Cellworx Vision Subnetwork Connection Configuration
Connection Name :
Connection Type : ATM VP - ATM VP
Network Element: Node1
UNI/NNI: Slot10_Port10 DS1CESUNI
0
VPI:
Segment Endpoint
Ingress NDC
Egress NDC
Test Type:
Loopback Location ID:
Insert Loopback Cells:
Test Status: None
Test Status
Network Element: Node2
UNI/NNI: Slot12_Port15 DS1CESUNI
0
VPI:
Segment Endpoint
Ingress NDC
Egress NDC
Test Type:
Loopback Location ID:
Insert Loopback Cells:
Test Status: None
Test Status
Figure 723-4. Subnetwork Connection Configuration Window
