Where:
Value Definition
ID of the Data Mover.
id
name of the Data Mover.
name
access control value for the VDM.
acl
for VDM server, the type is always VDM.
type
server the VDM is loaded on.
server
root filesystem of the VDM.
rootfs
I18N mode of the VDM. I18N mode is either ASCII or UNICODE.
I18N mode
file systems that are mounted on this VDM.
mountedfs
if it is a member of a cluster, then this field will show the cluster name.
member_of
whether the VDM is enabled or disabled, and whether it can be loaded ready, loaded active, mounted,
status
temporarily unloaded and permanently unloaded.
list the interfaces that is used for the services configured on this VDM. Currently only CIFS service is
Interfaces to
provided, so this field lists all the interfaces used in the cifs servers configured on this VDM.
services mapping
EXAMPLE #7
$ nas_server -name vdm_1 -type vdm -create server_2
-setstate mounted pool=clar_r5_performance -option fstype=uxfs
id = 3
name = vdm_1
acl = 0
type = vdm
server = server_2
rootfs = root_fs_vdm_1
I18N mode = UNICODE
mountedfs =
member_of =
status :
defined = enabled
actual = mounted
Interfaces to services mapping:
EXAMPLE #8
defined = enabled
actual = mounted
Interfaces to services mapping:
To create a mounted VDM named vdm_1 on server_2 using the
storage pool, clar_r5_performance with a rawfs type, type:
See Example #6 for a description of command output.
To set the state of a vdm_1 to mounted, type:
$ nas_server -vdm vdm_1 -setstate mounted
id = 3
name = vdm_1
acl = 0
type = vdm
server = server_2
rootfs = root_fs_vdm_1
I18N mode = UNICODE
