10. To configure the thresholds, place the cursor in the individual count boxes and type in the
new threshold value. Refer to Table 730-1 for valid values. Once all counts are entered in
each box, select the Apply button at the bottom of the screen to send the new data to the
database.
Stop! You have completed this procedure.
Cellworx Vision: Performance Monitoring Selection Criteria
Resource:
NE 1: Cellworx1
NE 2: Cellworx2
NE 3: Cellworx3
NE 4: CellworxEXP
Figure 727-1. Performance Monitoring Selection Criteria Screen (example)
Cellworx Vision: Performance Monitoring Data NE 2
Only non-zero selected intervals are displayed.
DS1
Card Type Slot-Port
T1 Multi 1 S10-P1-C1
Refresh
Figure 727-2. Performance Monitoring Data – T3 TMUX Multi 1 Port (example)
Cellworx Vision: PM Threshold Configuration AAL 1 Layer
Card Type
T3 TMUX Multi 1
Figure 727-3. Performance Monitoring Configuration – T3 TMUX Multi 1 Port (example)
Page 2-148
2000, ADC Telecommunications, Inc.
Slot / Card Type Port
Slot 4 / T1 MULTI 1 Slot 6 / Port 1
Slot 5 / T1 MULTI 1
-- Slot 6 / Port 1 / Ch
Slot 6 / T3 TMUX MUL
-- Slot 6 / Port 1 / Ch
Slot 7 / T3 CRS
-- Slot 6 / Port 1 / Ch
Slot 10 / T3 CRS
-- Slot 6 / Port 1 / Ch
Slot 12 / 155 MM CRS
-- Slot 6 / Port 1 / Ch
Slot 16 / 622 Ring
-- Slot 6 / Port 1 / Ch
Slot 17 / 622 Ring
-- Slot 6 / Port 1 / Ch
-- Slot 6 / Port 1 / Ch
-- Slot 6 / Port 1 / Ch
Apply
Interval ESs SESs SEFSs
current
0 0 0
Refresh All Reset Selected
Slot-Port
ESs
SESs
S6-P1-C1 0
0
Apply
Layer Interval
AAL1 current
ATM/TC 00:00 - 00:15
00:15 - 00:30
DS1
00:30 - 00:45
00:45 - 01:00
01:00 - 01:15
01:15 - 01:30
01:30 - 01:45
01:45 - 02:00
02:00 - 02:15
Close
UASs CSSs PCVs LESs
0 0 900 0
Clear Selected Configure Thresholds
SEFSs UASs
CSSs
0
0
Close
