session_id = fs25_T6_LUN0_000190100577_0047_fs23_T2_LUN0_000190100559_0047
application_label = RM/SE_WINSERVER1_K:\
replication source:
src_target_name = iqn.1992-05.com.emc:dr-target
src_LUN_number = 0
name = fs25_T6_LUN0_000190100577_0047
replicator_state = WaitingForRequest
latest_snap_replicated = fs23_T2_LUN0_000190100559_0047.ckpt000
current_number_of_blocks = 0
transport_type = DP_REP_TRANSPORT_TYPE_RCP
replication destination:
dst_target_name = iqn.1992-05.com.emc:0001901005590047-2
dst_LUN_number = 0
name = fs23_T2_LUN0_000190100559_0047
playback_state = WaitingForRequest
outstanding snaps:
version_name
---------------------------------------- ---------------------------- ----------
data_communication_state = DP_REP_NETWORK_CONNECTION_NOT_IN_USE
ctrl_communication_state = DP_REP_NETWORK_CONNECTION_ALIVE
recent_transfer_rate = ~64936 kbits/second
avg_transfer_rate = ~64936 kbits/second
source_ctrl_ip = 172.24.102.213
source_ctrl_port = 0
destination_ctrl_ip = 172.24.102.202
destination_ctrl_port = 5081
source_data_ip = 172.24.102.213
source_data_port = 0
destination_data_ip = 172.24.102.202
destination_data_port = 8888
QOS_bandwidth = 2147483647 kbits/second
server_3:
server_4:
Where:
Value
session_id
alias
application_label
src_target_name
src_LUN_number
name
replicator_state
latest_snap_replicated
current_number_of_blocks number of block that need to be transferred.
transport_type
dst_target_name
dst_LUN_number
name
create_time
Definition
identifier of the iSCSi replication session. The identifier is a character string.
alias name for the iSCSI replication session.
name of the application that is using the iSCSI replication session.
formal (IQN or EUI) name of the iSCSI target with the source LUN.
logical unit number of the source LUN.
name of the source.
available states are: in transfer, transferred, active.
name of the most recent snapshot replicated to the destination.
type of transport used for replication. Default is RCP transport.
formal (IQN or EUI) name of the iSCSI target with the destination LUN.
logical unit number of the destination LUN.
name of the destination.
