ADC Release 3.1 User Manual page 23

1152700 Issue 1 February 2001 Section 1 Introduction
ICON FOR NE-2 INDICATES
THE PRESENCE OF STN-EPS
SHELVES
File
Cellworx User: root
Local Time: 21:37 GMT Time: 21:37
Figure 1-5. Example of Primary Node with Secondary Expansions
Figure 1-6. Primary Node Physical Layout to Secondary Nodes
An Auto Discovery feature allows the NMIC to search for and display all nodes
connected in the network during initial system turn-up. Main menu headings are
displayed at the top of the screen (File, Configuration, Fault, Performance) and
when selected will allow the user to perform all higher level functions such as
system administration, establish end to end VP/VC connections, request
performance reports, or display network alarm summaries.
Page 1-6
© 2000, ADC Telecommunications, Inc.
Cellworx Vision: Subnetwork Management System
Configuration Fault Performance
STN
STN
STN
NE-2
Cellworx Vision:Physical Layouts for NE-2
NE-2
GNE-1
NE-3
EPS-2
EPS-1
Cancel
Help
10926-D
X
10960-B
