2. USER INTERFACES

The Network Management Interface Controller (NMIC) shown in Figure 1-2
provides a common ring and element management system platform where all
aspects of network management are performed. The NMIC houses the operating
system and application software for each node and card to provide Fault,
Configuration, Performance, and Security management functions based on TMN
principles at the Element Management Layer.
Page 1-2
© 2000, ADC Telecommunications, Inc.
SHELF
ALARM
INDICATOR
Figure 1-1. Cellworx STN Shelf
UPPER HEAT BAFFLE/
FIBER MANAGEMENT TRAY
ESD GROUND JACK
DOOR
LATCH
10479-C
