- Page 1 ANUAL HRE-602 List 1 Part Number: 150-2255-01 CLEI: T1M1ZM0C HRE-602 List 1B Part Number: 150-2255-12...
- Page 2 Contents herein are current as of the date of publication. ADC reserves the right to change the contents without prior notice. In no event shall ADC be liable for any damages resulting from loss of data, loss of use, or loss of profits, and ADC further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages.
- Page 3 Unpack each container and inspect the contents for signs of damage. If the equipment has been damaged in transit, immediately report the extent of damage to the transportation company and to ADC DSL Systems, Inc. Order replacement equipment, if necessary.
- Page 4 Inspecting Shipment 150-602-100-04 September 29, 2000 HRE-602 List 1 and List 1B...
-
Page 5: Table Of Contents
Installing Doublers ..........................9 Mounting ............................10 Grounding ............................10 Appendix A - Specifications____________________________________________________________ 11 Appendix B - Product Support _________________________________________________________ 12 Appendix C - Abbreviations ___________________________________________________________ 13 Certification and Warranty______________________________________________ Inside Back Cover HRE-602 List 1 and List 1B September 29, 2000... - Page 6 5. End Cap Compression Bolts.......................... 9 6. Front View of Mounting Hole Locations ....................10 IST OF ABLES 1. Cable Stub Length............................1 2. Installation Kit............................... 8 3. Torque Sequence Chart ..........................9 September 29, 2000 HRE-602 List 1 and List 1B...
-
Page 7: Overview
HiGain WorldAccess Mini Doublers (require two slots) – EDU-840 – EDU-841 The HRE-602 List 1 and List 1B differ only in the length of the gel-filled cable stub. Table 1 shows the difference between the two units. Table 1. Cable Stub Length... -
Page 8: Applications
Overview 150-602-100-04 PPLICATIONS The HRE-602 List 1 and List 1B houses doublers and allows quick and easy deployment of a single- or multi-doubler circuit, as shown in Figure Figure 1. HRE-602 Applications September 29, 2000 HRE-602 List 1 and List 1B... -
Page 9: Product Description
RODUCT ESCRIPTION The HRE-602 List 1 and List 1B include: • External mechanics featuring: – HRE-602 List 1: 20 ft (6.1 m) gel-filled stub HRE-602 List 1B: 100 ft (30.48 m) gel-filled stub – Ground wire – End cap •... -
Page 10: External Mechanics
Central office to Customer Slot 1 - Brown/White Slot 1 - Green/White Slot 2 - Green/Red Slot 2 - Orange/Red Spare Pairs Brown/Red Slate/Red Blue/Black Orange/Black Figure 2. HRE-602 External Mechanics September 29, 2000 HRE-602 List 1 and List 1B... -
Page 11: Hre-602 Gel-Filled Stub
Blue/ Slate White Green Orange Blue HDSL IN 1 HDSL IN 2 HDSL OUT 2 HDSL OUT 1 Pair 5 Pair 8 Pair 7 Pair 6 Field Figure 3. Wiring Diagram HRE-602 List 1 and List 1B September 29, 2000... -
Page 12: Ground Wire
Figure 4 shows a front view of the HRE-602. Doublers Card-edge connectors Lightning surge protectors Inner bracket Ferrite coil Elastometric seal Outer bracket 12-Pair Ground wire cable stub Figure 4. Internal Mechanics September 29, 2000 HRE-602 List 1 and List 1B... -
Page 13: Card-Edge Connectors
Full solar load is equal to maximum sunlight exposure as defined in Bellcore’s Technical Advisory TR-TSY-000057. HRE-602 R EPLACEMENT A replacement kit containing twenty TII 47BT gas-tube protectors is available from ADC (part number 132-1028-01). “Appendix B - Product Support” on page 12 details the ordering information. -
Page 14: Installation
Installation 150-602-100-04 NSTALLATION This section provides information on installing a doubler or repeater in the HRE-602 List 1 and List 1B and mounting the enclosure. Part number and wiring information are also provided. NSTALLATION Table 2 lists the HRE-602 installation kit components. If any of these items are missing or the shipment damaged, please contact your HiGain sales representative. -
Page 15: Installing Doublers
55 inch/pounds (139.7 centimeter/kilograms) 55 inch/pounds (139.7 centimeter/kilograms) 55 inch/pounds (139.7 centimeter/kilograms) 70 inch/pounds (177.8 centimeter/kilograms) 75 inch/pounds (190.5 centimeter/kilograms) 75 inch/pounds (190.5 centimeter/kilograms) 75 inch/pounds (190.5 centimeter/kilograms) 75 inch/pounds (190.5 centimeter/kilograms) HRE-602 List 1 and List 1B September 29, 2000... -
Page 16: Mounting
Failure to do so will expose the signal pairs to stray EMI which could introduce service affecting noise into the information payload. The No. 6 ground wire must also be properly grounded to provide both EMI and voltage surge protection for the doublers. September 29, 2000 HRE-602 List 1 and List 1B... -
Page 17: Appendix A - Specifications
150-602-100-04 Appendix A - Specifications A - S PPENDIX PECIFICATIONS The HRE-602 List 1 and List 1B outer enclosure has the following specifications: Length 12.5 in (31.7 cm) Width 3 in (7.7 cm) Depth 2 in (5.1 cm) Weight 3.5 lbs (1.6 kg) -
Page 18: Appendix B - Product Support
UPPORT ADC Customer Service Group provides expert pre-sales and post-sales support and training for all its products. Technical support is available 24 hours a day, 7 days a week by contacting the ADC Technical Assistance Center. • Quotation Proposals Sales Assistance •... -
Page 19: Appendixc - Abbreviations
CLEI: Common Language Equipment Identifier Central Office EDU: ETSI Doubler Unit EMI: ElectroMagnetic Interference ETPR: Extended Thermoplastic Rubber HDU: HiGain Doubler Unit HRE: HiGain Remote Enclosure ICEA: Insulated Cable Engineers Association HRE-602 List 1 and List 1B September 29, 2000... - Page 20 Appendix C - Abbreviations 150-602-100-04 September 29, 2000 HRE-602 List 1 and List 1B...
-
Page 21: Certification And Warranty
OMPLIANCE The HRE-602 List 1 and List 1B do not have a clocking source and are passive devices per FCC guidelines. When a unit is used in conjunction with any clocking devices, this combined system may radiate radio frequency energy that causes harmful interference to radio communications. - Page 22 ADC DSL Systems, Inc. 14402 Franklin Avenue Tustin, CA 92780-7013 Tel: 714.832.9922 Fax: 714.832.9924 Technical Assistance Tel: 800.638.0031 Tel: 714.730.3222 Fax: 714.730.2400 : 150-602-100-04 OCUMENT ISO 9001/TL 9000 ´,J@¶5q¨ 1242325 DNV Certification, Inc. REGISTERED FIRM...
