ADC Release 3.1 User Manual page 107

DISPLAYS NAME AND TYPE
OF SELECTED CONNECTION.
VERIFY INTERFACE AND VPI
BEING CONFIGURED.
SELECT A QOS CLASS.
SELECT A TRAFFIC CONTRACT
FROM AVAILABLE LIST OR
SELECT NEW TO CREATE A
NEW TRAFFIC CONTRACT.
VERIFY DESTINATION INTERFACE
AND VPI BEING CONFIGURED.
SELECT A QOS CLASS.
SELECT A TRAFFIC CONTRACT
FROM AVAILABLE LIST OR
SELECT NEW TO CREATE A
NEW TRAFFIC CONTRACT FOR
DESTINATION NE. SAME TRAFFIC
CONTRACT CAN BE USED FOR
BOTH NEs.
SELECT APPLY TO CONFIGURE
THE NEW CONNECTION.
Figure 708-6. Cellworx Vision ATM Virtual Path Connection Configuration
1152700 Issue 1 February 2001 Section 2 Operations and Maintenance
Cellworx Vision: Connection Configuration
Connection Name:
NE-1 <--> NE-2
Connection Type: ATM VP - ATM VP
NE-1
UNI: ds1ces: S-3: P-3: L-atm: I-1 VPI: 1
Service Class Type CBR
Ingress Traffic Contract:
<NEW>
NE-1
UNI: Slot8:Port1 OC3SM VPI: 5
Service Class Type CBR
Ingress Traffic Contract:
<NEW>
Apply Refresh
Page 7 of 7
Locked
Unlocked
Close
<< Previous
© 2000, ADC Telecommunications, Inc.
DLP-708
X
14452-A
Page 2-87
