ADC Release 3.1 User Manual page 68

1152700 Issue 1 February 2001 Section 2 Operations and Maintenance
DLP-701
Page 3 of 10
1 2 3 4
RECEIVE FIBERS FROM ONE DIRECTION.
Figure 701-2. Routing Fiber Across the Fiber Management Panel
RX
NODE 4 SLOT 17
TX
Page 2-48
© 2000, ADC Telecommunications, Inc.
FIBERS DESTINED FOR SLOT 13
DROP THROUGH THE UPPER
ROUTING FLANGES AT SLOT 12.
5 6 7 8 9
NODE 1
SLOT 17
TX
SLOT 16
RX
TX
SLOT 16
RX
SLOT 16
TX
SLOT 17
RX
NODE 3
Figure 701-3. 622 RIC Fibering Convention
FIBERS FROM SLOT 13 ARE ROUTED
THROUGH THE UPPER ROUTING
FLANGES AT SLOT 14.
10 11 12 13 14
TRANSMIT FIBERS IN ONE DIRECTION
RX
TX
RX TX
SLOT 17
SLOT 16
RX
TX
RX
TX
12385-A
15 16 17 18
10716-C
NODE 2
