NTP-012
Page 1 of 1
PERFORM ROUTINE OR NON-ROUTINE MAINTENANCE
Summary: This procedure lists procedures that can be followed to perform maintenance tasks on
a Cellworx STN ring network that may or may not be considered routine. Non-routine
maintenance may include installing new software versions on the NMIC, downloading new
software to interface cards, forcing cards off-line for maintenance procedures, and
troubleshooting alarms. Routine maintenance may include executing an Alarm Cut-Off (ACO),
retrieving performance monitoring reports, retrieving inventory lists, or retrieving alarm reports.
Graphical User Interface Procedures
1. Force Network Discovery
2. Launch the Cellworx Vision GUI from the X-Terminal
3. NMIC System File Replication
4. NMIC Protection
5. Perform Diagnostics on the optical cards
6. Retrieve Logs from the NMIC via FTP
7. Retrieve Compressed Logs from NMIC via FTP
8. Select different software versions for a particular card
9. View Ring Resource Usage
10. View Fiber Bandwidth Usage
Stop! You have completed this procedure.
ADCP-70-220 Issue 1 November 2000 Section 2 Operation and Maintenance
DLP-719
DLP-705
DLP-722
DLP-724
DLP-766
DLP-741
DLP-742
DLP-720
DLP-715
DLP-716
Page 2-27
