1152700 Issue 1 February 2001 Section 2 Operation and Maintenance
DLP-726
Page 2 of 4

THRESHOLD CONFIGURATION

9. Users may specify error counts required to trip a system alarm by clicking on the
Configure Thresholds button at the bottom of the PM Data window. This will bring up a
Performance Monitoring Configuration window similar to
10. To configure the thresholds, place the cursor in the individual count boxes and type in the
new threshold value. Do this for all the thresholds to be set in the Section, Line, and Path
tabs. Refer to Table 726-1 for valid values. Once all counts are entered in each box, select
the Apply button at the bottom of the screen to send the new data to the database. The
Apply button includes each tab in the request.
Stop! You have completed this procedure.
SELECT AN NE FOR PM
SELECT A SLOT AND CARD
RETRIEVAL AND THE SLOT
TYPE, INDIVIDUAL OR
AND CARD TYPES IN THE
MULTIPLE, TO DISPLAY THE
SHELF WILL BE DISPLAYED
PORTS IN THE NEXT WINDOW.
IN THE NEXT WINDOW.
Cellworx Vision: Performance Monitoring - Statistics
Resource: NE-1
Slot / Card Type
Slot 17 / 622 Ring
NE-1
Cellworx1
Slot 16 / 622 Ring
Cellworx2
NE-2
Slot 5 / T3 TMUX Multi 1
NE-3
Cellworx3
Slot 6 / 155 SM CRS
Slot 7 / 155 SM CRS
Slot 8 / 155 SM CRS
Slot 9 / 155 SM CRS
Slot 10 / T3 CRS
Slot 11 / T3 CRS
Slot 12 / T1 Multi 1
Apply
SELECT TO RETRIEVE PM
DATA FOR SELECTED
PARAMETERS.
Figure 726-1. Performance Monitoring – Selection Window
Page 2-144
2000, ADC Telecommunications, Inc.
SELECT THE PORT(S) DESIRED
SELECT THE PM LAYER(S)
TO DISPLAY THE LAYERS
TO BE RETRIEVED.
AVAILABLE IN THE NEXT
WINDOW.
Port
Layer
Sonet
Slot 16 / Port 1
DS1/E1
Slot 16 / Port 2
DS3
Slot 17 / Port 1
PLCP
Slot 17 / Port 2
ATM / TC
Slot 5 / Port 1
AAL1
- Channel 1
- Channel 2
- Channel 3
- Channel 4
- Channel 5
Figure
726-3.
SELECT THE CURENT
COUNT OR A HISTORICAL
TIME PERIOD FOR ONE
SLOT/PORT. USER CANNOT
SELECT CURRENT AND A
HISTORICAL AT THE SAME
TIME.
Interval
current
00:00-00:15
00:15-00:30
00:30-00:45
00:45-01:00
01:00-01:15
01:15-01:30
01:30-01:45
01:45-02:00
0200 - 02:15
Close
CLOSES PM STATISTICS
WINDOW.
X
11743-D
