Adding Services To A Cellworx Stn Node - ADC Release 3.1 User Manual

ADCP-70-220 Issue 1 November 2000 Section 2 Operation and Maintenance

ADDING SERVICES TO A CELLWORX STN NODE

Summary: This procedure outlines the steps involved for assigning card, port, and user level
parameters for individual interface cards and configuring protection operation for grouped
interface cards within each node. The cards must be physically equipped within a shelf before the
slots can be configured via the software.
1. Verify the cards to be provisioned are physically equipped
within the shelf by double clicking on the node to open a shelf
level GUI display. Each card should have a green status
indicator.
Note: Applications using the 19-inch chassis will show card slots 1 through 18 but only
card slots 1 through 11 and 16 through 18 are programmable.
2. Refer to the Cellworx STN Installation manual for card
installation procedures if cards are not currently equipped,
otherwise continue.
3. To remove or install cards currently in the chassis, refer to:
4. Set the configuration options for the following cards when
equipped:
Set the E1 Multi 1 Card configuration.
Set the 622 RIC card configuration
Set the 155 CRS card configuration
Set the 622 CRS card configuration
Set the T3 CRS card ATM configuration
Set the T3 TMUX Multi 1 card configuration.
Set the T1 Multi 1 Card configuration.
Set the 2488 RIC card configuration options.
Set the 155 RIC configuration options.
Set the FE1 FRS Card configuration.
Set the FT1 FRS Card configuration.
Set the T3 CES Card configuration
5. Configure card protection groups if applicable for each group of
interface cards.
6. Close the card configuration window to return to the shelf
display. Verify that the required cards are in-service by the
green status indicator.
7. Perform acceptance tests on the new access cards when
applicable.
Stop! You have completed this procedure.
Page 2-24
© 2000, ADC Telecommunications, Inc.
NTP-009
Page 1 of 1
1152693
DLP-777
DLP-747
DLP-751
DLP-752
DLP-797
DLP-753
DLP-754
DLP-755
DLP-756
DLP-758
DLP-784
DLP-785
DLP-792
DLP-765
NTP-011
