS >=1.
Sets a count of severely errored frame seconds that the port can incur before
creating a TCA on the system. SEFS determined when SEF >=1.
Sets a count of minutes that the port can incur a signal degradation before
creating a TCA on the system.
Sets a count of errored seconds that the port can incur before creating a TCA
on the system. Error seconds determined as number of seconds FE>=1, SEF
>=1, or any Cellworx Vision/AIS condition.
