NTP-002
Page 2 of 2
7. Launch the Cellworx Vision Graphical User Interface (GUI).
8. After the GUI boots up, it will prompt the user to synchronize
the database. Choose the active NMIC's database as the correct
database to synchronize.
9. Perform a discovery for a new Cellworx STN ring network.
10. Set the Date and Time on the NMIC.
11. Set the System Identifier for each node.
12. After all nodes are successfully discovered, configure them
before adding any expansion shelves. Configuration may include
timing configuration, locking ports to remove LOS alarms,
configuring the max VC bits to greater than zero to allow VC
connections for each port, etc.
13. Refresh the GUI screen so the nodes will display the new names.
14. Perform acceptance tests on the new nodes per local
requirements.
15. Add expansion shelves to the ring nodes if equipped.
16. Save the NMIC database.
Stop! You have completed this procedure.
ADCP-70-220 Issue 1 November 2000 Section 2 Operation and Maintenance
DLP-705
DLP-706
DLP-707
DLP-767
NTP-006
DLP-718
NTP-011
NTP-005
DLP-745
Page 2-9
