ADC Release 3.1 User Manual page 256

1152700 Issue 1 February 2001 Section 2 Operation and Maintenance
DLP-751
Page 3 of 3
Table 751-1. 622 RIC Card Configuration Options, continued
SELECTION DEFAULT
Signal 5
Degrade BER
Threshold
Medium Type SONET
Loopback None
towards
Line Coding NRZ
Line Type Card
Dependant
Transmit Path (example)
Trace
NE1_Slot17_
Port1 (OC12)
1
Page 2-236
© 2000, ADC Telecommunications, Inc.
OPTIONS DEFINITION
5 through 9 Defines the number of bit errors the port can incur
before a signal degrade occurs and generates an
alarm message and probably protection switch.
SONET Not configurable on RIC. This is determined by the
dipswitch on the SC EIM, which sets the shelf type.
SDH
Can be SONET, Synchronous Optical Network, US,
or Synchronous Digital Hierarchy, European
standard for transporting data over fiber.
None No loopback activated on this card.
Terminal Sends cells back to the cellbus and back out to the
ring. No changes are made to the path layer data.
Facility Loops the incoming signal back to the CPE and
generates AIS to the cellbus.
Not configurable by user.
SonetOther Not configurable by user, dependant on card type
inserted.
sonetShortSingle
Mode
sonetLongSingle
Mode
sonetMultiMode
Card position dependent. This is assigned by the
system according to the NE and slot it is equipped in.
