ADC Release 3.1 User Manual page 187

Current Ring Level:
Upgrade Ring Level:
Upgrade Ring Software:
Figure 731-5. Ring Upgrade Configuration Window
Ring Upgrade - Instruction
Do not reset RICs in slot 17 until upgrade of slot 16 RICs completes.
Do not reset SCCs until ring upgrade completes.
Figure 731-6. Ring Upgrade Instructional Window
Ring Upgrade - RIC Status
Wait for the 2488 Ring RICs in slot 16 to boot.
Network Element
NE 1 - Broadway
NE 2 - 17th Street
NE 3 - Northwest St.
NE 4 - Central Ave.
NE 5 - Duncan Dr.
Suspend
Figure 731-7. Ring Upgrade RIC Status Window
1152700 Issue 1 February 2001 Section 2 Operation and Maintenance
Ring Upgrade - Configuration
OC12c
OC48c
2.0.0.12
Cancel Refresh
Next>>
RIC Type (16)
622 Ring
622 Ring
622 Ring
622 Ring
622 Ring
Refresh
X
Next >>
0026-033
X
0026-034
Running SW (16)
oc12ric.2.0.0.10
oc12ric.2.0.0.10
oc12ric.2.0.0.10
oc12ric.2.0.0.10
oc12ric.2.0.0.10
Next >>
0026-035
2000, ADC Telecommunications, Inc.
DLP-731
Page 5 of 9
X
Page 2-167
