The fs Commands
Where:
Value
communication_state
current_transfer_rate rate at which the last 128 MB of data was sent across the IP network.
avg_transfer_rate
source_ip
source_port
destination_ip
destination_port
QOS_bandwidth
Where:
Value
Source File System:
Delta
Create Time
Dur
Blocks
Destination File System:
Playback Time
Dur
Blocks
DSiG
EXAMPLE #3
$ fs_replicate -abort src_ufs1
operation in progress (not interruptible)...id
name = src_ufs1
acl = 0
in_use = True
type = uxfs
worm = off
volume = v156
pool = clar_r5_performance
member_of = root_avm_fs_group_3
rw_servers= server_2
ro_servers=
rw_vdms =
ro_vdms =
ckpts = src_ufs1_ckpt1
ip_copies = dst_ufs1:cs110
stor_devs = APM00042000818-0014,APM00042000818-001B,APM00042000818-0018,APM00042
000818-0017
disks = d21,d12,d19,d10
disk=d21 stor_dev=APM00042000818-0014 addr=c16t0l15
disk=d21 stor_dev=APM00042000818-0014 addr=c48t0l15
disk=d21 stor_dev=APM00042000818-0014 addr=c0t0l15
84
Celerra Network Server Command Reference Manual
For the Communication between Celerras Definition
whether the Data Movers on each Celerra system can communicate with each other.
average rate at which the last 128 sets of data were sent across the IP network.
IP address of the source Data Mover.
port number of the source Data Mover that is assigned dynamically.
IP address of the destination Data Mover.
port number of the destination Data Mover. This is always assigned the number 8888 by default.
IP network bandwidth throttle that can be used for this replication relationship. Zero (0) represents
unlimited bandwidth.
For the Verbose option Definition
delta set number or delta set ID that was created.
date and start time the delta set was created.
duration of time (in seconds) that it took to create the delta set.
number of blocks modified in the delta set.
date and start time the delta set was replayed to the destination file system.
duration of time (in seconds) that it took to replay the delta set or DSiG.
number of blocks modified in the delta set.
number of delta sets in the group that were played back. In some instances, the playback service
can play back more than one delta set at a time. In this case, the Dur and Blocks fields refer to the
group as a whole, not an individual delta set.
To abort replication on the source side of the replication relationship,
from the source Control Station type:
= 58
server=server_2
server=server_2
server=server_2
