Cellworx Vision: Connection Configuration
DISPLAYS CONNECTION NAME.
Connection Name: Broadcast-1 Uptown
DISPLAYS CONNECTION TYPE
Connection Type:
SPECIFIED IN SEARCH.
Root Network Element: NE-1
UNI/NNI: oc3cmm:S-14:P-1:L-atm:I-1
VPI: 5
VCI: 32
SELECT USAGE DATA OR
Segment Endpoint
NDC COLLECTION FOR
ROOT ENDPOINT. HIT
Leaf Endpoints:
APPLY TO UPDATE ANY
CHANGES.
Network Element
NE-2
NE-4
NE-6
VCI: 32
LOCK OUT ANY SELECTED
Administrative State:
LEAF ENDPOINT.
Segment Endpoint
HIGHLIGHT A LEAF AND
SELECT USAGE DATA
OR NDC COLLECTION.
HIT APPLY TO UPDATE Apply
ANY CHANGES.
USE TO APPLY NEW
NDC AND USAGE
DATA SELECTIONS.
Figure 791-5. ATM Bundled VC Multicast Configuration Window
SELECT AN NE FROM
LIST FOR DESTINATION
ENDPOINT.
Cellworx Vision: Add Leaf
Resource: NE-1 Slot / Card Type
NE-1 Cellworx1
17 622 Ring
NE-2 Cellworx2
16 622 Ring
NE-3 Cellworx3
5 T3 TMUX Multi 1
6 155-UNI SM/ST
7 155-UNI SM/ST
8 155-UNI SM/ST
9 155-UNI SM/ST
10 DS3 CRS
11 DS3 CRS
12 T1 Multi 1 CRS
14 155-UNI MM/ST
Next>>
CLICK ON NEXT TO
CONTINUED TO NEXT
CONFIGURATION WINDOW.
Figure 791-6. Add Leaf Window – NE, Slot, VPI Selection
1152700 Issue 1 February 2001 Operation and Maintenance
ATM Bundled VC MULTICAST
Ingress NDC Egress NDC
Interface VPI
oc3cmm:S-11:P-2:L-atm:I-1 5
DS3crs:S-8:P-1:L-atm:I-1 5
T1multi1:S-14:P-5:L-atm:I-1
5
Locked Unlocked
Ingress NDC Egress NDC
Add
Retry
Refresh
Leaf
Leaf
USE TO REFRESH USE TO RETRY
DISPLAYED DATA A FAILED LEAF
AFTER RETRY, ADD, CONNECTION.
OR DELETE LEAF
CONNECTIONS.
SELECT A CARD SELECT A NETWORK INTERFACE
FROM NE FOR FROM LIST FOR DESTINATION
DESTINATION ENDPOINT.
ENDPOINT.
Network Interface / Interface Type
oc3cmm:S-14:P-1:L-atm:I-1 / UNI
oc3cmm:S-14:P-2:L-atm:I-1 / UNI
Refresh
REFRESHES THE DATA
ON THIS WINDOW AFTER
CHANGES ARE MADE.
X
Administrative State:
Locked
Unlocked
Status
FUNCTIONAL
FUNCTIONAL
FUNCTIONAL
Delete
Close
Leaf
TAKES USER TO DELETES THE HIGHLIGHTED
A NEW LEAF LEAF ENDPOINT.
CONFIGURATION
WINDOW.
SPECIFY A VPI FOR THE
ENDPOINT.
Page
1
VPI / NE / Rate (Kbps):
0
1
2
3
4
5
6
7
Close
CLOSES THIS WINDOW WITHOUT
SAVING CHANGES.
